Denon AVR-1611 Service Manual

EXPLODED VIEW
s
76
G X3
G X3
D X3
E
28
T X5
32 X5
26
T
46
72
H x4
Q
T X5
33
29
T
70
P
P
4
3
2
1
15
18 -2
5
7
12
8
T X6
18 -1
17
16 -1
14
19
19
20
42
41 X4
40 X4
T x4
44
T
T
T
50
56
83
52
53
54
55
57
51
T
F
F
T
F
T
59
73
D
T
45
60
T
T
6
6
43 x3
82
T x3
T
82
BACK
PCB GUIDE CABLE
z
z
C X1
A X21
11
23
22
61
AVR1611 ALL
AVR591
AVR1621
C X1
A X21
I
P
P
4
3
2
1
11
23
5
7
18
20
14
8
T X6
15
17
16
19
19
18 -1
22
61
I
AVR1611 BKE2/SPE2
AVR591 BKEA
G X2
77 X6
78
Parts marked with this symbol have critical
characteristics.
Use ONLY replacement parts recommended by
the manufacturer.
WARNING:
91

Denon AVR-1611 Specifications

General

Impedance	6 Ω
Frequency range	10 - 100000 Hz
Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	98 dB
Total Harmonic Distortion (THD)	0.7 %
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Radio Data System (RDS)	Yes
Audio system	Dolby TrueHD, Dolby Digital Plus, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, DTS-HD, DTS 96/24
Output power	110 W
Dimensions (WxDxH)	434 x 381 x 171 mm
Power requirements	AC 230, 50 Hz
HDMI ports quantity	5
I/O ports	1 x Component 3 x Composite (Video) 5 x Analogue Audio (Tuner included) 1 x Composite Monitor 1 x Microphone Port 1 x Dock Control Port 1 x FM Tuner Antenna 1 x AM Tuner Antenna
Connectivity technology	Wired
Digital audio optical in	1
Product color	Black
Power consumption (standby)	0.1 W
Power consumption (typical)	360 W

Weight and Dimensions

Weight	9200 g
