Denon AVR-2313CI

18
8. PCB PREOUT
(1) Remove the screws, then disconnect the connector wires
→
PCB SMPS ASSY PCB VIDEO
→
PCB AUDIO
→
PCB MX PORT/PCB RS232C
→
PCB HDMI
→
→
PCB PREOUT
TOP COVER
BACK CHASSIS
→
Proceeding :
CP4618
PCB SIDE CNT
CP4002
