Denon AVR-1611 Service Manual

29
Surround mode NOTE
Input signal types and formats
ANALOG
PCM DTS-HD DTS DOLBY DOLBY DIGITAL
LINEAR PCM
(multi ch)
LINEAR PCM
(2ch)
DTS-HD
Master
Audio
DTS-HD
High
Resolution
Audio
DTS
EXPRESS
DTS ES
DSCRT
(With Flag)
DTS ES
MTRX
(With Flag)
DTS
(5.1ch)
DTS 96/24
DOLBY
TrueHD
DOLBY
DIGITAL Plus
DOLBY
DIGITAL EX
(With Flag)
DOLBY
DIGITAL EX
(With no
Flag)
DOLBY
DIGITAL
(5.1/5/4ch)
DOLBY
DIGITAL
(4/3ch)
DOLBY
DIGITAL
(2ch)
MULTI CH IN
MULTI CH IN
F
MULTI CH IN + PLgx CINEMA z2z3 S MULTI CH IN + PLgx MUSIC z1z3 S MULTI CH IN + PLgz z4 S MULTI CH IN + Dolby EX
z1z3 S
MULTI CH IN 7.1
z3 F D (7.1)
DIRECT
DIRECT
SS SSSSSSSSSSSSSSS
DSP SIMULATION
MULTI CH STEREO
SS S SSSS SSSSS
ROCK ARENA
SS S SSSS SSSSS
JAZZ CLUB
SS S SSSS SSSSS
MONO MOVIE
SS S SSSS SSSSS
VIDEO GAME
SS S SSSS SSSSS
MATRIX
SS S SSSS SSSSS
VIRTUAL
SS S SSSS SSSSS
STEREO
STEREO
F
S FSSSSSSSSSSSSSS
z1 If “Speaker Config.“ – “S.Back“ is set to “None”, this surround mode cannot be selected. z2 If “Speaker Config.“ – “S.Back“ is set to “1sp” or “None”, this surround mode cannot be selected. z3 This surround mode can be selected when “Pre Assign” is set to “Normal”. z4 If “Speaker Config.“ – “Front Height“ is set to “None”, this surround mode cannot be selected.

Denon AVR-1611 Specifications

General

Impedance	6 Ω
Frequency range	10 - 100000 Hz
Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	98 dB
Total Harmonic Distortion (THD)	0.7 %
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Radio Data System (RDS)	Yes
Audio system	Dolby TrueHD, Dolby Digital Plus, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, DTS-HD, DTS 96/24
Output power	110 W
Dimensions (WxDxH)	434 x 381 x 171 mm
Power requirements	AC 230, 50 Hz
HDMI ports quantity	5
I/O ports	1 x Component 3 x Composite (Video) 5 x Analogue Audio (Tuner included) 1 x Composite Monitor 1 x Microphone Port 1 x Dock Control Port 1 x FM Tuner Antenna 1 x AM Tuner Antenna
Connectivity technology	Wired
Digital audio optical in	1
Product color	Black
Power consumption (standby)	0.1 W
Power consumption (typical)	360 W

Weight and Dimensions

Weight	9200 g
