Denon AVR-X3300W Service Manual

1. Version Display Mode
1.1. Actions
Version information is displayed when the device is started in this mode.
1.2. Starting up
While holding down buttons "
DIMMER
" and "
STATUS
" simultaneously, press the power button to turn
on the power.
then press the "
STATUS
" button to display the information in section 1.3 on the display.
b
The version list is also displayed on GUI while the version is displayed on the display.
1.3. Display Order
Error information(See "1.4. Error display") →
q
Model destination information →
w
Serial Number
→
e
Firmware Package →
r
Main µ-com →
t
Main 1st Boot Loader →
y
DSP ROM
→
u
Audio PLD →
i
Video PLD →
o
GUI SFLASH →
Q0
Ethernet 1st Boot Loader, Hardware ID
→
Q1
Ethernet 2nd Boot Loader, Rhapsody Flag →
Q2
Ethernet IMAGE
→
Q3
Network MAC ADDRESS information →
Q4
Bluetooth MAC Address information
q
Model destination information :
AVR-X3300W \\\
\
： Region (E3, E2, E1C, JP)
w
Serial Number :
S/N. **********
e
Firmware Package :
Package :****
r
Main µ-com :
Main :%%%%####*
%
： Main version,
#
： Sub version
t
Main 1st Boot Loader :
Main FBL :**.**
y
DSP ROM :
DSP :**.**
u
Audio PLD :
Audio PLD:**.**
i
Video PLD :
Video PLD:**.**
o
GUI SFLASH :
GUI :@@$\****
@
： Model code,
$
： Brand code (Non=0, De=1, Mz=2, Mc=3),
\
： Region code (E3=1, E2=2, E1C=5, JP=4, ALL=0),
*
： version
Q0
Ethernet 1st Boot Loader, Hardware ID :
Ethernet FBL
Press "
STATUS
" button.
******-**
Q1
Ethernet 2nd Boot Loader, Rhapsody Flag :
Ethernet SBL
Press "
STATUS
" button.
B************-0A
Q2
Ethernet IMAGE :
Ethernet IMG
Press "
STATUS
" button.
I************
Q3
Network MAC ADDRESS information：
*NET MAC Address
Press "
STATUS
" button.
******-******
Q4
Bluetooth MAC ADDRESS information：
*BT MAC Address
Press "
STATUS
" button.
******-******
116
Caution in
servicing
Electrical Mechanical Repair Information Updating
