Denon AVR-2313CI Service Manual

84
2. Analog video
Perform the operation below beforehand.
b
Check that the connection cable and the Monitor are normal.
b
Set VIDEO CONVERSION ON.
b
Set COMPONENT signal to 480i.
b
Set Function to the following.
V : SAT
COMPONENT : SAT
MONITOR OUT (CVBS/Cmponent/HDMI) output NG
Input
CVBS
To A
Input
COMPONENT
