Connecting video components
• To connect the video signal, connect using a 75 Ω/ohms video signal cable cord. Using an improper cable can result in a drop in picture quality.
• When making connections, also refer to the operating instructions of the other components.
R L
OUT
OUT
OUT
OUT
PRE OUT
PHONO
FRONT
CENTER
EFECT
/ SB
SURROUND
SIGNAL
GND
CD
DVD
VDP
TV
/
DBS
V.AUX
VCR
-
1
VCR
-
2
MD
/
TAPE-1
TAPE-2
MONITOR
SOURCE
MULTI
OUT-1
MONITOR
OUT-2
DVD
VDP
TV
/
DBS
V.AUX
VCR
-
1
VCR
-
2
VCR
-
1
VCR
-
2
VCR
-
1
VCR
-
2
MD
/
TAPE-1
TAPE-2
6CH EXT. IN
FR
SW
SR
ER
FL
C
SL
EL
8CH EXT. IN AUDIO VIDEO S-VIDEO DIGITAL
SUB
WOOFER
R L
R L
OPTICAL
COAXIAL
OPTICAL-5
123
123
4
IN
IN
IN
IN
IN
LOOP
ANT.
AM
FM
COAX.
75
ANTENNA TERMINALS
SB-R
SB/
SB-L
IN
VIDEO
COAXIAL OPTICAL
OUTPUT
R
L
R
L
R
L
R
L
L
R
R
L
R OUT IN
AUDIO
VIDEO
OUT IN
LRL
R
L
R
L
R OUT IN
AUDIO
VIDEO
OUT IN
LRL
R
L
R
L
R OUT
VIDEO
OUT
L
AUDIO
L
R
R OUT
VIDEO
OUT
L
AUDIO
L
R
TV or DBS tuner
LD player, CDV player, etc.
Monitor TV
Connecting a TV/DBS tuner
TV/DBS
• Connect the TV’s or DBS tuner’s video output jack (VIDEO OUTPUT) to the (yellow) TV/DBS IN jack using a
75 Ω/ohms video coaxial pin plug cord.
• Connect the TV’s or DBS tuner’s audio output jacks (AUDIO OUTPUT) to the TV/DBS IN jacks using pin plug
cords.
AUDIO
VIDEO
Connecting a video disc player VDP
VDP
• Connect the video disc player’s video output jack (VIDEO OUTPUT) to the
(yellow) VDP/DVD IN jack using a 75 Ω/ohms video coaxial pin plug
cord.
• Connect the video disc player’s analog audio output jacks (ANALOG AUDIO
OUTPUT) to the VDP/DVD IN jacks using pin plug cords.
• A DVD player can be connected to the DVD jacks in the same way.
• It is also possible to connect a video disc player, DVD player, video camcorder,
game machine, etc., to the V.AUX jacks.
AUDIO
VIDEO
MONITOR OUT
• Connect the TV’s video input
jack (VIDEO INPUT) to the
MONITOR OUT jack
using a 75 Ω/ohms video
coaxial pin plug cord.
• The monitor TV can also be
connected in the same way
to the VIDEO MONITOR
OUT-2 jack. Note, however,
that the AVR-4800’s on-
screen display signals are
not output from this jack.
(See page 29.)
VIDEO
Note on connecting the digital input jacks
• Only audio signals are input to the digital input
jacks. For details, see page 6.
LD player or other component
equipped with digital output jacks
Video deck 2
Video deck 1
• There are two sets of video deck (VCR) jacks, so two video decks can be connected for simultaneous recording or video copying.
Video input/output connections:
• Connect the video deck’s video output jack (VIDEO OUT) to the (yellow) VCR-1 IN jack, and the video deck’s video input jack (VIDEO IN) to the
(yellow) VCR-1 OUT jack using 75 Ω/ohms video coaxial pin plug cords.
Connecting the audio output jacks
• Connect the video deck’s audio output jacks (AUDIO OUT) to the VCR-1 IN jacks, and the video deck’s audio input jacks (AUDIO IN) to the VCR-1
OUT jacks using pin plug cords.
Connect the second video deck to the VCR-2 jacks in the same way.
AUDIOAUDIO
VIDEOVIDEO
Connecting a video decks

Denon AVR-4800 Specifications

Power Amplifier

stereo rated output	125 W + 125 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.05% T.H.D.)
surround rated output	125 W x 5 ch (8 Ω/ohms, 1 kHz with 0.7% T.H.D.)
dynamic power	170 W x 2 ch (8 Ω/ohms), 270 W x 2 ch (4 Ω/ohms), 350 W x 2 ch (2 Ω/ohms)

Analog Audio

input sensitivity / input impedance	200 mV / 47 kΩ/kohms
frequency response	10 Hz ~ 100 kHz: +0, –3 dB (DIRECT mode)
S/N ratio	105 dB (DIRECT mode)

Digital Audio

D/A output rated output	2 V (at 0 dB playback)
total harmonic distortion	0.005% (1 kHz, at 0 dB)
S/N ratio	105 dB

Phono Equalizer

input sensitivity	2.5 mV
RIAA deviation	±1 dB (20 Hz to 20 kHz)
signal-to-noise ratio	74 dB (A weighting, with 5 mV input)

Video

standard video jacks input/output level and impedance	1 Vp-p, 75 Ω/ohms
S-video jacks input/output level and impedance	Y signal — 1 Vp-p, 75 Ω/ohms; C signal — 0.286 Vp-p, 75 Ω/ohms
color component video terminal input/output level and impedance	Y signal — 1 Vp-p, 75 Ω/ohms; Cb signal — 0.7 Vp-p, 75 Ω/ohms; Cr signal — 0.7Vp-p, 75 Ω/ohms

Tuner

receiving range	87.5 MHz ~ 107.9 MHz, 520 kHz ~ 1710 kHz
usable sensitivity	1.0 µV (11.2 dBf), 18 µV
signal to noise ratio (IHF-A)	MONO 80 dB, STEREO 75 dB

General

power supply	AC 120 V, 60 Hz
power consumption	10.9 A
maximum external dimensions	434 (W) x 181 (H) x 494 (D) mm (17-3/32” x 7-1/8” x 19-29/64”)

Remote Control Unit

batteries	R6P/AA Type (two batteries)
external dimensions	70 (W) x 215 (H) x 24 (D) mm (2-3/4” x 8-15/32” x 15/16”)
weight	200 g (Approx. 7 oz) (including batteries)
