Denon AVR-1611 Service Manual

129
Ref. No. Part No. Part Name Remarks Q'ty New
z
C117 963132011940S
C,CERAMIC DE2F3KY103MB3BM02
AC250V
D008103589010S
C118 nsp C,CERAMIC 0.1UF-K/25V D011104774161S
C119 963134010210S C,ELECT 47UF-M/25V D041470084050S
C120-123 nsp C,CERAMIC 0.1UF-K/25V D011104774161S
z
C131, 133 963132011940S
C,CERAMIC DE2F3KY103MB3BM02 AC250V D008103589010S
OTHERS PARTS GROUP
BKT1-3 nsp BRACKET t1.0+Sn plating /PCB MTG 4010214876000S
BKT100 nsp BRACKET 0.8t/SCREW 4010210196100S
BKT101 nsp BRACKET SCREW 4010210196000S
CLAMP3 nsp CLAMP WIRE(SOLDER) 4330000120000S
CN1 nsp CN,WIRE 230MM/5P L000231052050S
CN2 nsp CN,WIRE 670MM/2P 1611E3 L000671020050S
CN3 nsp CN,WIRE 2MM 170MM/10P L002171102620S
CP1 nsp CN.WAFER 3CKT L108353280360S
CP12 CN.FPC 1.25MM 19P L131019100010S
CP22 nsp CN.WAFER 5P L101100040510S
CX100 nsp CN.WAFER 7.92MM
1611E3, 1611E1C, 1621E1C,
591E3
L108202000220S
CX102 nsp CN.WAFER 7.92MM L108353280290S
CX104 nsp CN.WAFER 5P L101100030510S
CX105 nsp CN,WIRE 370MM/5P L000371050010S
z
F100 963652010510S FUSE T2A/250V 1611E3,591E3 N751502001160S *
z
F100 963652010500S FUSE T1.6A/250V
1611E2,1611E1C,1621E1C,
591EA
N751501601160S
z
F101 963652010540S FUSE T5A/250V N751505001160S *
z
F101 963652010910S FUSE T3.15A/250V
1611E2, 1611E1C, 1621E1C,
591EA
N751503151160S
JACK1 963643010360S 6P JB-602A-02 G613602A0200YS
JACK2 00D9630257208 4P JB-405E(V0)-02
1611E2,1611E1C,1621E1C,
591E3,591EA
G612405E0200YS
JACK2 963646001690S 8P JB-405E(V0)-02 1611E3 G614108V1010MS
z
JK100 963641011240S SOCKET,POWER AC 1611E2,591EA G4300152P0001S
L1-5 nsp COIL INDUCTOR 0.5UH D330R50000000S
L6,7 nsp COIL INDUCTOR 0.5UH 1611E3 D330R50000000S
z
L100 963111010230S COIL LINE FILTER LF-4ZB-E273H 27mH D320402730020S
z
RL101 963682010370S RELAY HL31-1AT-5H 5V 1A G680050102020S *
RLY1 00D9630218409 RELAY BC3-12 24V 2A G680240202030S
RLY2-4 963682002440S RELAY 12V 5A SPK G680120502050S
RLY5 963682002440S RELAY 12V 5A SPK 1611E3 G680120502050S
z
T100 963102010240S TRANS,SWITCHING ST-4430A E060044300010S *

Denon AVR-1611 Specifications

General

Impedance	6 Ω
Frequency range	10 - 100000 Hz
Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	98 dB
Total Harmonic Distortion (THD)	0.7 %
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Radio Data System (RDS)	Yes
Audio system	Dolby TrueHD, Dolby Digital Plus, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, DTS-HD, DTS 96/24
Output power	110 W
Dimensions (WxDxH)	434 x 381 x 171 mm
Power requirements	AC 230, 50 Hz
HDMI ports quantity	5
I/O ports	1 x Component 3 x Composite (Video) 5 x Analogue Audio (Tuner included) 1 x Composite Monitor 1 x Microphone Port 1 x Dock Control Port 1 x FM Tuner Antenna 1 x AM Tuner Antenna
Connectivity technology	Wired
Digital audio optical in	1
Product color	Black
Power consumption (standby)	0.1 W
Power consumption (typical)	360 W

Weight and Dimensions

Weight	9200 g
