Denon AVR-X3300W Service Manual

EXPLODED
EXPLODED
※Parts indicated b
y
"ns
p
"on this table cannot be su
pp
lied. Part indicated b
y
"
@
" mark is not illustrated in the ex
p
loded view.
※The
p
arts listed below are onl
y
for maintenance. Therefore the
y
mi
g
ht differ from the
p
arts used in the unit in a
pp
earances or dimensions.
NOTE:The symbols in the column Remarks indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model JP : Japan model
BK : Black model SP : Premium Silver model
REF No. Part No. Part Name Remarks Q'ty New Ver
PCB GROUP
P12 nsp INPUT PCB 7028080051010 1 *
P12-P1 - F_HDMI PCB 7028080052010 1 *
P9 nsp MAIN PCB 70280796210A0 1 *
P9-P15 - RS_CNT PCB 70280796220A0 1 *
P9-P17 - GUIDE_L PCB 70280796230A0 1 *
P3 nsp FRONT PCB 70280796310A0 1 *
P3-P4 - FUNCTION PCB 70280796320A0 1 *
P3-P5 - CNT PCB 70280796330A0 1 *
P3-P18 - TOP_GUIDE PCB 70280796340A0 1 *
P3-P6 - FHDMI CABLE PCB 70280796350A0 1 *
P3-P14 - RS232 PCB 70280796360A0 1 *
P7 nsp AMP PCB 70280796710A0 1 *
P19 nsp VIDEO PCB 7028080041010 1 *
P19-P11 - FRONT CNT PCB 7028080042010 1 *
P8 nsp SMPS PCB 7028080061010 1 *
P13 9U6391027100S
HDMI PCB
See PROCEDURE AFTER REPLACING THE PCB.
7025HK1510017 1 *
P10 nsp SIDE_CNT PCB 7028080091010 1 *
P20 963189101650S
MODULE CY920-C (5GHz)
See PROCEDURE AFTER REPLACING THE U-COM, ETC.
8952230000010 1 *
OTHER PARTS GROUP
P1-1 963606502960S
CABLE,FLAT CARD SHIELD 1.0MM 1.0*23*280*A(4/4/8/8)*(0.035*0.65) (AC+AL) SHIELD
N713232812480S 1 *
P3-1 963606502970S
CABLE,FLAT CARD SHIELD 1.0MM 1.0*40*200*A(4/4/8/8)*(0.035*0.65) AL SHIELD
N713402012480S 1 *
P3-2 nsp RING,TER WIRE 120MM/1P ST710094-3=B1813TOP-2 1617#22 SJ 8410121010290S 1 *
P7-1_CN4212 - CN,WIRE 160MM/10P 20010HS-10=YBNH200-10 UL2651#26 SJ L026161102620S 1 *
P7-2_CN4213 - CN,WIRE ASSY 260MM/5P YMH025-05R=YBNH250-05 UL2651#22 SJ L028261050080S 1 *
P7-3_CN4211 - CN,WIRE ASSY 300MM/3P YMH025-03R=YBNH250-03 UL2651#22 SJ L028301030130S 1 *
P7-4_CN4200 - CN,WIRE ASSY 240MM/13P 20010HS-13=YBNH200-13 UL2651#26 SJ L028241130070S 1 *
P8-1_C4162 - C,ELECT GE 105C 5600UF-M/6.3V,12.5*35 NXA SY D041562081001S 1
P8-1_C4164 - C,ELECT GE 105C 5600UF-M/6.3V,12.5*35 NXA SY D041562081001S 1
P8-1_C4165 - C,ELECT GE 105C 5600UF-M/6.3V,12.5*35 NXA SY D041562081001S 1
P8-2_C4151 - C,ELECT GE 105C 220UF-M/200V,16*31.5 BULK 5.0MC NHA SY E3 D04122108G010S 1 *
P8-2_C4151 - C,ELECT 100UF-M/400V,18*31 E2, E1C D04110108K000S 1
! P8-3_T4140 - TRANS,SWITCHING EER2834 SW TRANSFORMER (AVR-X3300) E060283405540V 1 *
P8-4_BKT4144 - SHIELD AVRE400BKE3(DENON) SPTE 0.3T /CASE 3070210596100S 1
P9-1_C4052 - C,ELECT GE 85C 12000UF-M/71V,35*60 D040123089550S 1
P9-1_C4054 - C,ELECT GE 85C 12000UF-M/71V,35*60 D040123089550S 1
P9-2_C4065 - C,ELECT GE 85C 6800UF-M/25V,16*31.5 BULK 5.0MC MHA SY D040682084080S 1
P9-2_C4067 - C,ELECT GE 85C 6800UF-M/25V,16*31.5 BULK 5.0MC MHA SY D040682084080S 1
P9-3_JACK4000 - TER,BOARD SCREW 2P JB207-F02R3BY-A(RD,BK) G611207F02RAYS 1
