Denon AVR-2313CI Service Manual

200
Ref. No. Part No. Part Name Remarks Q'ty New
ZD408,409 963202500410S D,ZENER ZJ4.7B-0.5W K06004R744522S
ZD410 963202500300D D,ZENER ZJ5.1A-0.5W K06005R134522S
ZD411,412 963202500410S D,ZENER ZJ4.7B-0.5W K06004R744522S
ZD413 963202500300D D,ZENER ZJ5.1A-0.5W K06005R134522S
ZD414,415 963202500410S D,ZENER ZJ4.7B-0.5W K06004R744522S
ZD416 963202500300D D,ZENER ZJ5.1A-0.5W K06005R134522S
ZD417,418 963202500410S D,ZENER ZJ4.7B-0.5W K06004R744522S
ZD419 963202500300D D,ZENER ZJ5.1A-0.5W K06005R134522S
ZD420,421 963202500410S D,ZENER ZJ4.7B-0.5W K06004R744522S
RESISTORS GROUP
R403 nsp R,METAL FILM 270-J,1W C060027165060S
R405 nsp R,METAL FILM 270-J,1W C060027165060S
R406 963252100150S
POSISTOR,I9DHPTHF1608 471P
115T SMD PTC THERMISTOR
F320471001150S
R410 nsp JUMPER (0.6/52MM) L045084006040S
R415 963125012630S R,METAL FILM 22-J,1W FLAMERETARDANT C060022065050S
R418 963125010690S R,METAL FILM 15K-J,2W C060015366050S
R420 nsp
R,CARBON FILM,I9220K-J,1/5W-
52RE-AX
E3 C00002246P520S
R420 nsp
R,CARBON FILM,I9150K-J,1/5W-
52RE-AX
E2,E1C C00001546P520S
R424,425 00D9630345903 R,FIXED 2WJ-0.47 FLAMERETARDANT N113136647820S
R428 nsp JUMPER (0.6/52MM) L045084006040S
R430,431 00D9630345903 R,FIXED 2WJ-0.47 FLAMERETARDANT N113136647820S
R433 nsp
R,CARBON FILM,I9220K-J,1/5W-
52RE-AX
E3 C00002246P520S
R433 nsp
R,CARBON FILM,I9150K-J,1/5W-
52RE-AX
E2,E1C C00001546P520S
R434 nsp R,METAL FILM 3.3K-J,1W C060033265050S
R439 963125012630S R,METAL FILM 22-J,1W FLAMERETARDANT C060022065050S
R441,442 nsp R,METAL FILM 1K-J,1W C060010265050S
R443 nsp R,METAL FILM 270-J,1W C060027165060S
R447,448 nsp R,METAL FILM 270-J,1W C060027165060S
R449 963252100160S POSISTOR DHPTHF1608 471P 95T F320471000950S
R450 963252100150S
POSISTOR,I9DHPTHF1608 471P
115T SMD PTC THERMISTOR
F320471001150S
R453 nsp JUMPER (0.6/52MM) L045084006040S
R458 963125012630S R,METAL FILM 22-J,1W FLAMERETARDANT C060022065050S
R461 963125010690S R,METAL FILM 15K-J,2W C060015366050S
R463 nsp
R,CARBON FILM,I9220K-J,1/5W-
52RE-AX
E3 C00002246P520S
R463 nsp
R,CARBON FILM,I9150K-J,1/5W-
52RE-AX
E2,E1C C00001546P520S
R464 963252100160S POSISTOR DHPTHF1608 471P 95T F320471000950S
R467,468 00D9630345903 R,FIXED 2WJ-0.47 FLAMERETARDANT N113136647820S
R472 nsp JUMPER (0.6/52MM) L045084006040S
R474,475 00D9630345903 R,FIXED 2WJ-0.47 FLAMERETARDANT N113136647820S
R477 nsp
R,CARBON FILM,I9220K-J,1/5W-
52RE-AX
E3 C00002246P520S
R477 nsp
R,CARBON FILM,I9150K-J,1/5W-
52RE-AX
E2,E1C C00001546P520S
R483 963125012630S R,METAL FILM 22-J,1W FLAMERETARDANT C060022065050S
R485,486 nsp R,METAL FILM 1K-J,1W C060010265050S

Denon AVR-2313CI Specifications

General

Receiver type	-
Audio output channels	7.1 channels
Power output per channel (1KHz@6 Ohm)	135 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	8
Audio (L/R) in	6
Composite video in	4
Ethernet LAN (RJ-45) ports	1
Component video (YPbPr/YCbCr) in	2
12V trigger	Yes
FM band range	87.5 - 107.9 MHz
Supported radio bands	FM
Internet radio services supported	Pandora, SIRIUS Internet Radio, Spotify, vTuner
Card reader integrated	No
Product color	Black
Audio decoders	Dolby Digital Plus, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Digital Surround, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-HD, DTS-HD Master Audio
Volume control	Rotary

Weight and Dimensions

Depth	378.9 mm
Width	434.3 mm
Height	166.8 mm
Weight	10899 g
