Denon AVR-1611 Service Manual

127
PCB SPK ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
z
IC100 963239010480S IC PC123X2YFZ (DIP4P SHARP) K614123000010S
z
IC102 231010091708S IC TOP258MG G200258000010S *
IC116 212050010508S IC KIA2431AP J126243118010S
Q1-4 00D9630120704 TR KRA102S(PB) J520010200210S
Q5 00D9630120704 TR KRA102S(PB) 1611E3 J520010200210S
Q8-11 00D9630120801 TR 2SC KRC102S (NB) J522010200210S
Q12 00D9630120801 TR 2SC KRC102S (NB) 1611E3 J522010200210S
D1-4 00D9630355401 D,SWITCHING KDS4148U K005041480030S
D5 00D9630355401 D,SWITCHING KDS4148U 1611E3 K005041480030S
D8 00D2760401905 D,SWITCHING 1SS133T K000013300520S
D9,10 963209011740S D,RECTIFIER BRIDGE D3SB60-5000 K047036040030S
D100-102 00D9630328409 D,SWITCHING 1N4007 K000400700010S
D103 203050018706S D,SCHOTTKY D25SC6M 60V 25A K120256000010S
D104-106 00D9630328409 D,SWITCHING 1N4007 K000400700010S
D108 963209010430S D,FAST RECOVERY AP01C-V1 52RE-AX K050000015000S
D109,110 00D9630328409 D,SWITCHING 1N4007 K000400700010S
D112 00D2760401905 D,SWITCHING 1SS133T K000013300520S
ZD100 963202010440S D,ZENER MTZJ22B K06022R044520S
ZD101 00D2760762958 D,ZENER MTZJ39B 1611E3,591E3 K06039R044520S
ZD102 963202010440S D,ZENER MTZJ22B K06022R044520S
ZD103 00D2760762958 D,ZENER MTZJ39B 1611E3,591E3 K06039R044520S
ZD104 963202010440S D,ZENER MTZJ22B K06022R044520S
ZD105 00D2760762958 D,ZENER MTZJ39B 1611E3,591E3 K06039R044520S
ZD106,107 963202010440S D,ZENER MTZJ22B K06022R044520S
ZD108,109 00D2760762958 D,ZENER MTZJ39B 1611E3,591E3 K06039R044520S
ZD110 963202010440S D,ZENER MTZJ22B 1611E3,591E3 K06022R044520S
ZD110 00D2760762958 D,ZENER MTZJ39B
1611E2,1611E1C,1621E1C,
591AE
K06039R044520S
ZD111 00D2760762958 D,ZENER MTZJ39B
1611E2,1611E1C,1621E1C,
591AE
K06039R044520S
ZD112 963202010440S D,ZENER MTZJ22B K06022R044520S
ZD113 00D2760762958 D,ZENER MTZJ39B
1611E2,1611E1C,1621E1C,
591AE
K06039R044520S
ZD114 00D9600095607 D,ZENER MTZJ5.6B K06005R644520S
ZD115 00D2760762958 D,ZENER MTZJ39B K06039R044520S
ZD116 00D2760762958 D,ZENER MTZJ39B
1611E2,1611E1C,1621E1C,
591AE
K06039R044520S
ZD117,118 963202010440S D,ZENER MTZJ22B K06022R044520S
ZD119 00D2760762958 D,ZENER MTZJ39B
1611E2,1611E1C,1621E1C,
591AE
K06039R044520S
DZ1 00D9600095801 D,ZENER MTZJ6.8B K06006R844520S
TR100-102 00D9630255802 TR 2SC KTC3199Y J5023199Y0010S
RESISTORS GROUP
R5-14 963125010100S R,METAL FILM 10-J 2W C060010066050S
R16-18 963125010100S R,METAL FILM 10-J 2W 1611E3 C060010066050S

Denon AVR-1611 Specifications

General

Impedance	6 Ω
Frequency range	10 - 100000 Hz
Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	98 dB
Total Harmonic Distortion (THD)	0.7 %
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Radio Data System (RDS)	Yes
Audio system	Dolby TrueHD, Dolby Digital Plus, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, DTS-HD, DTS 96/24
Output power	110 W
Dimensions (WxDxH)	434 x 381 x 171 mm
Power requirements	AC 230, 50 Hz
HDMI ports quantity	5
I/O ports	1 x Component 3 x Composite (Video) 5 x Analogue Audio (Tuner included) 1 x Composite Monitor 1 x Microphone Port 1 x Dock Control Port 1 x FM Tuner Antenna 1 x AM Tuner Antenna
Connectivity technology	Wired
Digital audio optical in	1
Product color	Black
Power consumption (standby)	0.1 W
Power consumption (typical)	360 W

Weight and Dimensions

Weight	9200 g
