EXPLODED
REF No. Part No. Part Name Remarks Q'ty New Ver
31-2 nsp DOUBLE TAPE(W:5mm) AVRX2200WBKE3(DENON) TESA#4970 5X88 A4 1220212039000V 1
32 963451101190D
SHEET RING FUNCTION AVRX3300WBKE3(DENON) PET(BK)t0.25 A4/RING FUNCTIO
CGX1A486 1
33 nsp LABEL SPOTIFY STICKER AVR/NR/SR SPOTIFY STICKER - BK E3, E2 5507000020100V 1
33 nsp LABEL SPOTIFY STICKER E1C 5507000020100V 1
34 nsp SPRING AVRX2200BKE3
DENON
SUS304 PI1.2 내경PI7.7 A4/KNOB 3720210566000V 2
35-1 nsp BRACKET AVRX3300WBKE3(DENON) SECC t1.0 A4/HDMI 4010215226100V 1
35-2 nsp TAPE (DENON) NITTO NO_156(15*70)A4/ACETATE CLOTH 1220210129300V 1 *
36 nsp BRACKET TRANS AVRX3300WBKE3(DENON) SECC T1.2/TRANS 4010216496000S 1 *
37 nsp
SPEAKER REAR SHEET AVRE400BKE3(DENON) PC(Clear T0.2) A4/SPEAKER REAR
1217212349000S 1
38 963419100910S
BUSH,WIFI ANT AVRX2100WBKE3(DENON) ABS(HB)(CMH1A357) A4/WIFI ANT
2410210161000CN 2
39 963419100920S
HOLDER,WIFI ANT AVRX2100WBKE3(DENON) ABS(HB)(CMH1A358) A3/WIFI ANT
4320211391000CN 2
40 963419100930S
SUPPORTER,WIFI ANT AVRX2100WBKE3(DENON) ABS(HB)(CMH1A360) A3/WIFI ANT
4070212301000CN 2
41-1 963116100820S WIFI ANT(300mm) RFDPA870930IMLB306 300MM WIFI ANT E600000230030S 1
41-2 963116100810S WIFI ANT(450mm) RFDPA870945IMLB305 450MM WIFI ANT E600000230040S 1
! 42 963641500550S SOCKET,POWER AC AC INLET R-301(B21) G430040807010S 1
43 nsp CUSHION FFC AVRS900WBKE3EVA(BK) HD(20~25) 17*17*5T 4050215325000S 1
44 nsp SUPPORTER PCB AVRX2300WBKE3(DENON) KANG YANG LCC-18 H18/PCB 4070212511000S 3
45 nsp
SUPPORTER BUSHING PCB NR1607U1B(MARANTZ) M3 BUSHING H=18 /PCB
4070212497000S 1
46 nsp
INSULATION HDMI PCB AVRX3300WBKE3(DENON) PC 0.175t+AL A2/HDMI PCB
1240210232000S 1 *
47 nsp
CUSHION BOTTOM TRANS AVRX3300WBKE3 Rubber(neoprene)BK 23*37*2T/TRANS BO
4050216205000V 1 *
48 nsp TAPE ACETATE(10*70) (DENON) NITTO NO_156(15*70)A4/ACETATE CLOTH 1220210129300V 3 *
49 nsp CLAMP MTG ACM393(AKAI) DARB-2(W=4.5,L=50)/WIRE(MTG) 4330000310000S 1
T1_Q410 00D9630235204 TR 2SB1647Y 130W 15A (2SD2390-Y and 2SB1560-Y is one pair parts.) J5011647Y0170S 1
T1_Q422 00D9630235204 TR 2SB1647Y 130W 15A (2SD2390-Y and 2SB1560-Y is one pair parts.) J5011647Y0170S 1
T1_Q434 00D9630235204 TR 2SB1647Y 130W 15A (2SD2390-Y and 2SB1560-Y is one pair parts.) J5011647Y0170S 1
T1_Q446 00D9630235204 TR 2SB1647Y 130W 15A (2SD2390-Y and 2SB1560-Y is one pair parts.) J5011647Y0170S 1
T1_Q458 00D9630235204 TR 2SB1647Y 130W 15A (2SD2390-Y and 2SB1560-Y is one pair parts.) J5011647Y0170S 1
T1_Q470 00D9630235204 TR 2SB1647Y 130W 15A (2SD2390-Y and 2SB1560-Y is one pair parts.) J5011647Y0170S 1
T1_Q482 00D9630235204 TR 2SB1647Y 130W 15A (2SD2390-Y and 2SB1560-Y is one pair parts.) J5011647Y0170S 1
