Denon AVR-2313CI Service Manual

75
3.4. Device display during rmware update
Display of target device during rmware update.
Target device Display Error code when an error occurs
Main CPU
M a i n : * * % * * * m i n
08 - 0B
10 - 15
20 - 27
36 - 3B
3F
Audio PLD
A P L D : * * % * * * m i n
50 - 52
54 - 58
5A - 64
DSP
D S P : * * % * * * m i n
50 - 52
54 - 58
5A - 64
GUI Serial Flash
G U I : * * % * * * m i n
50 - 52
54 - 58
5A
62 - 64
80 - 86
DM860A Boot Loader
E S B L : * * % * * * m i n
A0 - A4
A6 - A7
AE - B5
DM860A Image
E I M G : * * % * * * m i n
A0 - A4
A6 - A7
AE - B5
DM860A Image (Emergency Mode)
U p d a t e r e t r y
–
Conrming the rmware’s number after upgraded
After updating the rmware, check the version. Refer to "
1. μcom/DSP Version display mode
" (24 page).

Denon AVR-2313CI Specifications

General

Receiver type	-
Audio output channels	7.1 channels
Power output per channel (1KHz@6 Ohm)	135 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	8
Audio (L/R) in	6
Composite video in	4
Ethernet LAN (RJ-45) ports	1
Component video (YPbPr/YCbCr) in	2
12V trigger	Yes
FM band range	87.5 - 107.9 MHz
Supported radio bands	FM
Internet radio services supported	Pandora, SIRIUS Internet Radio, Spotify, vTuner
Card reader integrated	No
Product color	Black
Audio decoders	Dolby Digital Plus, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Digital Surround, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-HD, DTS-HD Master Audio
Volume control	Rotary

Weight and Dimensions

Depth	378.9 mm
Width	434.3 mm
Height	166.8 mm
Weight	10899 g
