Denon AVR-1611 Service Manual

Ref. No. Part No. Part Name Remarks Q'ty New
18-1 963411001410D BUTTON 3KEY B BK 5097213611000S 1
18-1 963411011340D BUTTON 3KEY B SP 5097213611100S 1 *
18-2 963411001400D BUTTON 3KEY A 591BKE3,591BKEA 5097213601000S 1
19 00D9630365002 BUTTON WIN 3KEY BK 5097213371000S 2
19 00D9630365301 BUTTON WIN 3KEY SP 5097213371110S 2
20 963411003400D BUTTON WIN 3KEY C BK 5097213831000S 1
20 963411003690D BUTTON WIN 3KEY C SP 5097213831100S 1
★
27 nsp SHEET RATING CHASSIS 1210211269000S 1 *
28 nsp HEAT SINK MAIN 1611BKE3 2120211788000S 1 *
28 nsp HEAT SINK MAIN
1611SPE2,1611BKE2,1611SPE1C,
1621SPE1C,591BKE3,591BKEA
2120211778000S 1 *
32 nsp BRACKET H SINK 4010056906010S 5
40 nsp CUSHION FOOT 4050211295000S 4
41 963407003330D FOOT 4000210261000S 4
42 nsp CHASSIS MAIN 3200213506000S 1 *
43 nsp SUPPORTER PCB 4070001601010S 3
44 nsp BRACKET SIDE 4010210686000S 1
45 nsp SUPPORTER P.C. 4070210192000S 1
z
46 963101009890S POWER TRANS MAIN 1611BKE3,591BKE3 8200858690350S 1 *
z
46 963101009900S POWER TRANS MAIN 1611SPE2,1611BKE2,591BKEA 8200858690360S 1 *
z
46 963101009910S POWER TRANS MAIN 1611SPE1C,1621SPE1C 8200858690370S 1 *
59 nsp SPACER CARD 4300210062000S 1
60 nsp BRACKET SMPS 4010214886000S 1 *
61 nsp PLATE EARTH USB 4470211946100S 1 *
★
63 00D9960018706 TR 2SB1560-Y
Q410,Q422,Q434,Q446,Q458,Q470,Q482
: for 7CH AMP
J5011560Y0000S 7
★
63 00D9960018706 TR 2SB1560-Y
Q410,Q422,Q434,Q446,Q458 :
for 5CH AMP
J5011560Y0000S 5
★
64 963219003340S TR 2SC KTC3964
Q409,Q421,Q433,Q445,Q457,Q469,Q481
: for 7CH AMP
J502396400010S 7
★
64 963219003340S TR 2SC KTC3964
Q409,Q421,Q433,Q445,Q457
: for 5CH AMP
J502396400010S 5
★
65 00D9960018706 TR 2SD2390-Y
Q404,Q416,Q428,Q440,Q452,Q464,Q476
: for 7CH AMP
J5032390Y0000S 7
★
65 00D9960018706 TR 2SD2390-Y
Q404,Q416,Q428,Q440,Q452
: for 5CH AMP
J5032390Y0000S 5
70 nsp CHASSIS BACK 1611BKE3 3207213526000S 1 *
70 nsp CHASSIS BACK 1611SPE2,1611BKE2 3207213526100S 1 *
70 nsp CHASSIS BACK 591BKEA 3207213526110S 1 *
70 nsp CHASSIS BACK 1611SPE1C 3207213526200S 1 *
70 nsp CHASSIS BACK 1621SPE1C 3207213526220S 1 *
70 nsp CHASSIS BACK 591BKE3 3207213526300S 1 *
72 nsp STOPPER CORD AC
1611BKE3,1611SPE1C,1621SPE1C,
591BKE3
4380210002000S 1
z
73 00D9630292205 CORD ASSY 1611BKE3,591BKE3 L068125100020S 1
z
73 00D9630349909 CORD ASSY 1611SPE1C,1621SPE1C L068250060010S 1
76 963401010050D CABINET TOP BK 3000211736000S 1 *
76 963403011330D CABINET TOP SP 3000211736100S 1 *
77 963454001800D COVER HOLDER 1611BKE2,591BKEA 4310213701000S 6
77 963454001810D COVER HOLDER 1611SPE2,1611SPE1C,1621SPE1C 4310213701100S 6
