For details on how to select, set and cancel settings for each menu, see “Menu Operations” (vpage 19).

Getting Started Connections Setup Playback Remote Control Multi-zone Information Troubleshooting
ENGLISH
Specifications
Volume Limit
Make a setting for maximum volume.
[Selectable items]
OFF
: Do not set a maximum volume.
–20dB
: Set the maximum volume to –20 dB.
–10dB
: Set the maximum volume to –10 dB.
0dB
: Set the maximum volume to 0 dB.
Power On Level
Define the volume setting that is active when the power is turned
on.
[Selectable items]
Last
: Use the memorized setting from the last session.
– – –
: Always use the muting on condition when power is
turned on.
–70dB ~ 18dB
: Set the volume level when the power is turned on
in units of 1 dB.
Mute Level
Set the amount of attenuation when muting is on.
[Selectable items]
Full
: The sound is cut off entirely.
–40dB
: The sound is attenuated by 40 dB.
–20dB
: The sound is attenuated by 20 dB.
This can be set when “Volume Level” is set to “VAR”.
This can be set when “Volume Level” is set to “VAR”.
“VAR” is fixed when a power amplifier is assigned to the ZONE2 or
ZONE3 output channel at menu “Manual Setup” “Option Setup”
– “Amp Assign” (vpage 31).
F Menu screen F
2.Manual Setup
2.HDMI Setup
1.Speaker Setup
4.Zone Setup
5.Option Setup
3.Audio Setup
Option Setup
Make various other settings.
a
Amp Assign
Define how the amplifier for the surround back speaker channels
is used.
The places where the surround back amplifier are used can be set
freely according to the usage environment. This makes it possible to
output sound to rooms other than the room (the MAIN ZONE) where
surround playback is performed (multi-zone playback) or play the sound
with high quality using the front speakers (bi-amp connections).
[Selectable items]
7.1ch
: The surround back channel is output from the
speakers connected to the SURR.BACK/AMP
ASSIGN terminals.
ZONE2
: When ZONE2 power is on, ZONE2 sound is
emitted from the speaker connected to the
SURR.BACK/AMP ASSIGN terminal.
ZONE3
: When ZONE3 power is on, ZONE3 sound is
emitted from the speaker connected to the
SURR.BACK/AMP ASSIGN terminal.
ZONE2/3-MONO
: ZONE2 monaural sound is emitted from the
speaker connected to the SURR.BACK/AMP
ASSIGN (L) speaker, and ZONE3 monaural sound
is emitted from the speaker connected to the
SURR.BACK/AMP ASSIGN (R) terminal.
FrontA Bi-Amp
: The Front A channel for Bi-Amp use is output
from the speakers connected to the SURR.
BACK/AMP ASSIGN terminals.
FrontB Bi-Amp
: The Front B channel for Bi-Amp use is output
from the speakers connected to the SURR.
BACK/AMP ASSIGN terminals.
2.Vol.Control
3.Source Delete
4.On-Screen Display
5.Quick Select Name
6.Trigger Out
7.Remote ID Setup
8.232C Port
9.Display
10.Setup Lock
1.Amp Assign
2-5.Option Setup
Level Lch
Adjust the left channel output level.
[Variable range]
–12dB
~
0dB
~
+12dB
Level Rch
Adjust the right channel output level.
[Variable range]
–12dB
~
0dB
~
+12dB
Channel
Switch between stereo and mono output.
[Selectable items]
Stereo
: Select stereo output.
Mono
: Select monaural output.
When menu “Manual Setup” “Option Setup” “Amp Assign”
(vpage 31) is set to ZONE2/3-MONO”, the “Channel” setting is
automatically set to “Mono”.
The “Level Lch” and “Level Rch” can be set when “Channel” is set
to “Stereo”.
Volume Level
Adjust the main volume level.
[Selectable items]
VAR
: Allow volume adjustment by remote control.
–40dB
: Fix the volume to –40 dB.
0dB
: Fix the volume to 0 dB.
