Denon AVR-2313CI Service Manual

222
Ref. No. Part No. Part Name Remarks Q'ty New
R1629 nsp R,CHIP THICK,I9180-F,1/16W-1608REEL C20001814M160S
R1630 nsp R,CHIP THICK,I92.7K-F,1/16W-1608REEL C20002724M161S
R1631 nsp R,CHIP THICK,I9180-F,1/16W-1608REEL C20001814M160S
R1699,1700 nsp R,CHIP THICK 51-D,1/16W-1608REEL C20005101M160S
R1818,1819 nsp R,CHIP THICK 1K-D,1/16W-1608REEL C20001021M160S
R1844,1845 nsp R,CHIP THICK 51-D,1/16W-1608REEL C20005101M160S
R3017 nsp CHIP RES. 0-J 1/16W-1608REEL E2 C20000006M160S
R3017 nsp CHIP RES. 10K-J 1/16W-1608REEL E1C C20001036M160S
R3018 nsp CHIP RES. 0-J 1/16W-1608REEL E3 C20000006M160S
R3018 nsp CHIP RES. 10K-J 1/16W-1608REEL E1C C20001036M160S
R3625 nsp R,CHIP 150K-D,1/16W-1608REEL C20001541M160S
R3626 nsp R,CHIP THICK 47K-D,1/16W-1608REEL C20004731M160S
R3627 nsp R,CHIP 150K-D,1/16W-1608REEL C20001541M160S
R3628 nsp R,CHIP THICK 120K-D,1/16W-1608REEL C20001241M160S
R3629 nsp R,CHIP 150K-D,1/16W-1608REEL C20001541M160S
R3630 nsp R,CHIP THICK,I9470K-D,1/16W-1608REEL C20004741M160S
R3631 nsp R,CHIP 150K-D,1/16W-1608REEL C20001541M160S
R3632 nsp R,CHIP THICK 300K-D,1/16W-1608REEL C20003041M160S
R3633 nsp R,CHIP 150K-D,1/16W-1608REEL C20001541M160S
R3634 nsp R,CHIP THICK 120K-D,1/16W-1608REEL C20001241M160S
CAPACITORS GROUP
C1003-1007 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1010 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C1016 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C1023 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C1025 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C1027 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C1029 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C1031 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C1201-1207 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1208 nsp C,CERAMIC 10UF-K/16V D011106573200S
C1209 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C1210 nsp CER. CAP. X7R)0.01UF-K/50V-1005REEL D011103777101S
C1211 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C1212 nsp C,CERAMIC 10UF-K/16V D011106573200S
C1219 nsp C,CERAMIC 10UF-K/16V D011106573200S
C1301-1304 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1305 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C1306-1311 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1312 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C1314-1321 nsp R,CHIP 0-J,1/16W C20000006M101S
C1323-1325 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1327 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1329-1331 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1333 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1335,1336 nsp CER. CAP. X7R)0.01UFK/25V1005REEL D011103174101S
C1337 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1339 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1341 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1342 nsp CER. CAP. X7R)0.01UFK/25V1005REEL D011103174101S
C1345 nsp CER. CAP. X7R)0.01UFK/25V1005REEL D011103174101S
C1350 nsp CER. CAP. X7R)0.01UFK/25V1005REEL D011103174101S
C1351 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1358 nsp CER. CAP. X7R)0.01UFK/25V1005REEL D011103174101S
C1361 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1362 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C1364 nsp CER. CAP. X7R)0.01UFK/25V1005REEL D011103174101S

Denon AVR-2313CI Specifications

General

Receiver type	-
Audio output channels	7.1 channels
Power output per channel (1KHz@6 Ohm)	135 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	8
Audio (L/R) in	6
Composite video in	4
Ethernet LAN (RJ-45) ports	1
Component video (YPbPr/YCbCr) in	2
12V trigger	Yes
FM band range	87.5 - 107.9 MHz
Supported radio bands	FM
Internet radio services supported	Pandora, SIRIUS Internet Radio, Spotify, vTuner
Card reader integrated	No
Product color	Black
Audio decoders	Dolby Digital Plus, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Digital Surround, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-HD, DTS-HD Master Audio
Volume control	Rotary

Weight and Dimensions

Depth	378.9 mm
Width	434.3 mm
Height	166.8 mm
Weight	10899 g