T2_Q404 00D9630235301 TR 2SD2560Y 130W 15A (2SD2390-Y and 2SB1560-Y is one pair parts.) J5032560Y0170S 1
T2_Q416 00D9630235301 TR 2SD2560Y 130W 15A (2SD2390-Y and 2SB1560-Y is one pair parts.) J5032560Y0170S 1
T2_Q428 00D9630235301 TR 2SD2560Y 130W 15A (2SD2390-Y and 2SB1560-Y is one pair parts.) J5032560Y0170S 1
T2_Q440 00D9630235301 TR 2SD2560Y 130W 15A (2SD2390-Y and 2SB1560-Y is one pair parts.) J5032560Y0170S 1
T2_Q452 00D9630235301 TR 2SD2560Y 130W 15A (2SD2390-Y and 2SB1560-Y is one pair parts.) J5032560Y0170S 1
T2_Q464 00D9630235301 TR 2SD2560Y 130W 15A (2SD2390-Y and 2SB1560-Y is one pair parts.) J5032560Y0170S 1
T2_Q476 00D9630235301 TR 2SD2560Y 130W 15A (2SD2390-Y and 2SB1560-Y is one pair parts.) J5032560Y0170S 1
T3_Q409 963219003340S TR/GE NPN 2SC KTC3964/TO126S-BULK J502396400010S 1
T3_Q421 963219003340S TR/GE NPN 2SC KTC3964/TO126S-BULK J502396400010S 1
T3_Q433 963219003340S TR/GE NPN 2SC KTC3964/TO126S-BULK J502396400010S 1
T3_Q445 963219003340S TR/GE NPN 2SC KTC3964/TO126S-BULK J502396400010S 1
T3_Q457 963219003340S TR/GE NPN 2SC KTC3964/TO126S-BULK J502396400010S 1
T3_Q469 963219003340S TR/GE NPN 2SC KTC3964/TO126S-BULK J502396400010S 1
T3_Q481 963219003340S TR/GE NPN 2SC KTC3964/TO126S-BULK J502396400010S 1
@ nsp LABEL AVR/NR/SR DTS ready sticker - SET ATTACH 5507000019890S 1
@ nsp POLY BAG RD6108(A GROUP) 330*240*0.05 SILK JACK-HOLE 6337040062010S 1
@ nsp POLY BAG () LD 160*250 SILK PRINTING ZIPPER 6337210719000V 1
@ nsp CLAMP CABLE TIE DACT-100A 4330040343010S 5
@ nsp CLAMP CABLE TIE DACT-100A 4330040343010S 2
@ nsp TAPE NR1606U1B(MARANTZ) NO_156(15X45)SCETATE CLOTH TAPE 1220210059050SV 1
SCREW GROUP
A nsp SCREW,TAP TITE KRA4030(K)(KENWOOD) +2S 3*8 B-TYPE ZNW/BH B020030081B10SV 63
B nsp SCREW,TAP TITE +2S 3*6 B-TYPE ZNW/BH B020030061B10S 4
C nsp SCREW,TAP TITE KRA4030(K)(KENWOOD) +2S 3*8 B-TYPE BK/BH B020030083B10SV 2 *
D nsp SCREW,TAP TITE () +2S 3*6(ROUND) BK/BH B020230063B10SV 7
E nsp SCREW,TAP TITE XHM82K/SYXEV8(PIONEER) +3S 3*6 ZNW/BH B020930061B10SV 1 *
F - G121162400040S NUT -2
Gnsp
SCREW,TAP TITE ASSY AVR1910BKE3(DENON) +3S 4*10 P+S-WASHER(ROUND)BK/BH
B028940101B11SV 4
Hnsp
SCREW,TAPPING ASSY AVR1404(KE3)(DENON) +2S 3*14 P(Φ6)S-WASHER ZNY/HH
B018230141H11SV 21
P nsp SCREW,TAP TITE HCD60M(HAITAI) +2S 3*17 B-TYPE ZNW/BH B020030171B10SV 2
J nsp SCREW AVR3300(E3)(DENON) +2S 4*8 B-TYPE(DOT) BK/BH 1500040083B10SV 6
K nsp SCREW,TAP TITE AVR3300(E3)(DENON) +2S 3*10 B-TYPE(DOT) BK/BH B020030103B11SV 34
L nsp SCREW,TAP TITE NR1606U1B(MARANTZ) +3S 3*6 C-TITE(DOT) BK/BH B020930063B11SV 13
M nsp SCREW HRV4000(K)(HAITAI) +2S 3*8 PI9.5 B-TYPE ZNW 1500001206010SV 3
N nsp SCREW,TAP TITE +3S 4*6 C-TYPE ZNW/BH B020940061B10S 5 *
38
