Denon AVR-2809 User Manual

For details on how to select, set and cancel settings for each menu, see “Menu Operations” (vpage 19).

Getting Started Connections Setup Playback Remote Control Multi-zone Information Troubleshooting
ENGLISH
F Menu screen F
2.Manual Setup
2.HDMI Setup
1.Speaker Setup
4.Zone Setup
5.Option Setup
3.Audio Setup
Audio Setup
Make settings for audio playback.
2.2ch Direct/Stereo
3.Dolby Digital Setup
4.Auto Surround Mode
5.EQ Preset
1.EXT.IN SW Level
2-3.Audio Setup
s
2ch Direct/Stereo
Make speaker settings for 2-channel mode playback.
Setting
To change the settings, select “Custom”.
[Selectable items]
Basic
: Use the same settings as in “Speaker Setup”.
Custom
: Make separate settings for 2-channel mode.
a
EXT. IN Subwoofer Level
Set the subwoofer level for playback.
[Selectable items]
0dB +5dB +10dB +15dB
We recommend setting to “+15dB”.
Front
Select front speaker size.
[Selectable items]
Large Small
: Select front speaker size.
Subwoofer
Select subwoofer use.
[Selectable items]
Yes No
: Select subwoofer use.
Subwoofer Mode
Select low range signal to be reproduced by subwoofer.
[Selectable items]
LFE LFE+Main
: Select subwoofer signal.
Crossover
Select crossover frequency from which subwoofer handles low range
signal.
[Selectable items]
40Hz 60Hz 80Hz 90Hz 100Hz 110Hz 120Hz 150Hz
200Hz 250Hz
: Select crossover frequency.
Distance FL
Set distance from listening position to front left speaker.
[Variable range]
0.00m ~ 18.00m
Distance FR
Set distance from listening position to front right speaker.
[Variable range]
0.00m ~ 18.00m
NOTE
Set the distance between the listening position and the various
speakers to no more than 6.00 meters (20.0 ft).
Specifications
[Selectable items]
ON OFF
• This can be set when “HDMI Control“ is set to “ON“.
• Please consult the operating instructions for each connected device
to check the settings.
NOTE
• When the “HDMI Control” setting has been changed, always turn
off the power to the connecting devices afterwards and then turn
back on.
• The “HDMI Control” and “Power Off Control” does not work when
the power to the equipment is off.
• For details, see “HDMI Control Function” (vpage 54).
h Power Off Control
Interlock power OFF with HDMI control.
d
Dolby Digital Setup
Set dynamic range for downmix playback of Dolby Digital
sources.
• Set this to “ON” if the sound from the front speakers seems
distorted.
• When not using the center speaker or surround speakers, the
playback sound is down-mixed and output from the front speakers.
[Selectable items]
ON
: Compression is used. Select this if sound from front
speakers is distorted.
OFF
: Do not use compression. This is the recommended
setting.
