Denon AVR-X3300W Service Manual

DISASSEMBLY
Flowchart
• Remove each part following the ow below.
• Reassemble the removed parts in the reverse order.
• Read "SAFETY PRECAUTIONS" before reassembling the removed parts.
• If wire bundles are removed or moved during adjustment or part replacement, reshape the wires after completing the work. Failure to shape the wires correctly may cause problems such as noise.
• See "EXPLODED VIEW"
FRONT PANEL ASSY
DISASSEMBLY
2. FRONT PANEL ASSY
and "EXPLODED VIEW"
F_HDMI PCB
Ref. No. of EXPLODED VIEW : P 1
FRONT PCB
Ref. No. of EXPLODED VIEW : P 3
FUNCTION PCB
Ref. No. of EXPLODED VIEW : P 4
CNT PCB
Ref. No. of EXPLODED VIEW : P 5
FHDMI CABLE PCB
Ref. No. of EXPLODED VIEW : P 6
TOP_GUIDE PCB
Ref. No. of EXPLODED VIEW : P 18
COVER
TOP COVER
TRANS
DISASSEMBLY
9. TRANS
and "EXPLODED VIEW"
POWER TRANS
Ref. No. of EXPLODED VIEW : 13
RADIATOR ASSY
DISASSEMBLY
3. RADIATOR ASSY
and "EXPLODED VIEW"
AMP PCB
Ref. No. of EXPLODED VIEW : P 7
GUIDE_L PCB
Ref. No. of EXPLODED VIEW : P 17
HDMI PCB
DISASSEMBLY
4. HDMI PCB
and "EXPLODED VIEW"
HDMI PCB
Ref. No. of EXPLODED VIEW : P 13
VIDEO PCB
DISASSEMBLY
5. VIDEO PCB
and "EXPLODED VIEW"
VIDEO PCB
Ref. No. of EXPLODED VIEW : P 19
INPUT PCB
DISASSEMBLY
6. INPUT PCB
and "EXPLODED VIEW"
INPUT PCB
Ref. No. of EXPLODED VIEW : P 12
MAIN PCB
DISASSEMBLY
7. MAIN PCB
and "EXPLODED VIEW"
MAIN PCB
Ref. No. of EXPLODED VIEW : P 9
SIDE_CNT PCB
Ref. No. of EXPLODED VIEW : P 10
FRONT CNT PCB
Ref. No. of EXPLODED VIEW : P 11
AUDIO_IN PCB
Ref. No. of EXPLODED VIEW : P 12
RS232C PCB
Ref. No. of EXPLODED VIEW : P 14
RS_CNT PCB
Ref. No. of EXPLODED VIEW : P 15
SMPS PCB
DISASSEMBLY
8. SMPS PCB
and "EXPLODED VIEW"
SMPS PCB
Ref. No. of EXPLODED VIEW : P 8
63
Caution in
servicing
Electrical Mechanical Repair Information Updating

Denon AVR-X3300W Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Pre-out channels	7.2
Pre-out connectivity	Yes
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.05 %
Power output per channel (1KHz@6 Ohm)	180 W
Power output per channel (20-20KHz@8 Ohm)	105 W
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W
Product color	Black
Audio decoders	DTS-HD, DTS-HD Master Audio, Dolby TrueHD
Multi-Zone quantity	2
Apple docking compatibility	-
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
HDMI in	8
Audio (L/R) in	5
Remote control in	1
Composite video in	3
Composite video out	0
Connectivity technology	Wired
Speakers connectivity type	Clamp terminals
Audio formats supported	AAC, AIFF, ALAC, DSD, FLAC, MP3, WAV, WMA

Weight and Dimensions

Depth	389 mm
Width	434 mm
Height	167 mm
Weight	10800 g
