Denon AVR-X3300W Service Manual

POWER DIAGRAM
VCC
OPEN
NET2.5V
NET1.2V
NET1.8V
CEC1.1V1
CEC1.1V
DV1.8V
DA1.0V
CEC1.1V2
D3.3V
CEC3.3V
TPS562200
TPS562200
TPS563200
TPS563200
TPS563200
TPS563200
TPS563200
KIA7905PI
KIA7805API
FDC608PZ
FDC608PZ
BD82065FVJ-E2
AP7361-ADJ
JUMPER
PQ120DNA
AP7361-ADJ
KIA7805API
TPS562200
TPS563200
TPS563200
KIA7808API
KIA7908PI
FDC608PZ
FDC608PZ
FDC608PZ
FDC608PZ
3
4 1
2
2.22
0.183A
1.5A
1.5A
1.12A
2.3A
FRONT-USB
REMOTE3.3V
D5V
VKK
A.V-5.0V
TUNER_+5V
A.V+5.0V
A-7.0V
A+7.0V
MAIN -B
MAIN +B
RELAY
5.2V
0.3A
0.235
1.5A
1.8A
MUTE3.3V
STBY3.3V
FL AC (F1)
FL AC (F2)
S1(AMP +B)
E_POWER4
U1071
CEC_POWER
U1063
U1064
U1069
U1068
D5V_POWER
CEC_POWER
Q1069
Q1077
E_POWER1
DA_POWER
DV_POWER1
CPU_POWER
( PCM9211/ PCM1690/TC74VHCU04FT / LC89091 / 5M240ZT100C5N )
MAIN TRANS
S2(+8V,-8V)
U1070
U1072
E_POWER2
D5V_POWER
U1065
CEC_POWER
CEC_POWER
DV_POWER2
DA_POWER2
U1066
U1067
E_POWER3
DA_POWER
Q1071
Q1067
Q1063
CEC_POWER
DV_POWER1
REMOTE_POWER
+3.3V ( PCM5100*2 )
DA+5.0V ( PCM1690 / PCM9211 )
AC CORD
CEC_POWER2
DA1.8V (5M240ZT100C5N)
DA1.0V (CS49844A)
DV5V (ADV7850/ADV8003)
MAIN PWR ON
NET1.2V (CY920)
NET2.5V (CY920)
CEC1.1V1(HDMI SW1)
NET1.8V (CY920)
CEC1.1V2(HDMI SW2)
CEC1.1V(HDMI TX)
NET3.3V (CY920 / MFI337S3959 / MX25L25635FMI-10G )
DV1.8V (ADV8003-8B/ADV7850 / A3R12E40CBF-8E*2 )
DA3.3V ( CS49844A / W9864G6KH-5 / MX25L6406EM21-12G / SN74LVC244PWR )
DV3.3V (ADV8003-8B/ADV7850 / MX25L12835FMI-10G / EPM570F256C4N )
CEC3.3V(HDMI SW1/HDMI SW2/HDMI TX / AD8195ACPZ )
CEC5V(HDMI SW1/HDMI SW2/HDMI TX / AD8195ACPZ )
SWM3.3V (FLT)
M3.3V (CPU / R1EX24128BSASO1 / MC14094BDTR2G*5 )
TRIGGER +12V
AVR-X3300 VCC DIAGRAM
50
Caution in
servicing
Electrical Mechanical Repair Information Updating

Denon AVR-X3300W Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Pre-out channels	7.2
Pre-out connectivity	Yes
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.05 %
Power output per channel (1KHz@6 Ohm)	180 W
Power output per channel (20-20KHz@8 Ohm)	105 W
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W
Product color	Black
Audio decoders	DTS-HD, DTS-HD Master Audio, Dolby TrueHD
Multi-Zone quantity	2
Apple docking compatibility	-
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
HDMI in	8
Audio (L/R) in	5
Remote control in	1
Composite video in	3
Composite video out	0
Connectivity technology	Wired
Speakers connectivity type	Clamp terminals
Audio formats supported	AAC, AIFF, ALAC, DSD, FLAC, MP3, WAV, WMA

Weight and Dimensions

Depth	389 mm
Width	434 mm
Height	167 mm
Weight	10800 g
