1.3. Error display
See the following table for each "Error information" display and its explanation (status).
Display order is
q
,
w
,
e
,
r
,
t
.
Condition Status FL Display Trouble shooting
q
Firm Check
NG
Compared with the destination setting
on the board. This is displayed when the
model name or destination information
written into the rmware does not match.
(
b
)
F I R M E R R O R
• Please check the
destination-resistors
(
R3017/R3018, HDMI
PCB).
• Please write the
rmware of correct
destination.
w
DIR NG
No response from DIR.
D I R E R R O R 0 1
• Please check DIR
（
U2205, HDMI PCB)
and around circuits.
e
DSP NG
When DSP code boot is performed, the
DSP FLAG0 port does not change to "H"
even if DSP reset is executed.
D S P E R R O R 0 1
• Please check DSP
（
U2001, HDMI PCB)
and around circuits.
Before DSP command is issued, the DSP
BUSY port does not change to "L".
D S P E R R O R 0 2
When DSP data read is performed,
executing WRITE="L" does not result in
ACK="H".
D S P E R R O R 0 3
When DSP data read is performed,
executing REQ="L" does not result in
ACK="L".
D S P E R R O R 0 4
When DSP data writing is performed,
executing WRITE="H" does not result in
ACK="H".
D S P E R R O R 0 5
When DSP data writing is performed,
executing REQ="L" does not result in
ACK="L".
D S P E R R O R 0 6
r
IP SCALER
NG
An error occurred in testing writing data
between IP SCALER and DDR.
I P S C A L E R E R R 0 1
• Please check IP
SCALER (U1601,
HDMI PCB) and
around circuits.
Testing writing data between IP SCALER
and DDR resulted in no response.
I P S C A L E R E R R 0 2
t
EEPROM NG
Error occurs in EEPROM checksum.(*** is
a block address number.)
E 2 P R O M E R R * * *
Status FL Display
b
The written Firmware and product settings
(model name, brand name, destination)
are compared. If Firmware that is not
designed for this product is written, ▲
or ▼ is displayed in the rst column, as
shown on the right.
–
M a i n : * * * * * * * *
–
D S P : * * . * *
–
A u d i o P L D : * * . * *
–
G U I : * * * * * * * *
•
G U I : * * * * * * * *
To Next Page
