Denon AVR-2313CI Service Manual

202
Ref. No. Part No. Part Name Remarks Q'ty New
R612 963125012630S R,METAL FILM 22-J,1W FLAMERETARDANT C060022065050S
R614,615 nsp R,METAL FILM 1K-J,1W C060010265050S
R616 nsp R,METAL FILM 270-J,1W C060027165060S
R619 nsp R,METAL FILM 270-J,1W C060027165060S
R621 nsp R,METAL FILM 270-J,1W C060027165060S
R623 963252100150S
POSISTOR,I9DHPTHF1608 471P
115T SMD PTC THERMISTOR
F320471001150S
R626 nsp JUMPER (0.6/52MM) L045084006040S
R631 963125012630S R,METAL FILM 22-J,1W FLAMERETARDANT C060022065050S
R634 963125010690S R,METAL FILM 15K-J,2W C060015366050S
R636 nsp
R,CARBON FILM,I9220K-J,1/5W-
52RE-AX
E3 C00002246P520S
R636 nsp
R,CARBON FILM,I9150K-J,1/5W-
52RE-AX
E2,E1C C00001546P520S
R640,641 00D9630345903 R,FIXED 2WJ-0.47 FLAMERETARDANT N113136647820S
R644 nsp JUMPER (0.6/52MM) L045084006040S
R646,647 00D9630345903 R,FIXED 2WJ-0.47 FLAMERETARDANT N113136647820S
R649 nsp
R,CARBON FILM,I9220K-J,1/5W-
52RE-AX
E3 C00002246P520S
R649 nsp
R,CARBON FILM,I9150K-J,1/5W-
52RE-AX
E2,E1C C00001546P520S
R650 nsp R,METAL FILM 3.3K-J,1W C060033265050S
R655 963125012630S R,METAL FILM 22-J,1W FLAMERETARDANT C060022065050S
R657,658 nsp R,METAL FILM 1K-J,1W C060010265050S
R659 nsp R,METAL FILM 270-J,1W C060027165060S
R662 nsp R,METAL FILM 270-J,1W C060027165060S
R664 nsp R,METAL FILM 270-J,1W C060027165060S
R666 963252100150S
POSISTOR,I9DHPTHF1608 471P
115T SMD PTC THERMISTOR
F320471001150S
R669 nsp JUMPER (0.6/52MM) L045084006040S
R674 963125012630S R,METAL FILM 22-J,1W FLAMERETARDANT C060022065050S
R677 963125010690S R,METAL FILM 15K-J,2W C060015366050S
R679 nsp
R,CARBON FILM,I9220K-J,1/5W-
52RE-AX
E3 C00002246P520S
R679 nsp
R,CARBON FILM,I9150K-J,1/5W-
52RE-AX
E2,E1C C00001546P520S
R683,684 00D9630345903 R,FIXED 2WJ-0.47 FLAMERETARDANT N113136647820S
R687 nsp JUMPER (0.6/52MM) L045084006040S
R689,690 00D9630345903 R,FIXED 2WJ-0.47 FLAMERETARDANT N113136647820S
R692 nsp
R,CARBON FILM,I9220K-J,1/5W-
52RE-AX
E3 C00002246P520S
R692 nsp
R,CARBON FILM,I9150K-J,1/5W-
52RE-AX
E2,E1C C00001546P520S
R694 nsp R,METAL FILM 3.3K-J,1W C060033265050S
R698 963125012630S R,METAL FILM 22-J,1W FLAMERETARDANT C060022065050S
R700,701 nsp R,METAL FILM 1K-J,1W C060010265050S
R702 nsp R,METAL FILM 270-J,1W C060027165060S
VR401-407 963161012400S VR,SEMI CARBON EVN-DCAA03B 1KB C541102315000S

Denon AVR-2313CI Specifications

General

Receiver type	-
Audio output channels	7.1 channels
Power output per channel (1KHz@6 Ohm)	135 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	8
Audio (L/R) in	6
Composite video in	4
Ethernet LAN (RJ-45) ports	1
Component video (YPbPr/YCbCr) in	2
12V trigger	Yes
FM band range	87.5 - 107.9 MHz
Supported radio bands	FM
Internet radio services supported	Pandora, SIRIUS Internet Radio, Spotify, vTuner
Card reader integrated	No
Product color	Black
Audio decoders	Dolby Digital Plus, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Digital Surround, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-HD, DTS-HD Master Audio
Volume control	Rotary

Weight and Dimensions

Depth	378.9 mm
Width	434.3 mm
Height	166.8 mm
Weight	10899 g
