Denon AVR-X3300W Service Manual

FRONT
REF No. Part No. Part Name Remarks Q'ty New Ver
G4400
ns
p
RING,TER WIRE 120MM/1P ST710094-3=B1813TOP-2 1617#22 SJ 8410121010290
S
1*
J4458
ns
p
R,CHIP THICK 0-J,1/8W-3216REEL C200000061300
S
1
J4474
ns
p
R,CHIP THICK 0-J,1/8W-3216REEL C200000061300
S
1
JACK4400
963643101600
D
JACK,D6.5 PHONE (YUQIU) D6.5 9P NI PJ-621HA G402PJ621HA0YS
1
JACK4401
963643103380
S
JACK,D3.5 EARPHONE JACK(PJ-354H-4)(MIC) BLACK-REV G401PJ354H4RYS
1
JACK4700
00D963032560
6
JACK,D3.5 EARPHONE JACK PJ-308-02(RD) G40130802001Y
S
1
JACK4702
00D205130500
8
CN.WAFER INTERFACE 9P FEMALE D-SUB DS03-09 ADD SCREW(4.8*11.8)BLACK L103090090030
S
1
JP4401
ns
p
R,CHIP THICK 0-J,1/8W-3216REEL C200000061300
S
1
JP4402
ns
p
R,CHIP THICK 0-J,1/8W-3216REEL C200000061300
S
1
JP4490
ns
p
CN,WIRE 1P JUMPER (0.6/52MM) L045084006040
S
1
JP4491
ns
p
CN,WIRE 1P JUMPER (0.6/52MM) L045084006040
S
1
JP4492
ns
p
CN,WIRE 1P JUMPER (0.6/52MM) L045084006040
S
1
JP4493
ns
p
CN,WIRE 1P JUMPER (0.6/52MM) L045084006040
S
1
K1000
00D963024470
3
JACK,D3.5 EARPHONE JACK PJ-308-02 G40130802000Y
S
1
K1001
00D963024470
3
JACK,D3.5 EARPHONE JACK PJ-308-02 G40130802000Y
S
1
RMC4400
963262010290
S
MODULE,REMOCON R34FS9A 38KHZ IR REMOCON MODULE P=2.54MM H=15MM E940349003811S
1
SW4401
00D963009530
5
SW,TACT SKHV10910D01 KB581/LG 160G G180040500010
S
1
SW4402
00D963009530
5
SW,TACT SKHV10910D01 KB581/LG 160G G180040500010
S
1
SW4405
00D963009530
5
SW,TACT SKHV10910D01 KB581/LG 160G G180040500010
S
1
SW4406
00D963009530
5
SW,TACT SKHV10910D01 KB581/LG 160G G180040500010
S
1
SW4408
00D963009530
5
SW,TACT SKHV10910D01 KB581/LG 160G G180040500010
S
1
SW4409
00D963009530
5
SW,TACT SKHV10910D01 KB581/LG 160G G180040500010
S
1
SW4410
00D963038740
8
SW,ENCODER EC16B24SO-ZZZ L=25MM CLICK=24 TORQUE=100-300 G121162400070
S
1
SW4411
00D963009530
5
SW,TACT SKHV10910D01 KB581/LG 160G G180040500010
S
1
SW4412
963667100170
D
SW,ENCODER EC16B12SAAD4ZZZ G121161200070
S
1
SW4413
00D963009530
5
SW,TACT SKHV10910D01 KB581/LG 160G G180040500010
S
1
SW4416
00D963009530
5
SW,TACT SKHV10910D01 KB581/LG 160G G180040500010
S
1
SW4419
00D963009530
5
SW,TACT SKHV10910D01 KB581/LG 160G G180040500010
S
1
SW4420
00D963009530
5
SW,TACT SKHV10910D01 KB581/LG 160G G180040500010
S
1
@
ns
p
HOLDER AVRX2300WBKE3(DENON) SPTE 0.3T A4/FLT 4320211516000
S
1
@
ns
p
TAPE TESA #4970 14MM*50M/DOUBLE
A
710000750000S
0
@
ns
p
HOLDER AVRX2300WBKE3(DENON) SPTE 0.3T A4/FLT 4320211516000
S
1
@
ns
p
TAPE TESA #4970 14MM*50M/DOUBLE
A
710000750000S
0
5

Denon AVR-X3300W Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Pre-out channels	7.2
Pre-out connectivity	Yes
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.05 %
Power output per channel (1KHz@6 Ohm)	180 W
Power output per channel (20-20KHz@8 Ohm)	105 W
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W
Product color	Black
Audio decoders	DTS-HD, DTS-HD Master Audio, Dolby TrueHD
Multi-Zone quantity	2
Apple docking compatibility	-
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
HDMI in	8
Audio (L/R) in	5
Remote control in	1
Composite video in	3
Composite video out	0
Connectivity technology	Wired
Speakers connectivity type	Clamp terminals
Audio formats supported	AAC, AIFF, ALAC, DSD, FLAC, MP3, WAV, WMA

Weight and Dimensions

Depth	389 mm
Width	434 mm
Height	167 mm
Weight	10800 g
