Denon AVR-X3300W Service Manual

PACKING
PACKING
※Parts indicated b
y
"ns
p
"on this table cannot be su
pp
lied. Part indicated b
y
"
@
" mark is not illustrated in the ex
p
loded vie
w
※The
p
arts listed below are onl
y
for maintenance. Therefore the
y
mi
g
ht differ from the
p
arts used in the unit in a
pp
earances or dimension
s
NOTE:The symbols in the column Remarks indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model JP : Japan model
BK : Black model SP : Premium Silver model
REF No. Part No. Part Name Remarks Q'ty New Ver
2 nsp PE,SHEET Warning 28 Language NITRON 750*1460 VINA/SET 6327040059000V 1
3 30701016900AD REMOCON AVRX2100(DENON) RC-1192 HB8101P 8300119201020S 1
4-1 963533103460S CUSHION,SNOW AVRX3300WBKE3(DENON) EPS WH 55/FRONT TOP 6230214244000V 1 *
4-2 963533103470S CUSHION,SNOW AVRX3300WBKE3(DENON) EPS WH 55/FRONT BOTTOM 6230214254000V 1 *
4-3 963533103450S CUSHION,SNOW AVRX3300WBKE3(DENON) EPS WH 55/REAR TOP 6230214264000V 1 *
4-4 963533103480S CUSHION,SNOW AVRX3300WBKE3
(
DENON
)
EPS WH 55배/REAR BOTTOM 6230214274000
V
1*
5 nsp BATTERY,DRY R03 AAA SIZE 1.5V G670001R50243S 2
6 32401000800AD MIC CONDENSER AUTO SETUP MIC ACM1HB M040000310080S 1
7 963531105940S BOX,GIFT AVRX3300WBKE3BW BC FLUTE 515*477*238 E3 6007213240000V 1 *
7 963531105920S BOX,GIFT E2 6007213240010V 1 *
7 963531105930S BOX,GIFT E1C 6007213240020V 1 *
8 nsp LABEL CONTROL AVR-X3300W (E3) CONTROL/Box 2EA+SERIAL 1EA attach E3 5507000021100V 1 *
8 nsp LABEL CONTROL E2 5507000021110V 1 *
8 nsp LABEL CONTROL E1C 5507000021120V 1 *
9 nsp WARRANTY CARD E1C 5727000000441S 1
10 nsp TAPE PACKING TAPE PACKING W:50(NEW TAPE:4.5kgf) 1220210772000S 1.5
12 nsp DTS READY LABEL AVR/NR/SR DTS ready sticker - BOX ATTACH 5507000019900S 2
13 42911002000AS STAND ASSY AVRX2100WBKE3(DENON) (CPG1A1021ZA)PAPER A3/MIC 4148210170000S 1
14 nsp LABEL MIC AVR_NR_SR / MIC 5507000019510S 1
! 15 963611501070S CORD ASSY 13A/125V SP14/IS14A SJT 16AWG*2 1.8M WH-STRAP E3 L068125130220S 1
! 15 90M-ZC000600R CORD ASSY E2 L068250160170S 1
! 15 963611501100S CORD ASSY E1C L068250100220S 1
16 nsp BUSHING E2, E1C 2410040353010S 1
17 nsp LABEL AVRX3300W/BKE3_QR CODE E3 5507000021160CN 1 *
A4 SIZE POLY BAG ASSY
nsp NOTE ON RADIO AVR-S920/X2200/X3300(ALL)Notes on RADIO Sheet (A3) 5227000004131V 1 *
nsp Cautions on Using Batteries sheet E2 5227000004160V 1 *
nsp SAFETY INST. AVR-S910/X2200(E3) Safety Instruction (A3) E3 5227000003551S 1 *
nsp SAFETY INST. E2 5227000003571S 1 *
nsp SAFETY INST. E1C 5227000003620S 1
nsp
WARRANTY CARD(E3 ONLY) Denon(E3)warranty card WhitePaper No.54311000370AD
E3 5727000003040S 1
nsp INSERTION SHEET(E3 ONLY) DENON North america only /INSERTION E3 5227000008660S 1
963544104550S SPK WIRE LABEL AVRS910_X2200/SR5010/NR1606(ALL) SPEAKER WIRE 5507000018970S 1
nsp PASS CARD E1C 5777000000290S 1
963116100550S
ANTENNA WIRE(FM) ANT FM NTSC CABLE 1500MM BK1007#22 WH-STARP LABEL
E605010140050S 1
963116100560S
ANTENNA LOOP(AM) ANT AM LOOP STAND 9.5UH BK1691#24 WH-STRAP LABEL
E601019000050S 1
nsp ANTENNA ISORATOR(E1C ONLY) E1C L170200060010S 1
A5 SIZE POLY BAG ASSY
nsp SPOTIFY INSERTION SHEET AVR/NR/SR SPOTIFY insertion Sheet(A4) E3, E2 5227000003950V 1
nsp SHEET DTS READY Buyer No.54311045800AD AVRX2200W(E3)DTS E3 5227000003870S 1
nsp SHEET DTS READY E2 5227000003860S 1 *
nsp SHEET DTS READY E1C 5227000003970S 1 *
nsp
UPDATE INSERTION SHEET AVRS920/X2300/X3300(E3) Firmware Update insertion
E3 5227000004140V 1
54111137800AD GETTING STARTED AVR-X3300(E3) Quick Manual / No. E3 5707000010920V 1 *
54111137900AD GETTING STARTED E2 5707000010930V 1 *
54111138000AD GETTING STARTED E1C 5707000010940V 1 *
39

Denon AVR-X3300W Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Pre-out channels	7.2
Pre-out connectivity	Yes
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.05 %
Power output per channel (1KHz@6 Ohm)	180 W
Power output per channel (20-20KHz@8 Ohm)	105 W
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W
Product color	Black
Audio decoders	DTS-HD, DTS-HD Master Audio, Dolby TrueHD
Multi-Zone quantity	2
Apple docking compatibility	-
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
HDMI in	8
Audio (L/R) in	5
Remote control in	1
Composite video in	3
Composite video out	0
Connectivity technology	Wired
Speakers connectivity type	Clamp terminals
Audio formats supported	AAC, AIFF, ALAC, DSD, FLAC, MP3, WAV, WMA

Weight and Dimensions

Depth	389 mm
Width	434 mm
Height	167 mm
Weight	10800 g
