Denon AVR-2313CI Service Manual

82
6
Surround
Sound Mode NOTE
Input signal types and formats
ANALOG
PCM DTS-HD DTS DOLBY DOLBY DIGITAL Super Audio CD
PCM
(multi ch)
PCM
(2ch)
DTS-HD
Master
Audio
DTS-HD
High
Resolution
Audio
DTS
EXPRESS
DTS ES
DSCRT
(With Flag)
DTS ES
MTRX
(With Flag)
DTS
(5.1ch)
DTS 96/24
DOLBY
TrueHD
DOLBY
DIGITAL
Plus
DOLBY
DIGITAL EX
(With Flag)
DOLBY DIGITAL
EX
(With no Flag)
DOLBY
DIGITAL
(5.1ch)
DOLBY
DIGITAL
(2ch)
DSD
(multi ch)
DSD
(2ch)
MULTI CH IN
MULTI CH IN
z1 F S
MULTI CH IN + PLgx CINEMA z2z4 S S MULTI CH IN + PLgx MUSIC z2z3 S S MULTI CH IN + PLgz z5z6 S S MULTI CH IN + Dolby EX
z2z3 S S
MULTI CH IN 7.1
z2z3 F (7.1)
Audyssey DSX
®
S
DIRECT
DIRECT
S S S S S S S S S S S S S S S S S S
DSD DIRECT
S S
PURE DIRECT
PURE DIRECT
S S S S S S S S S S S S S S S S S S
DSP SIMULATION
MULTI CH STEREO
S S S S S S S S S S S S S S S S
ROCK ARENA
S S S S S S S S S S S S S S S S
JAZZ CLUB
S S S S S S S S S S S S S S S S
MONO MOVIE
S S S S S S S S S S S S S S S S
VIDEO GAME
S S S S S S S S S S S S S S S S
MATRIX
S S S S S S S S S S S S S S S S
VIRTUAL
S S S S S S S S S S S S S S S S
STEREO
STEREO
F S F S S S S S S S S S S S S S S S
z1 If “Audyssey DSX
®
” is set to “On”, the Audyssey DSX
®
effect is added to the sound mode marked with z1.
z2 This sound mode can be selected when “Assign Mode” is set to “Surround Back”. z3 If “Speaker Config.” – “Surr. Back” is set to “None”, this sound mode cannot be selected. z4 If “Speaker Config.” – “Surr. Back” is set to “1spkr” or “None”, this sound mode cannot be selected. z5 If “Speaker Config.” – “Front Height” is set to “None”, this sound mode cannot be selected. z6 This sound mode can be selected when “Assign Mode” is set to “Front Height”.

Denon AVR-2313CI Specifications

General

Receiver type	-
Audio output channels	7.1 channels
Power output per channel (1KHz@6 Ohm)	135 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	8
Audio (L/R) in	6
Composite video in	4
Ethernet LAN (RJ-45) ports	1
Component video (YPbPr/YCbCr) in	2
12V trigger	Yes
FM band range	87.5 - 107.9 MHz
Supported radio bands	FM
Internet radio services supported	Pandora, SIRIUS Internet Radio, Spotify, vTuner
Card reader integrated	No
Product color	Black
Audio decoders	Dolby Digital Plus, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Digital Surround, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-HD, DTS-HD Master Audio
Volume control	Rotary

Weight and Dimensions

Depth	378.9 mm
Width	434.3 mm
Height	166.8 mm
Weight	10899 g
