Denon AVR-X3100W Service Manual

Error
Code
Details of Error code Display Coping strategies
12
Abnormal data in Update Packet
received from CX870 (PacketNo-
Error).
U p d a t i n g f a i l 1 2
Turn on the power again. Update will
start automatically.
13
Block Erase failed before rewriting
Main.
E r a s e f a i l 1 3
Turn on the power again. Update will
start automatically.
14
Block Write failed while rewriting
Main.
U p d a t i n g f a i l 1 4
Turn on the power again. Update will
start automatically.
15
Error in Verify after rewriting Main
(Check SumError).
U p d a t e C h e c k N G 1 5
Turn on the power again. Update will
start automatically.
16
Setup failure of the transfer
method of XModem.
U p d a t i n g f a i l 1 6
Check the network connection. Update
in an environment where there is a
small network load.
20
SBL Mode after IP Address acqui-
sition failure (AutoIP).
C o n n e c t i o n F a i l 2 0
Check the network connection. Update
in an environment where there is a
small network load.
21
SBL Mode after IP Address acqui-
sition failure (Time Out).
C o n n e c t i o n F a i l 2 1
Check the network connection. Update
in an environment where there is a
small network load.
22
Login incorrect notication SBL
Mode after DPMS connection.
L o g i n f a i l e d 2 2
Initialize the unit and try updating
again.
Update in an environment where there
is a small network load.
23
Server congestion notication SBL
Mode after DPMS connection.
S e r v e r i s b u s y 2 3
Update in an environment where there
is a small network load.
24
Connection failure notication
SBL Mode after DPMS connection.
C o n n e c t i o n F a i l 2 4
Check the network connection. Update
in an environment where there is a
small network load.
25 Failed to transit to SBL Mode.
C o n n e c t i o n F a i l 2 5
Initialize the unit and try updating
again.
26
Error in Firmware Download (Time
Out).
D o w n l o a d f a i l 2 6
Check the network connection. Update
in an environment where there is a
small network load.
27
Failed to write to EEPROM after
SBL Mode.
D o w n l o a d f a i l 2 7
Initialize the unit and try updating
again.
36
Login incorrect notication DPMS
connection.
L o g i n f a i l e d 3 6
Update in an environment where there
is a small network load.
37
Server congestion notication by
DPMS connection.
S e r v e r i s b u s y 3 7
Update in an environment where there
is a small network load.
38
Connection failure notication
DPMS connection.
C o n n e c t i o n F a i l 3 8
Check the network connection. Update
in an environment where there is a
small network load.
81

Denon AVR-X3100W Specifications

General

Receiver type	Surround
Speaker selector	A+B
Audio output channels	7.1 channels
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	180 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	8
Remote control in	1
Composite video in	3
Multichannel audio input type	Terminals
Component video (YPbPr/YCbCr) in	2
12V trigger	Yes
Speakers connectivity type	-
Audio formats supported	AAC, AIFF, FLAC, MP3, WAV, WMA
Supported radio bands	FM
Product color	Black
Audio decoders	Dolby Digital EX, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:X, DTS-ES, DTS-HD Master Audio
Volume control	Rotary
Apple docking compatibility	Not supported
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W

Weight and Dimensions

Depth	388 mm
Width	434 mm
Height	167 mm
Weight	10700 g
