Denon AVR-X3100W Service Manual

Error
Code
Details of Error code Display Coping strategies
5B
NACK received in response or no
response from Sub for L com-
mand.
U p d a t i n g f a i l 5 B
Turn on the power again. Update will
start automatically.
5C
No Update Packet received from
CX870 (Time Out).
U p d a t i n g f a i l 5 C
Turn on the power again. Update will
start automatically.
5D
Abnormal data in Update Packet
received from CX870 (CRCError).
U p d a t i n g f a i l 5 D
Turn on the power again. Update will
start automatically.
5E
Abnormal data in Update Packet
received from CX870 (PacketNo-
Error).
U p d a t i n g f a i l 5 E
Turn on the power again. Update will
start automatically.
5F
Setup failure of the transfer
method of XModem.
U p d a t i n g f a i l 5 F
Turn on the power again. Update will
start automatically.
60
NACK received in response or no
response from Sub for "P" com-
mand.
U p d a t i n g f a i l 6 0
Turn on the power again. Update will
start automatically.
61
Mismatched Check Sum in re-
sponse or no response from Sub
for "I" command.
U p d a t e C h e c k N G 6 1
Turn on the power again. Update will
start automatically.
62
Failed to start up Sub in Power On
sequence during Update.
U p d a t i n g f a i l 6 2
Turn on the power again. Update will
start automatically.
80
Write Enable Latch Bit not set in
Read after issuing WREN com-
mand.
U p d a t i n g f a i l 8 0
Turn on the power again. Update will
start automatically.
81
Block Erase failed in Read after
issuing BE command.
U p d a t i n g f a i l 8 1
Turn on the power again. Update will
start automatically.
82
No Update Packet received from
CX870 (Time Out).
U p d a t i n g f a i l 8 2
Turn on the power again. Update will
start automatically.
83
Abnormal data in Update Packet
received from CX870 (CRCError).
U p d a t i n g f a i l 8 3
Turn on the power again. Update will
start automatically.
84
Abnormal data in Update Packet
received from CX870 (PacketNo-
Error).
U p d a t i n g f a i l 8 4
Turn on the power again. Update will
start automatically.
85
Setup failure of the transfer
method of XModem.
U p d a t i n g f a i l 8 5
Turn on the power again. Update will
start automatically.
86
Mismatched Check Sum in Check
Sum comparison after rewriting.
U p d a t i n g f a i l 8 6
Turn on the power again. Update will
start automatically.
A0
IP Address acquisition failure
(AutoIP).
C o n n e c t i o n F a i l A 0
Check the network connection. Update
in an environment where there is a
small network load.
83
