Denon AVR-X3300W Service Manual

3-5. TUNER STEP mode (E3 / E2 only) 3-6. Remote ID Setup Mode
3-5.1. Actions
This is a special mode for enabling reception STEP of the ANALOG TUNER to be changed.
3-5.2. Starting up
2. While holding down buttons "
ZONE2 SOURCE
", "
DIMMER
" and "
STATUS
" simultaneously, press the
power button to turn on the power.
Select the "
5. TUNER FRQ SET
" using the "
TUNER PRESET CH+
" button, then press the "
STATUS
"
button then to conrm.
3-5.3. Displays
Start up this unit in TUNER STEP mode, select the desired option using the "
TUNER PRESET CH+/-
"
button, then enter using the "
STATUS
" button.
The following information is displayed in the following order.
(a) AM9 kHz / FM50 kHz is selected
< AM9/FM50 >
"
TUNER PRESET CH+
" "
TUNER PRESET CH-
"
(b) AM10 kHz / FM200 kHz is selected
< AM10/FM200 >
"
STATUS
"
(c) Press the power button to turn off the power.
(d) Press the power button to turn on the power.
3-6.1. Actions
This function allows only the desired AV receiver to be operated if multiple DENON AV receivers are
used in the same room.
3-6.2. Starting up
2. While holding down buttons "
ZONE2 SOURCE
", "
DIMMER
" and "
STATUS
" simultaneously, press the
power button to turn on the power.
Select the "
6. REMOTE ID
" using the "
TUNER PRESET CH+
" button, then press the "
STATUS
" button
then to conrm.
3-6.3. Operations
(a) When Remote ID Setup mode is activated, the following message is displayed.
REMOTE ID ?
(b) Press the desired "
QUICK SELECT 1 - 4
" button.
Button Display
QUICK SELECT 1
REMOTE ID 1
QUICK SELECT 2
REMOTE ID 2
QUICK SELECT 3
REMOTE ID 3
QUICK SELECT 4
REMOTE ID 4
(c) Press the power button to turn off the power.
(d) Press the power button to turn on the power.
b
Only "
QUICK SELECT 1 - 4
" and the POWER button on the unit can be used in Remote ID Setup
Mode.
b
The remote ID of the remote control supplied with this unit cannot be changed.
NOTE :
If the ID of the unit and remote control do not match, "
AVAMP
z
" appears on the display of the unit
when the remote control is used
(
z
: own remote control ID).
124
Caution in
servicing
Electrical Mechanical Repair Information Updating

Denon AVR-X3300W Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Pre-out channels	7.2
Pre-out connectivity	Yes
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.05 %
Power output per channel (1KHz@6 Ohm)	180 W
Power output per channel (20-20KHz@8 Ohm)	105 W
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W
Product color	Black
Audio decoders	DTS-HD, DTS-HD Master Audio, Dolby TrueHD
Multi-Zone quantity	2
Apple docking compatibility	-
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
HDMI in	8
Audio (L/R) in	5
Remote control in	1
Composite video in	3
Composite video out	0
Connectivity technology	Wired
Speakers connectivity type	Clamp terminals
Audio formats supported	AAC, AIFF, ALAC, DSD, FLAC, MP3, WAV, WMA

Weight and Dimensions

Depth	389 mm
Width	434 mm
Height	167 mm
Weight	10800 g
