HDMI DIAGNOSTICS Menu
When the Hardware Self-Diagnostics Test is passed, the AV Receiver displays the HDMI DIAGNOSTICS Menu below.
1
Use ui to select the menu to be set or operated, then press ENTER.
0
Front panel display sample (e.g.AVR-X2400H)
.
Item Description page
1 Auto Test
The AV Receiver assists you in identifying the cause of any HDMI issues using Video Test, Audio Test,
Cable Test or the limit mode feature according to the guidance indicated on the front panel display.
－
2 Video Test
Diagnose video-related issues. If an error is detected, please refer to the flow of the corresponding
error number in the "Trouble shooting Guide".
20
3 Audio Test
Diagnose audio-related issues. If an error is detected, please refer to the flow of the corresponding
error number in the "Trouble shooting Guide".
This cannot be selected if the currently selected input source is an audio type source.
20
4 Cable Test Check HDMI-Cable integrity and signal (resolution) capability. 10
5 Limitation Mode
(Limit Mode)
Set settings to limit the AV Receiver's Video or Audio EDID.
There are instances where limiting the AV Receiver video or audio EDID will fix various issues.
Please try each limit settings in accordance with the "Trouble shooting Guide".
If you want to clear the limit settings, please refer to "3.Initialization".
12
6 Log/EDID
Save the Logging data to USB file or network server.
Please use it when receiving the requested by customer service.
19
7 Exit Exit the HDMI Diagnostic mode －
Introduction How to operate Cable Test Limit mode Log & EDID Troubleshooting
6
To Next Page
