Denon AVR-2313CI Service Manual

207
Ref. No. Part No. Part Name Remarks Q'ty New
R4147 nsp 270K-J,1/16W-1608 E3 C20002746M160S
R4147 nsp 56K-J,1/16W-1608 E2/E1C C20005636M160S
R4148,4149 nsp 2.2M-J,1/5W-52RE-AX E3 C00002256P520S
R4150 nsp 1M-J,1/5W-52RE-AX E3 C00001056P520S
CAPACITORS GROUP
C4000 nsp
C,CERAMIC CHIP HIK,I9X7R
0.01UF-K/200V-2012REEL
E3 D01110317G200S
C4001 nsp
C,FILM P.PROPYLENE // ST-0.01UF-
J/100V-5RE MANUAL
E2,E1C D02110306C050S
C4002 nsp
C,CERAMIC CHIP HIK,I9X7R
0.01UF-K/200V-2012REEL
E3 D01110317G200S
C4003 nsp
C,FILM P.PROPYLENE // ST-0.01UF-
J/100V-5RE MANUAL
E2,E1C D02110306C050S
C4004 nsp C,FILM MI-0.047UF-J/50V D020473167050S
C4006 nsp
C,CERAMIC CHIP HIK,I9X7R
0.01UF-K/200V-2012REEL
E3 D01110317G200S
C4007 nsp
C,FILM P.PROPYLENE // ST-0.01UF-
J/100V-5RE MANUAL
E2,E1C D02110306C050S
C4008 nsp C,FILM MI-0.047UF-J/50V D020473167050S
C4010 nsp
C,CERAMIC CHIP HIK,I9X7R
0.01UF-K/200V-2012REEL
E3 D01110317G200S
C4011 nsp
C,FILM P.PROPYLENE // ST-0.01UF-
J/100V-5RE MANUAL
E2,E1C D02110306C050S
C4012 nsp
C,CERAMIC CHIP HIK,I9X7R
0.01UF-K/200V-2012REEL
E3 D01110317G200S
C4013 nsp
C,FILM P.PROPYLENE // ST-0.01UF-
J/100V-5RE MANUAL
E2,E1C D02110306C050S
C4015 nsp C,FILM MI-0.047UF-J/50V D020473167050S
C4016 nsp
C,CERAMIC CHIP HIK,I9X7R
0.01UF-K/200V-2012REEL
E3 D01110317G200S
C4017 nsp
C,FILM P.PROPYLENE // ST-0.01UF-
J/100V-5RE MANUAL
E2,E1C D02110306C050S
C4019 nsp
C,CERAMIC CHIP HIK,I9X7R
0.01UF-K/200V-2012REEL
E3 D01110317G200S
C4020 nsp
C,FILM P.PROPYLENE // ST-0.01UF-
J/100V-5RE MANUAL
E2,E1C D02110306C050S
C4021 nsp C,FILM MI-0.047UF-J/50V D020473167050S
C4025 nsp C,FILM MI-0.047UF-J/50V D020473167050S
C4029 nsp C,FILM MI-0.047UF-J/50V D020473167050S
C4031 nsp C,FILM MI-0.047UF-J/50V D020473167050S
C4033 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C4036 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C4039 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C4042 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C4045 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C4048 00D2544574922 C,ELECT 100UF-M/50V D040101087060S
C4049 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C4052 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C4060,4061 nsp C,FILM 0.1UF-K/250V E3 D02010407H080S
C4060,4061 nsp C,FILM P.PROPYLENE E2,E1C D02110406C050S
C4062 00D2544573981 C,ELECT 10UF-M/50V D040100087070S
C4063,4064 963134010180S C,ELECT 12000UF-M/71V D040123089550S
C4065 nsp C,CERAMIC 1000PF-K/50V D011102777160S

Denon AVR-2313CI Specifications

General

Receiver type	-
Audio output channels	7.1 channels
Power output per channel (1KHz@6 Ohm)	135 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	8
Audio (L/R) in	6
Composite video in	4
Ethernet LAN (RJ-45) ports	1
Component video (YPbPr/YCbCr) in	2
12V trigger	Yes
FM band range	87.5 - 107.9 MHz
Supported radio bands	FM
Internet radio services supported	Pandora, SIRIUS Internet Radio, Spotify, vTuner
Card reader integrated	No
Product color	Black
Audio decoders	Dolby Digital Plus, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Digital Surround, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-HD, DTS-HD Master Audio
Volume control	Rotary

Weight and Dimensions

Depth	378.9 mm
Width	434.3 mm
Height	166.8 mm
Weight	10899 g
