Video Flow V1-03/04/05/08/09
.
"V1-03/04/05/08/09"
Please try another video check again.
If your issue has been fixed, go to "Yes".
If you get the same Diag. ID, go to "No".
(If you get the another Diag. ID, try another flow)
Yes
No
End
Please check the AV
Receiver setting.
(Note 2)
Question 5
Yes No
Please call
Customer Service
Are the AV Receiver settings correct ?
Please check the Source Device (Note 1)
Please retry
setting the AVR
and try another video check.
Description "V1-03": Cannot detect the HDMI signal from the source device at
the AVR input terminal (TMDS Rx PLL Lock, but SCDT(CKDT) OFF).
Description "V1-04": Missing Video Info, or receiving Info Error (AVI Info does
not exist).
Description "V1-05": HDMI signal has video timing Error (Timing is not correct).
Description "V1-08": Mismatch between input resolution and the resolution that
is supported by monitor.
Description "V1-09": Audio/Video MUTE command from Source Device is
always ON.
Question * :Question for user to answer
Note 1 : Source Device check item (For details (
v
p. 40))
Note 2 : AV Receiver check item (For details (v p. 40))
