Denon AVR-1611 Service Manual

128
Ref. No. Part No. Part Name Remarks Q'ty New
R28-33 00D9630310404 R,METAL FILM 2.2K-J,1W C060022265050S
R34 nsp R,METAL FILM 10K-J,1/4W C060103063050S
R35,36 nsp R,METAL FILM 47K-J,1/4W C060047363050S
R37,38 963125010110S R,METAL FILM 470-J,2W C060047166060S
CAPACITORS GROUP
C1 nsp C,FILM MI-0.047UF-J/50V D020473167050S
C2 nsp C,CERAMIC 2200PF-K/50V D011222777160S
C3,4 nsp C,FILM MI-0.047UF-J/50V D020473167050S
C5 nsp C,CERAMIC 2200PF-K/50V D011222777160S
C6 nsp C,FILM MI-0.047UF-J/50V D020473167050S
C7 nsp C,CERAMIC 2200PF-K/50V D011222777160S
C8,9 nsp C,FILM MI-0.047UF-J/50V D020473167050S
C10 nsp C,CERAMIC 2200PF-K/50V D011222777160S
C11,12 nsp C,FILM MI-0.047UF-J/50V D020473167050S
C13 nsp C,CERAMIC 2200PF-K/50V D011222777160S
C14 nsp C,FILM MI-0.047UF-J/50V D020473167050S
C15 nsp C,CERAMIC 2200PF-K/50V 1611E3 D011222777160S
C16 nsp C,FILM MI-0.047UF-J/50V 1611E3 D020473167050S
C17 nsp C,FILM MI-0.047UF-J/50V D020473167050S
C18 nsp C,CERAMIC 2200PF-K/50V 1611E3 D011222777160S
C19,22,25 nsp C,FILM MI-0.047UF-J/50V 1611E3 D020473167050S
C27 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C30 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C33 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C36 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C39 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C42,45 nsp C,CERAMIC 1000PF-K/50V 1611E3 D011102777160S
C53 00D9609009937 C,ELECT 100UF-M/50V D040101087060S
C54 nsp C,FILM 0.1UF-K/250V D02010407H080S
C55 963134004220S C,ELECT 6800UF-M/75V
1611E2,1611E1C,1621E1C,
591E3,591EA
D04068208A000S
C55 963134011440S C,ELECT 10000UF-M/71V 1611E3 D040103089000S *
C57 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C58 963134004220S C,ELECT 6800UF-M/75V
1611E2,1611E1C,1621E1C,
591E3,591EA
D04068208A000S
C58 963134011440S C,ELECT 10000UF-M/71V 1611E3 D040103089000S *
C60 00D9630244606 C,ELECT 0.1UF-M/50V (Pb Free) D040R10087080S
C61 nsp C,FILM 0.1UF-K/250V D02010407H080S
C63 nsp C,CERAMIC 1000PF-K/50V D011102777160S
z
C100 963132010140S C,CERAMIC ECQU2A104ML 0.1UF D00810408H000S
C102 963134010530S C,ELECT 100UF-M/400V D04110108K010S
C103 963132010120S C,CERAMIC DEHR33A102KB2B D00810207Q010S
z
C104,105 963134011730S C,CERAMIC DE1B3KX471KB4BL01 AC250V D00847127H010S
C106-108 963134010220S C,ELECT5600UF-M/6.3V D041562081001S
C110 nsp C,CERAMIC 0.1UF-K/25V D011104774161S
C111 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C112 963134010190S C,ELECT 10UF-M/50V D041100087050S
C113 nsp C,CERAMIC 0.1UF-K/25V D011104774161S
C115 963132011930S C,CERAMIC DE1E3KX222MB4BL01 AC250V D00822248H010S
C116 nsp C,CERAMIC 0.1UF-K/25V D011104774161S

Denon AVR-1611 Specifications

General

Impedance	6 Ω
Frequency range	10 - 100000 Hz
Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	98 dB
Total Harmonic Distortion (THD)	0.7 %
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Radio Data System (RDS)	Yes
Audio system	Dolby TrueHD, Dolby Digital Plus, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, DTS-HD, DTS 96/24
Output power	110 W
Dimensions (WxDxH)	434 x 381 x 171 mm
Power requirements	AC 230, 50 Hz
HDMI ports quantity	5
I/O ports	1 x Component 3 x Composite (Video) 5 x Analogue Audio (Tuner included) 1 x Composite Monitor 1 x Microphone Port 1 x Dock Control Port 1 x FM Tuner Antenna 1 x AM Tuner Antenna
Connectivity technology	Wired
Digital audio optical in	1
Product color	Black
Power consumption (standby)	0.1 W
Power consumption (typical)	360 W

Weight and Dimensions

Weight	9200 g