P9-3_JACK4001 - TER,BOARD SCREW 2P JB207-F02R3BY-A(RD,BK) G611207F02RAYS 1
P9-3_JACK4002 - TER,BOARD SCREW 2P JB207-F02R3BY-A(RD,BK) G611207F02RAYS 1
P9-3_JACK4003 - TER,BOARD SCREW 2P JB207-F02R3BY-A(RD,BK) G611207F02RAYS 1
P9-3_JACK4004 - TER,BOARD SCREW 2P JB207-F02R3BY-A(RD,BK) G611207F02RAYS 1
P9-3_JACK4005 - TER,BOARD SCREW 2P JB207-F02R3BY-A(RD,BK) G611207F02RAYS 1
P9-3_JACK4006 - TER,BOARD SCREW 2P JB207-F02R3BY-A(RD,BK) G611207F02RAYS 1
P12-1_JK4200_4 - TER,RCA 4PIN RCA-405B-04(WH,WH,RD,RD)-YUQIU G602405B0400YS 1
P12-1_JK4201_4 - TER,RCA 4PIN RCA-405B-04(WH,WH,RD,RD)-YUQIU G602405B0400YS 1
P12-1_JK4202_4 - TER,RCA 4PIN RCA-405B-04(WH,WH,RD,RD)-YUQIU G602405B0400YS 1
P12-1_JK4205_4 - TER,RCA 4PIN RCA-405B-04(WH,WH,RD,RD)-YUQIU G602405B0400YS 1
P12-2_JK4203_4 - TER,RCA 4PIN RCA-405B-55(WH,WH,RD,BK)-YUQIU G602405B5500YS 1
P12-3_JK4204_1 - TER,RCA 1PIN RCA-107A(BK) G600107A0000YS 1
P13-1_K1002 - TER,RCA 2PIN RCA-206A-02 NI SHIELD(ORANGE,ORANGE) G601206A0200YS 1
P13-2_CN4141 - CN,WIRE 160MM/6P YMH025-06R=YBNH250-06 UL2651#22 TUBE SJ L026161060180S 1 *
P13-3_CN404 - CN,WIRE 150MM/7P 20010HS-07=YBNH200-07 UL2651#26 SJ L026151070070S 1 *
P13-4_CN4402 - CN,WIRE ASSY 440MM/6P 20010HS-06=YBNH200-06 2725#24,28 SH SJ L028441060010S 1 *
P19-1_JACK5000 - TER,RCA 2PIN RCA-206B-01(YL,YL) G601206B0100YS 1
P19-2_JACK5004 - TER,RCA 1PIN RCA-107AY(YL) G600107AY000YS 1
P19-3_JACK5001 - TER,RCA 3PIN RCA-303B1-08(GN,BL,RD) G606303B1080YS 1
P19-3_JACK5002 - TER,RCA 3PIN RCA-303B1-08(GN,BL,RD) G606303B1080YS 1
P19-3_JACK5003 - TER,RCA 3PIN RCA-303B1-08(GN,BL,RD) G606303B1080YS 1
1 963446100850S
PANEL SUB&PLATE SUB AVRX2200WBKE3_K(DENON) ABS STAMPING A3/SUB PANEL
E3 4477213091001S 1
1 963446100860S PANEL SUB&PLATE SUB E2, E1C 4477213091011S 1
2 963412100860D KNOB VOLUME AVR2313(DENON)ABS(HB) A3/VOLUME 5080212661000S 1
3 963421100500D
BADGE IN-COMMAND AVRX2100WBKE3 GOLD(42131003300AD)/IN-COMMAND
5630210878000S 1
4 963416101340D WINDOW DISPLAY AVR-X2100(E3/K) PMMA(DC-1970WINE RED)A2/DISPLAY E3 5077213333060CN 1
4 963416101350D WINDOW DISPLAY E2, E1C 5077213333070CN 1
5 963421100510D BADGE AVRX2100WBKE3AL GOLD A3(42141003400AD)/DENON E3 5630210838200S 1
5 42151002100AD BADGE E2, E1C 5637210838000S 1
6 963402106230S PANEL FRONT AVR-X3300WBKE3(DENON) ABS BK A2 / FRONT E3 3067216461020S 1 *
6 963402106240S PANEL FRONT E2 3067216451060S 1 *
6 963402106360S PANEL FRONT E1C 3067216451070S 1 *
7 963402103910D BUTTON POWER AVRE400(DENON) ABS CAP+ABS BK/POWER 5098215301000SZ 1
8 963423100500D LENS STANDBY AVRX2100WBKE3(DENON) PMMA(MILKY)/STANDBY 3710211283100CN 1
9 963411103160D BUTTON 10KEY AVRS900WBKE3(DENON) ABS BK A3/10KEY 5090215381000CN 1
10 nsp SHEET EMI AVRX2300WBKE3 25*50*0.1T CONDUCTIVE(SHEET TAPE/EMI 1210213099000S 1
11 nsp PLATE USB AVRX2200WBKE3(DENON) SPTEt0.3 A4/USB 4470212696000SV 1
12 nsp CHASSIS MAIN AVRX3300WBKE3(DENON) SECC t1.0 A1/MAIN 3200215426000S 1 *
