Denon AVR-1611 Service Manual

120
Ref. No. Part No. Part Name Remarks Q'ty New
R450 963252004160S POSISTOR 18BC471QB5RB F320184710050S
R451 nsp R,FIXED 1WJ-5.6K N113135656220S
R458 963125012630S R,METAL FILM 22-J,1W FLAMERETARDANT C060022065050S
R467,468 00D9630345903 R,FIXED 2WJ-0.47 FLAMERETARDANT N113136647820S
R474,475 00D9630345903 R,FIXED 2WJ-0.47 FLAMERETARDANT N113136647820S
R478 nsp R,METAL FILM 3.3K-J,1W C060033265050S
R483 963125012630S R,METAL FILM 22-J,1W FLAMERETARDANT C060022065050S
R485 nsp R,METAL FILM 1.2K-J,1W C060012265050S
R487 nsp R,METAL FILM 47-J,1W C060047065060S
R489 nsp R,FIXED 1WJ-5.6K N113135656220S
R493 00D9630337908 R,METAL 33-J,1W FLAMERETARDANT C060033065050S
R494 963252004160S POSISTOR 18BC471QB5RB F320184710050S
R495 nsp R,FIXED 1WJ-5.6K N113135656220S
R502 963125012630S R,METAL FILM 22-J,1W FLAMERETARDANT C060022065050S
R511,512 00D9630345903 R,FIXED 2WJ-0.47 FLAMERETARDANT N113136647820S
R517,518 00D9630345903 R,FIXED 2WJ-0.47 FLAMERETARDANT N113136647820S
R521 nsp R,METAL FILM 3.3K-J,1W C060033265050S
R526 963125012630S R,METAL FILM 22-J,1W FLAMERETARDANT C060022065050S
R528 nsp R,METAL FILM 1.2K-J,1W C060012265050S
R530 nsp R,METAL FILM 47-J,1W C060047065060S
R534 nsp R,FIXED 1WJ-5.6K N113135656220S
R537 963252004160S POSISTOR 18BC471QB5RB F320184710050S
R538 nsp R,FIXED 1WJ-5.6K N113135656220S
R545 963125012630S R,METAL FILM 22-J,1W FLAMERETARDANT C060022065050S
R551 00D9639005639 R,METAL FILM 100-J,1W FLAMERETARDANT C060010165060S
R554,555 00D9630345903 R,FIXED 2WJ-0.47 FLAMERETARDANT N113136647820S
R561,562 00D9630345903 R,FIXED 2WJ-0.47 FLAMERETARDANT N113136647820S
R564 nsp R,METAL FILM 3.3K-J,1W C060033265050S
R569 963125012630S R,METAL FILM 22-J,1W FLAMERETARDANT C060022065050S
R571 nsp R,METAL FILM 1.2K-J,1W C060012265050S
R573 nsp R,METAL FILM 47-J,1W C060047065060S
R577 nsp R,FIXED 1WJ-5.6K N113135656220S
R580 963252004160S POSISTOR 18BC471QB5RB F320184710050S
R581 nsp R,FIXED 1WJ-5.6K N113135656220S
R588 963125012630S R,METAL FILM 22-J,1W FLAMERETARDANT C060022065050S
R597,598 00D9630345903 R,FIXED 2WJ-0.47 FLAMERETARDANT N113136647820S
R603,604 00D9630345903 R,FIXED 2WJ-0.47 FLAMERETARDANT N113136647820S
R607 nsp R,METAL FILM 3.3K-J,1W C060033265050S
R612 963125012630S R,METAL FILM 22-J,1W FLAMERETARDANT C060022065050S
R614 nsp R,METAL FILM 1.2K-J,1W C060012265050S
R616 nsp R,METAL FILM 47-J,1W C060047065060S
R620 nsp R,FIXED 1WJ-5.6K N113135656220S
R623 963252004160S POSISTOR 18BC471QB5RB F320184710050S
R624 nsp R,FIXED 1WJ-5.6K N113135656220S
R631 963125012630S R,METAL FILM 22-J,1W FLAMERETARDANT C060022065050S
R640,641 00D9630345903 R,FIXED 2WJ-0.47 FLAMERETARDANT N113136647820S
R646,647 00D9630345903 R,FIXED 2WJ-0.47 FLAMERETARDANT N113136647820S
R650 nsp R,METAL FILM 3.3K-J,1W C060033265050S
R655 963125012630S R,METAL FILM 22-J,1W FLAMERETARDANT C060022065050S
R657 nsp R,METAL FILM 1.2K-J,1W C060012265050S
R659 nsp R,METAL FILM 47-J,1W C060047065060S
R663 nsp R,FIXED 1WJ-5.6K N113135656220S
R666 963252004160S POSISTOR 18BC471QB5RB F320184710050S

Denon AVR-1611 Specifications

General

Impedance	6 Ω
Frequency range	10 - 100000 Hz
Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	98 dB
Total Harmonic Distortion (THD)	0.7 %
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Radio Data System (RDS)	Yes
Audio system	Dolby TrueHD, Dolby Digital Plus, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, DTS-HD, DTS 96/24
Output power	110 W
Dimensions (WxDxH)	434 x 381 x 171 mm
Power requirements	AC 230, 50 Hz
HDMI ports quantity	5
I/O ports	1 x Component 3 x Composite (Video) 5 x Analogue Audio (Tuner included) 1 x Composite Monitor 1 x Microphone Port 1 x Dock Control Port 1 x FM Tuner Antenna 1 x AM Tuner Antenna
Connectivity technology	Wired
Digital audio optical in	1
Product color	Black
Power consumption (standby)	0.1 W
Power consumption (typical)	360 W

Weight and Dimensions

Weight	9200 g