78 963419011370D COVER SAFETY 1611BKE2,591BKEA 4310215202100S 1 *
78 963419011360D COVER SAFETY 1611SPE2,1611SPE1C,1621SPE1C 4310215202000S 1 *
82 nsp CUSHION SCREW 4050213025000S 4 *
83 nsp CUSHION 4050213155000S 1 *
★
88 963606010490S CABLE,FLAT CARD 1.0MM N711402912480S 1 *
★
89 nsp CLAMP CABLE 1611BKE3 4330040343010S 9
Ref. No. Part No. Part Name Remarks Q'ty New
★
89 nsp CLAMP CABLE 591BKE3 4330040343010S 6
★
89 nsp CLAMP CABLE
1611SPE2,1611BKE2,1611SPE1C,
1621SPE1C,591BKEA
4330040343010S 5
★
90 nsp TAPE INLET 1611SPE2,1611BKE2,591BKEA 1220210759000S 1
SCREWS
A nsp SCREW +2S 3*8 B-TYPE ZNW/BH B020030081B10S 21
C nsp SCREW +2S 3*15 B-TYPE ZNW/BH B020030151B10S 1
D nsp SCREW, +2S 3*10 B-TYPE(DOT) BK/BH 1611BKE3 B020030103B11S 24
D nsp SCREW, +2S 3*10 B-TYPE(DOT) BK/BH 1611SPE1C,1621SPE1C,591BKE3 B020030103B11S 23
D nsp SCREW, +2S 3*10 B-TYPE(DOT) BK/BH 1611SPE2,1611BKE2,591BKEA B020030103B11S 22
E nsp
SCREW +2S 3*14 P(Φ6)+S-WASHER
ZNY/HH
1611BKE3 B018230141H11S 21
E nsp
SCREW +2S 3*14 P(Φ6)+S-WASHER
ZNY/HH
1611SPE2,1611BKE2,1611SPE1C,
1621SPE1C,591BKE3,591BKEA
B018230141H11S 15
F nsp SCREW +2S 3*17 B-TYPE ZNW/BH B020030171B10S 3
G 00D9630048307 SCREW +2S 4*8 B-TYPE(DOT) BK/BH
1611SPE2,1611BKE2,591BKEA :
for INLET
1500040083B10S 2
G 00D9630048307 SCREW +2S 4*8 B-TYPE(DOT) BK/BH BK : for CABINET TOP 1500040083B10S 6
G 00D9639004012 SCREW +2S 4*8 B-TYPE(DOT) NI/BH SP : for CABINET TOP 1500040084B10S 6
H nsp
SCREW +3S 4*10 P+S-WASHER(ROUND)
BK/BH
B028940101B11S 4
I nsp SCREW +2S 3*8 ZnY WASHER PI12 1500001456010S 1
P nsp SCREW +2S 3*8 PI9.5 B-TYPE ZNW 1500001206010S 2
Q nsp SCREW +M 3*6 BK/BH B000030063B10S 5
T nsp SCREW +2S 3*8(ROUND) BK/BH B020230083B10S 47
93

Denon AVR-1611 Specifications

General

Impedance	6 Ω
Frequency range	10 - 100000 Hz
Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	98 dB
Total Harmonic Distortion (THD)	0.7 %
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Radio Data System (RDS)	Yes
Audio system	Dolby TrueHD, Dolby Digital Plus, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, DTS-HD, DTS 96/24
Output power	110 W
Dimensions (WxDxH)	434 x 381 x 171 mm
Power requirements	AC 230, 50 Hz
HDMI ports quantity	5
I/O ports	1 x Component 3 x Composite (Video) 5 x Analogue Audio (Tuner included) 1 x Composite Monitor 1 x Microphone Port 1 x Dock Control Port 1 x FM Tuner Antenna 1 x AM Tuner Antenna
Connectivity technology	Wired
Digital audio optical in	1
Product color	Black
Power consumption (standby)	0.1 W
Power consumption (typical)	360 W

Weight and Dimensions

Weight	9200 g
