Denon AVR-X3100W Service Manual

Pin Symbol Pin Name I/O Pu/Pd
LvCnv
STBY
CEC
STBY
Function
34 P12/SCL/IRQ2 778_1_RST O C
Pd
Z
※
HDMI MN8647781(TX) RESET control pin
35 PH3 HSDA I/O C
CEC
3VPu
O/L L HDMI I2C- MN8647781
36 PH2/IRQ1 HSCL I/O C
CEC
3VPu
O/L L HDMI I2C- MN8647781
37 PH1/IRQ0 778_1_HINT I -
-
Z - HDMI MN8647781(TX) HDMI INT input pin
38 PH0 778_2_RST O C
Pd
Z
※
HDMI MN8647781(RX) RESET control pin
39 P55 778_2_HINT I -
-
Z - HDMI MN8647781(RX) HDMI INT input pin
40 P54 778_3_RST O C
Pd
Z
※
HDMI MN8647781(RX) RESET control pin
41 BCLK/P53 778_3_HINT I -
-
Z - HDMI MN8647781(RX) HDMI INT input pin
42 P52 IP_RST O C
Pd
Z L HDMI ADV8003 RESET control pin
43 P51 DE_RST O C
Pd
Z L HDMI ADV7850 RESET control pin
44 P50 DE_INT I -
-
Z - HDMI ADV7850 HDMI INT input pin
45 PC7/TXD8/SSDA8 UB I -
Pd
Z - Unused
46 PC6/RXD8/SSCL8 HINSELA O C
-
Z -
TC74VHC4051AFT control pin. (Control the detection
of HDMI 5V INPUT for CEC STANDBY. )
47 PC5/SCK8 HINSELB O C
-
Z -
TC74VHC4051AFT control pin. (Control the detection
of HDMI 5V INPUT for CEC STANDBY. )
48 PC4/SCK5 HINSELC O C
-
Z -
TC74VHC4051AFT control pin. (Control the detection
of HDMI 5V INPUT for CEC STANDBY. )
49 PC3/TXD5/SSDA5 DSPMOSI O C
DA3
VPu
Z L DSP control pin (ADSP21487KSWZ-3B)
50 PC2/RXD5/SSCL5 DSPMISO I -
DA3
VPu
Z - DSP control pin (ADSP21487KSWZ-3B)
51 PC1/SCK5 DSPICLK O C
DA3
VPu
Z L DSP control pin (ADSP21487KSWZ-3B)
52 PC0 DA_POWER O C
-
Z L
DIGITAL AUDIO POWER SUPPLY (DA3.3V & DA1.1V)
control pin.(ON:H)
53 PB7/TXD9/SSDA9 AVSDA I/O C
DV3
VPu
O/L L VIDEO I2C- ADV8003/ADV7850
54 PB6/RXD9/SSCL9 AVSCL I/O C
DV3
VPu
O/L L VIDEO I2C- ADV8003/ADV7850
55 PB5/SCK9
CEC_
POWER
O C
-
Z
※
HDMI CEC POWER SUPPLY control pin
(CEC5V,CEC3.3V,CEC1.8V)
56 PB4 DV_POWER1 O C
-
Z L
Digital VIDEO POWER SUPPLY control pin
(DV5V,DV3.3V)
57 PB3/SCK8 DV_POWER2 O C
-
Z - Digital VIDEO POWER SUPPLY control pin (DV1.8V)
58 PB2 H5VDET I -
-
Z - HDMI INPUT 5V (for EDID / HOT PLUG) detection pin
59
PB1/TXD6/SSDA6/IRQ4-
DS
778_3_HAINT I -
-
Z - HDMI MN8647781(RX) Audio INT input pin
60 VCC VCC - -
-
- - +3.3V
61 PB0/RXD6/SSCL6 NC O C
-
Z - NC
62 VSS VSS - -
-
- - GND
63 PA7 HPD8 O C
-
Z L HPD8 output pin
64 PA6 HPD7 O C
-
Z L HPD7 output pin
65 PA5 HPD6 O C
-
Z L HPD6 output pin
66
PA4/TXD5/SSDA5/IRQ5-
DS
HPD5 O C
-
Z L HPD5 output pin
67
PA3/RXD5/SSCL5/IRQ6-
DS
HPD4 O C
-
Z L HPD4 output pin
68 PA2/RXD5/SSCL5 HPD3 O C
-
Z L HPD3 output pin
69 PA1/SCK5 HPD2 O C
-
Z L HPD2 output pin
70 PA0 HPD1 O C
-
Z L HPD1 output pin
71 PE7/IRQ7/AN015 APLDCK O C
-
Z L A.PLD control pin
72 PE6/IRQ6/AN014 APLDCS O C
-
O/L L A.PLD control pin
73 PE5/IRQ5/AN013 APLDDI O C
-
Z L A.PLD control pin
74 PE4/AN012 SUB_TCK O C
Pd
Z L A.PLD/V.PLD rewriting pin(JTAG)
75 PE3/AN011 SUB_TDI O C
DA
3.3Pu
Z L A.PLD/V.PLD rewriting pin(JTAG)
76
PE2/RXD12/SSCL12/
IRQ7-DS/AN010
SUB_TDO I -
-
Z L A.PLD/V.PLD rewriting pin(JTAG)
77
PE1/TXD12/SSDA12/
AN009
SUB_TMS O C
DA
3.3Pu
Z L A.PLD/V.PLD rewriting pin(JTAG)
78 PE0/SCK12/AN008 DACRST1 O C
-
Z L D/A converter control pin(PCM1690)
79 PD7/IRQ7 NC O C
-
Z - NC
80 PD6/IRQ6 DACMC O C
-
Z L D/A converter control pin(PCM1690)
81 PD5/IRQ5 DACMD O C
-
Z L D/A converter control pin(PCM1690)
82 PD4/IRQ4 DACMS1 O C
-
Z L D/A converter control pin(PCM1690)
83 PD3/IQR3 NC O C
-
Z - NC
84 PD2/IRQ2 DSP1RST O C
-
Z L DSP(ADSP21487KSWZ-3B) reset output pin (Reset : L)
165

Denon AVR-X3100W Specifications

General

Receiver type	Surround
Speaker selector	A+B
Audio output channels	7.1 channels
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	180 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	8
Remote control in	1
Composite video in	3
Multichannel audio input type	Terminals
Component video (YPbPr/YCbCr) in	2
12V trigger	Yes
Speakers connectivity type	-
Audio formats supported	AAC, AIFF, FLAC, MP3, WAV, WMA
Supported radio bands	FM
Product color	Black
Audio decoders	Dolby Digital EX, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:X, DTS-ES, DTS-HD Master Audio
Volume control	Rotary
Apple docking compatibility	Not supported
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W

Weight and Dimensions

Depth	388 mm
Width	434 mm
Height	167 mm
Weight	10700 g