! 13 963101102800S MAIN TRANS AVRX3300BKE3(DENON) 120V/60Hz 96*65/MAIN SEOUL E3 8200960650170V 1 *
! 13 963101102810S MAIN TRANS E2 8200960650180V 1 *
! 13 963101102820S MAIN TRANS E1C 8200960650190V 1 *
14 nsp SUPPORTER PCB UPAF07 ABS BK/PCB 4070001601010S 2
15 00D9630214607 CUSHION FOOT AVR2106 BKE3(DENON) PORON(HH48-NITTO500)t2.5/FOOT 4050211295000S 4
16 963407100420D FOOT AVRX2100WBKE2(DENON) ABS HF A2/FOOT 4000210831000CN 4
17 nsp CHASSIS BACK AVRX3300WBKE3SECC t1.0 A1/BACK E3 3207215416000S 1 *
17 nsp CHASSIS BACK E2 3207215416100S 1 *
17 nsp CHASSIS BACK E1C 3207215416110S 1 *
18 963424100310D KNOB RING VOLUME AVR2313(DENON)ABS(HB) A3/RING VOLUME 5080212681000S 1
19 963424100330D KNOB RING FUNCTION AVR2313(DENON)ABS(HB) A3/RING FUNCTION 5080212671000S 1
20 nsp HEAT SINK ASSY AVRX3300WBKE3(DENON) AL6063S-T5(H:100)/MAIN 212821204800T2 1 *
20-1 nsp HEATSINK MAIN AVRE400BKE3(DENON) AL6063S-T5 FIN(t0.5)(t4) TiTop 212021204800TS 1
21 nsp BRACKET HEAT SINK R925 SECC 1.0T/H SINK 4010056906010S 5
22 nsp BRACKET SMPS AVR1911BKE3(DENON) SECC t1.0 A4 /SMPS 401021488600DS 1
23 963403101390S
CABINET TOP AVRX3300WBKE3(DENON) AVRX3300WBKE3SECC t0.8 SPRAY 3007211916200S 1 *
24 963412100880D KNOB FUNCTION AVR2313(DENON)ABS(HB) A3/FUNCTION 5080212651000S 1
25 nsp
CUSHION CABINET SIDE AVRE400BKE3(DENON) EVA60X60Xt4.5 BK/CABINET SIDE
4050214795000V 2
26 nsp
SHEET RATING CHASSIS AVR1913BKE3(DENON) Teflon t0.06 A4/RATING CHASSIS
1210211909000S 1
27 nsp
CUSHION SCREW AVR1911BKE3(DENON) RUBBER(HARDNESS50~70)BK/SCREW
4050213025000S 3
28 nsp LABEL POP AVR-X3300(BKE3) POP LABEL -SET- (REMOVABLE) E3 5507000021130V 1 *
28 nsp LABEL POP E2 5507000021140CN 1 *
28 nsp LABEL POP E1C 5507000021150CN 1 *
29 nsp ACETATE TAPE(10*100) AVRX2300WBKE3(DENON) 100*10/ACETATE 1220211459000V 2
30 963451101200D
SHEET RING VOLUME AVRX3300WBKE3(DENON) PET(BK)t0.25 A4/RING VOLUME
CGX1A485 1
31-0 nsp DOUBLE TAPE(W:10mm) AVRX2200WBKE3(DENON) TESA#4970 10X200 A4 1220212019000V 1
31-1 nsp DOUBLE TAPE(W:10mm) AVRX2200WBKE3(DENON) TESA#4970 10X70 A4 1220212029000V 1
37

Denon AVR-X3300W Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Pre-out channels	7.2
Pre-out connectivity	Yes
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.05 %
Power output per channel (1KHz@6 Ohm)	180 W
Power output per channel (20-20KHz@8 Ohm)	105 W
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W
Product color	Black
Audio decoders	DTS-HD, DTS-HD Master Audio, Dolby TrueHD
Multi-Zone quantity	2
Apple docking compatibility	-
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
HDMI in	8
Audio (L/R) in	5
Remote control in	1
Composite video in	3
Composite video out	0
Connectivity technology	Wired
Speakers connectivity type	Clamp terminals
Audio formats supported	AAC, AIFF, ALAC, DSD, FLAC, MP3, WAV, WMA

Weight and Dimensions

Depth	389 mm
Width	434 mm
Height	167 mm
Weight	10800 g
