Denon AVR-X2400H Troubleshooting Guide

Setting
Max Resolution
Max Resolution has 5 selectable items.
No Limit No limit. The AV Receiver works up to 4K(6G).
4K(3G)
(Default):
This sets EDID information and max resolution of the video
output from the AV Receiver to up to 4K(3G)
1080p:
*2
This sets EDID information and max resolution of the video
output from the AV Receiver to up to 1080p (60/50).
720p:
*1
This sets EDID information and max resolution of the video
output from the AV Receiver to up to 720p, 1080i or 1080p
24. When 720p is set, the resolution may be 1080i for some
playback devices or content.
480p:
This sets EDID information and max resolution of the video
output from the AV Receiver to up to 480p or 576p.
z1
On the AVR-S730H and AVR-X1400H, “720p” is the default setting for audio input
sources such as Tuner and HEOS Music. “No Limit”, “4K(3G) ” and “1080p” cannot be
set for these sources.
z2
On other models, “1080p” is the default setting for audio input sources such as Tuner,
Phono and HEOS Music. “No Limit” and “4K(3G) ” cannot be set for these sources.
0
When you set a resolution in the "Max Res." setting, you will not be able to change to a
higher resolution in the AVR Setup Menu-Video-Output settings.
0
When the Max Resolution settings are changed from the default values, “Custom” is
displayed in the AVR Setup Menu – Video – 4K Signal Format. The Max Resolution
settings take priority when “Custom” is set.
【Relationship between Max Resolution setting and Support Resolution】
Support
Resolution
Color
Space
Pixel
Depth
Max Resolution setting
No Limit
(4K(6G))
4K(3G) 1080p 720p 480p
480i/p,
576i/p
RGB
24,30,36bit
✔ ✔ ✔ ✔ ✔
YCbCr4:4:4
YCbCr4:2:2 36bit ✔ ✔ ✔ ✔ ✔
1080i
60/50
RGB
24,30,36bit
✔ ✔ ✔ ✔ -
YCbCr4:4:4
YCbCr4:2:2 36bit ✔ ✔ ✔ ✔ -
720p
60/50
RGB
24,30,36bit
✔ ✔ ✔ ✔ -
YCbCr4:4:4
YCbCr4:2:2 36bit ✔ ✔ ✔ ✔ -
1080p 24
RGB
24,30,36bit
✔ ✔ ✔ ✔ -
YCbCr4:4:4
YCbCr4:2:2 36bit ✔ ✔ ✔ ✔ -
1080p
60/50
RGB
24,30,36bit
✔ ✔ ✔ - -
YCbCr4:4:4
YCbCr4:2:2 36bit ✔ ✔ ✔ - -
4K24p,
4K30p,
4K25p
RGB 24bit ✔ ✔ - - -
YCbCr4:4:4 30,36bit ✔ - - - -
YCbCr4:2:2 36bit ✔ ✔ - - -
4K60p,
4K50p
YCbCr4:2:0
24bit ✔ ✔ - - -
30,36bit ✔ - - - -
RGB
24bit
✔ - - - -
YCbCr4:4:4
YCbCr4:2:2 36bit ✔ - - - -
Introduction How to operate Cable Test Limit mode Log & EDID Troubleshooting
13

Denon AVR-X2400H Specifications

General

Receiver type	Surround
Frequency range	20 - 20000 Hz
Pre-out channels	2 SW
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	150 W
Power output per channel (20-20KHz@8 Ohm)	95 W
Display	VFL
HDCP version	2.2
Apple docking	No
Product color	Black
Audio decoders	DTS-HD Master Audio, DTS:X, Dolby Atmos, Dolby Surround
Volume control	Rotary
Center speaker impedance	16 Ω
Supported video modes	720i, 720p, 960p, 1080i, 1080p, 2160p
Supported graphics resolutions	3840 x 2160
HDMI in	8
Audio (L/R) in	4
Digital audio coaxial in	0
Ethernet LAN (RJ-45) ports	1
Multichannel audio input type	RCA
Component video (YPbPr/YCbCr) in	2
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Internet radio services supported	Deezer, Napster, Pandora, SIRIUS Internet Radio, Spotify, Tidal, iHeartRadio
Audio formats supported	ALAC, DSD, FLAC, MP3, WAV
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	500 W
Headphone connectivity	3.5 mm
Connectivity technology	Wired & Wireless
Speakers connectivity type	3.5mm
Certification	CE, EAC

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	167 mm
Weight	9400 g
