Denon AVR-2313CI Service Manual

WIRING DIAGRAM
4P WIRE
10P WIRE
5P WIRE
(S5,S6)
5P WIRE(SPK OUT F/C/S)
23P FFC CARD CABLE
13P WIRE
(S2,S4)
TUNER PACK
5P SHIELD WIRE
10P WIRE(+/-B, GND)
JUMPER
7CH AMP B'D
DIG +5V
SELECT B'D
HP B'D
SPK B'D
FRONT B'D
USB B'D
JUMPER
AUDIO IN B'D
VIDEO B'D
DIGITAL POWER B'D
AC CORD
CHASSIS
2P WIRE(SPK OUT SB)
(S1)
HDMI B'D
F_CNT B'D
HDMI B'D
S_CNT B'D
13P WIRE(RELAY CONT)
REG B'D
REG_CNT B'D
40P FFC CARD CABLE
MAIN TRANS
VOL ENCODER
PREOUT B'D
159

Denon AVR-2313CI Specifications

General

Receiver type	-
Audio output channels	7.1 channels
Power output per channel (1KHz@6 Ohm)	135 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	8
Audio (L/R) in	6
Composite video in	4
Ethernet LAN (RJ-45) ports	1
Component video (YPbPr/YCbCr) in	2
12V trigger	Yes
FM band range	87.5 - 107.9 MHz
Supported radio bands	FM
Internet radio services supported	Pandora, SIRIUS Internet Radio, Spotify, vTuner
Card reader integrated	No
Product color	Black
Audio decoders	Dolby Digital Plus, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Digital Surround, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-HD, DTS-HD Master Audio
Volume control	Rotary

Weight and Dimensions

Depth	378.9 mm
Width	434.3 mm
Height	166.8 mm
Weight	10899 g
