Denon AVR-X3300W Service Manual

PACKING VIEW
ZIPPERBAG(A5size)
SPOTIFY inseron sheet
dts : User update inseron
Update inseron sheet (E3 only)
QUICK START GUIDE (ALL)
*Geng started
ZIPPERBAG(A4size)
Notes on RADIO (ALL)
Cauons on Using Baeries (E2 only)
SAFETY INST. (ALL)
WARRANTY USA & CANADA (E3 only)
INSERTION SHEET (E3 only)
SPK WIRE LABEL (ALL)
CARD PASS
(E1C only)
AM Antenna
FM Antenna
Antenna Isolator
E1C only
*MANUAL POLYBAG ASSY*
* POLY BAG PACKING STYLE
8
10
4-4
4-1
8
* NOTE : This drawing is limited the mechanism,
Conformed to the limit design specifications.
(label, etc.)
accessory packing specification.
10
* BOX BOTTOM TAPING
1
7
16
SPEAKER TERMINAL BUSHING
2
3
5
9
TAPE
CORD AC
(CLEAR)
S E T
15
POLYBAG CODE : 6337-04006-201-0S
TOP
BOTTOM
6
11
4-2
4-3
13
POLYBAG CODE : 6337-21071-900-0V
14
17
12
12
*PACKING PROCESS
*MIC STAND ASSY
OLNY UK PLUG(at store)
68
Caution in
servicing
Electrical Mechanical Repair Information Updating

Denon AVR-X3300W Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Pre-out channels	7.2
Pre-out connectivity	Yes
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.05 %
Power output per channel (1KHz@6 Ohm)	180 W
Power output per channel (20-20KHz@8 Ohm)	105 W
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W
Product color	Black
Audio decoders	DTS-HD, DTS-HD Master Audio, Dolby TrueHD
Multi-Zone quantity	2
Apple docking compatibility	-
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
HDMI in	8
Audio (L/R) in	5
Remote control in	1
Composite video in	3
Composite video out	0
Connectivity technology	Wired
Speakers connectivity type	Clamp terminals
Audio formats supported	AAC, AIFF, ALAC, DSD, FLAC, MP3, WAV, WMA

Weight and Dimensions

Depth	389 mm
Width	434 mm
Height	167 mm
Weight	10800 g
