24
1. µcom/DSP Version display mode
1.1. Operation specications
µcom/DSP version display mode:
When the set is started up in this mode, the version information is displayed.
Starting up:
Press the "Power operation (
X
)" button to turn on the power while pressing the "STATUS" and "DIMMER" buttons.
Now, press the "STATUS" button to the display the 2nd item information on the FL Display.
b
When the version is displayed on the FL Display, the version list is also displayed on the GUI.
1.2. Display Order
Error information(Refer to
1.3. Error display
) →
q
Model destination information →
w
Serial Number
→
e
Firmware Package Version →
r
Main µ-com →
t
Main 1st Boot Loader →
y
DSP ROM →
u
Audio PLD
→
i
GUI SFLASH → *
o
Ethernet(DM860A) 1st Boot Loader, Hardware ID
→ *
Q0
Ethernet(DM860A) 2nd Boot Loader → *
Q1
Ethernet(DM860A) IMAGE
→ *
Q2
Ethernet(DM860A)MAC ADDRESS information
q
Model destination information :
Model FLD
AVR-2313CI E3 model
A V R 2 3 1 3 E 3
AVR-2313 E2 model
A V R 2 3 1 3 E 2
AVR-2313 E1C model
A V R 2 3 1 3 E 1 C
w
Serial Number :
FLD
S / N . * * * * * * * * * *
e
Firmware Package Version :
FLD
P a c k a g e : * * * *
r
Main µ-com :
FLD
M a i n : * * * * * * * *
t
Main 1st Boot Loader :
FLD
M a i n F B L : * * . * *
y
DSP ROM :
FLD
D S P : * * . * *
u
Audio PLD :
FLD
A u d i o P L D : * * . * *
i
GUI SFLASH :
Model FLD
AVR-2313CI E3 model
G U I : 5 9 1 1 * * * *
AVR-2313 E2 model
G U I : 5 9 1 2 * * * *
AVR-2313 E1C model
G U I : 5 9 1 5 * * * *
To Next Page
