Denon AVR-1611 Service Manual

132
Ref. No. Part No. Part Name Remarks Q'ty New
CN13 nsp CN,WIRE 2MM 120MM/13P L002121130010S *
CN15 nsp CN,WIRE 2MM 120MM/4P L002121040110S *
CN100 nsp CN,WAFER 13P L109012521310S *
CN101 nsp CN,WAFER 11P L109012521110S *
CN102 nsp CN,WAFER 17P L109012521710S *
CN103 nsp CN,WAFER 19P L109012521910S *
CN104 nsp CN,WAFER 27P L109012522710S *
CN105 nsp CN,WAFER 17P L109012521710S *
CP3 nsp CN,WAFER 11P L109012511110S *
CP4 nsp CN,WAFER 25P L109012512510S *
CP13A nsp CN.WAFER 13P L101200101320S
CP14 nsp CN.WAFER 4P L101200100420S
CP100 nsp CN,WAFER 13P L109012511310S *
CP101 nsp CN,WAFER 11P L109012511110S *
CP102 nsp CN.WAFER 4P L102526700400S
CP104 nsp CN.WAFER 3P L102526700300S
CP105 nsp CN,WAFER 19P L109012511910S *
CP106 nsp CN,WAFER 17P L109012511710S *
CP108 nsp CN,WAFER 19P L109012511910S *
CP109 nsp CN,WAFER 17P L109012511710S *
CP110 nsp CN.WAFER33P L109012513310S *
z
F104 963652010500S FUSE T1.6A/250V
1611E2,1611E1C,1621E1C,
591EA
N751501601160S *
z
F105-108 963652010500S FUSE T1.6A/250V N751501601160S *
F104A, 104B nsp HOLDER,FUSE CLIP G645000050010S
F105A-108A nsp HOLDER,FUSE CLIP G645000050010S
F105B-108B nsp HOLDER,FUSE CLIP G645000050010S
nsp BRACKET SCREW 4010210196000S

Denon AVR-1611 Specifications

General

Impedance	6 Ω
Frequency range	10 - 100000 Hz
Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	98 dB
Total Harmonic Distortion (THD)	0.7 %
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Radio Data System (RDS)	Yes
Audio system	Dolby TrueHD, Dolby Digital Plus, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, DTS-HD, DTS 96/24
Output power	110 W
Dimensions (WxDxH)	434 x 381 x 171 mm
Power requirements	AC 230, 50 Hz
HDMI ports quantity	5
I/O ports	1 x Component 3 x Composite (Video) 5 x Analogue Audio (Tuner included) 1 x Composite Monitor 1 x Microphone Port 1 x Dock Control Port 1 x FM Tuner Antenna 1 x AM Tuner Antenna
Connectivity technology	Wired
Digital audio optical in	1
Product color	Black
Power consumption (standby)	0.1 W
Power consumption (typical)	360 W

Weight and Dimensions

Weight	9200 g
