Denon AVR-X3100W Service Manual

Pin Symbol Pin Name I/O Pu/Pd
LvCnv
STBY
CEC
STBY
Function
85 PD1/IRQ1 DSP1CS O C
DA
3VPu
Z L DSP control pin (ADSP21487KSWZ-3B)
86 PD0/IRQ0 DSP1FLAG0 I -
Pd
Z - DSP control pin (ADSP21487KSWZ-3B)
87 P47/AN007 NC O C
-
Z - NC
88 P46/AN006 VIN A O C
-
Z - COMPOSITE VIDEO SELECT IC(NJM2595)
89 P45/AN005 VIN B O C
-
Z - COMPOSITE VIDEO SELECT IC(NJM2595)
90 P44/AN004 VIN C O C
-
Z - COMPOSITE VIDEO SELECT IC(NJM2595)
91 P43/AN003 COMP SW1 O C O/L L COMPONENT VIDEO SELECT IC(NJM2586)
92 P42/AN002 COMP SW2 O C O/L L COMPONENT VIDEO SELECT IC(NJM2586)
93 P41/AN001 NC O C
-
Z - NC
94 VREFL0 VREFL0 - -
-
- - GND
95 P40/AN000 NC O C
-
Z - NC
96 VREFH0 VREFH0 - -
-
- - +3.3V
97 AVCC0 AVCC - -
-
- - +3.3V
98 P07 NC O C
-
Z - NC
99 AVSS0 AVSS0 - -
-
- - GND
100 P05 TXEN O C
-
Z - Front HDMI INPUT (AD8195) control pin
166

Denon AVR-X3100W Specifications

General

Receiver type	Surround
Speaker selector	A+B
Audio output channels	7.1 channels
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	180 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	8
Remote control in	1
Composite video in	3
Multichannel audio input type	Terminals
Component video (YPbPr/YCbCr) in	2
12V trigger	Yes
Speakers connectivity type	-
Audio formats supported	AAC, AIFF, FLAC, MP3, WAV, WMA
Supported radio bands	FM
Product color	Black
Audio decoders	Dolby Digital EX, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:X, DTS-ES, DTS-HD Master Audio
Volume control	Rotary
Apple docking compatibility	Not supported
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W

Weight and Dimensions

Depth	388 mm
Width	434 mm
Height	167 mm
Weight	10700 g
