Denon AVR-2313CI Service Manual

102
Checking the set (AVR-2313):(if no sound is output from ZONE2)
YES
Check "
4.1 AUDIO CHECK
" Procedure.(Refer to 97 page.)
Are signals input to U2401 pin 12, pin 13, pin 14 and pin 15?
The U2602 and surrounding circuitry are
defective.
NO
YES
Are audio signals output from U2401 pin 7 and pin 6?
The U2401 and surrounding circuitry are
defective.
NO

Denon AVR-2313CI Specifications

General

Receiver type	-
Audio output channels	7.1 channels
Power output per channel (1KHz@6 Ohm)	135 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	8
Audio (L/R) in	6
Composite video in	4
Ethernet LAN (RJ-45) ports	1
Component video (YPbPr/YCbCr) in	2
12V trigger	Yes
FM band range	87.5 - 107.9 MHz
Supported radio bands	FM
Internet radio services supported	Pandora, SIRIUS Internet Radio, Spotify, vTuner
Card reader integrated	No
Product color	Black
Audio decoders	Dolby Digital Plus, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Digital Surround, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-HD, DTS-HD Master Audio
Volume control	Rotary

Weight and Dimensions

Depth	378.9 mm
Width	434.3 mm
Height	166.8 mm
Weight	10899 g
