Denon AVR-X2400H

Test Item & Test Result
Test whether there are issues in the HDMI cable communication line and whether the line is compatible with the transfer domains of the resolutions in the table below.
After you finish the cable test, if you still have any issues, please try the following solution.
1
Replace the HDMI cable.
2
To use this cable in your system, please set the limit mode to the resolution that was passed in the following test.
Cable Test Item
Result
(Front panel display)
Communication
line
Video Resolution (RGB / 8bit)
4k60 4k30 1080p 720p 480p
PASS PASS PASS PASS PASS PASS CABLE TEST PASS
PASS FAIL PASS PASS PASS PASS 4K(3G) PASS / 4K(6G) FAIL
PASS FAIL FAIL PASS PASS PASS 1080p PASS / 4K(3G) FAIL
PASS FAIL FAIL FAIL PASS PASS 720p PASS / 1080p FAIL
PASS FAIL FAIL FAIL FAIL PASS 480p PASS / 720p FAIL
PASS FAIL FAIL FAIL FAIL FAIL CABLE TEST FAIL
FAIL --- --- --- --- --- CABLE TEST FAIL
