161
PARTS LIST OF EXPLODED VIEW
z
Parts indicated by "nsp" on this table cannot be supplied.
z
PCB ASS'Y indicated by "nsp" on this table cannot be supplied. When repairing the PCB ASS'Y, check the board parts list and order replacement parts.
z
Parts indicated by the "
★
" mark are not illustrated in the exploded view.
z
The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions.
NOTE: The symbols in the column "Remarks" indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model E1C : China model
BK : Black model SP : Premium Silver model NOT FIXED : Update will be next version
Ref. No. Part No. Part Name Remarks Q'ty New
P8 nsp 7CH_AMP PCB ASSY E3 7025HK1113010 1 *
P8 nsp 7CH_AMP PCB ASSY E2 7025HK1113020 1 *
P8 nsp 7CH_AMP PCB ASSY E1C 7025HK1113030 1 *
P18A nsp SPK PCB ASSY E3 7025HK1113011 1 *
P18A nsp SPK PCB ASSY E2 7025HK1113021 1 *
P18A nsp SPK PCB ASSY E1C 7025HK1113031 1 *
P18 - PCB SMPS -
P19 - PCB SPK -
P12A nsp REG_CNT PCB ASSY E3 7025HK1113012 1 *
P12A nsp REG_CNT PCB ASSY E2 7025HK1113022 1 *
P12A nsp REG_CNT PCB ASSY E1C 7025HK1113032 1 *
P11 - PCB REG -
P12 - PCB REG_CNT -
P14 - PCB SIDE _CNT -
P15 - PCB RS232 -
P17 - PCB RC5_MXPORT -
P20 - PCB FRONT_CNT -
P3A nsp FRONT PCB ASSY E3 7025HK1113013 1
P3A nsp FRONT PCB ASSY E2 7025HK1113023 1
P3A nsp FRONT PCB ASSY E1C 7025HK1113033 1
P2 - PCB USB -
P3 - FRONT PCB ASSY -
P4 - PCB FUNCTION -
P5 - PCB CNT -
P6 - PCB FRONT HDMI_GUIDE -
P7 - PCB GUIDE_R -
P9 - PCB TOP_GUIDE -
P10 - PCB GUIDE_L -
P13 nsp AUDIO PCB ASSY E3 7025HK1113014 1 *
P13 nsp AUDIO PCB ASSY E2 7025HK1113024 1 *
P13 nsp AUDIO PCB ASSY E1C 7025HK1113034 1 *
P21A nsp VPT PCB ASSY E3 7025HK1113015 1 *
P21A nsp VPT PCB ASSY E2 7025HK1113025 1 *
P21A nsp VPT PCB ASSY E1C 7025HK1113035 1 *
P21 - PCB PREOUT -
P22 - PCB VIDEO -
To Next Page
