Denon AVR-X3300W Service Manual

INPUT
REF No. Part No. Part Name Remarks Q'ty New Ver
R4514
ns
p
R,CHIP THICK 47-J,1/16W-1608REEL C20004706M160
S
1
R4515
ns
p
R,CHIP THICK 470K-J,1/16W-1608REEL C20004746M160
S
1
R4517
ns
p
R,CHIP THICK 47-J,1/16W-1608REEL C20004706M160
S
1
R4518
ns
p
R,CHIP THICK 470K-J,1/16W-1608REEL C20004746M160
S
1
R4520
ns
p
R,CHIP THICK 47-J,1/16W-1608REEL C20004706M160
S
1
R4521
ns
p
R,CHIP THICK 470K-J,1/16W-1608REEL C20004746M160
S
1
R4523
ns
p
R,CHIP THICK 47-J,1/16W-1608REEL C20004706M160
S
1
R4524
ns
p
R,CHIP THICK 470K-J,1/16W-1608REEL C20004746M160
S
1
R4526
ns
p
R,CHIP THICK 47-J,1/16W-1608REEL C20004706M160
S
1
R4527
ns
p
R,CHIP THICK 470K-J,1/16W-1608REEL C20004746M160
S
1
R4529
ns
p
R,CHIP THICK 47-J,1/16W-1608REEL C20004706M160
S
1
R4530
ns
p
R,CHIP THICK 470K-J,1/16W-1608REEL C20004746M160
S
1
R4532
ns
p
R,CHIP THICK 47-J,1/16W-1608REEL C20004706M160
S
1
R4533
ns
p
R,CHIP THICK 470K-J,1/16W-1608REEL C20004746M160
S
1
R4553
ns
p
R,CHIP THICK 0-J,1/16W-1608REEL C20000006M160
S
1
R4554
ns
p
R,CHIP THICK 0-J,1/16W-1608REEL C20000006M160
S
1
CAPACIITORS GROUP
C1380
ns
p
C,CERAMIC CHIP HIK X5R)10UF-K/16V-2012REEL GRM21BR61C106KE15
L
D011106573200
S
1
C1385
ns
p
C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REE
L
D011104177101
S
1
C1386
ns
p
C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REE
L
D011104177101
S
1
C1387
ns
p
C,CERAMIC CHIP HIK X7R)0.1UF-K/50V-1608REE
L
D011104577160
S
1
C1388
ns
p
C,CERAMIC CHIP HIK X7R)0.01UF-K/25V-1005REE
L
D011103174101
S
1
C1389
ns
p
C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REE
L
D011104177101
S
1
C1390
ns
p
C,CERAMIC CHIP HIK X7R)0.1UF-K/50V-1608REE
L
D011104577160
S
1
C1391
ns
p
C,CERAMIC CHIP HIK X5R)10UF-K/16V-2012REEL GRM21BR61C106KE15
L
D011106573200
S
1
C1392
ns
p
C,CERAMIC CHIP HIK X7R)0.1UF-K/50V-1608REE
L
D011104577160
S
1
C1393
ns
p
C,CERAMIC CHIP HIK X7R)0.1UF-K/50V-1608REE
L
D011104577160
S
1
C1394
ns
p
C,CERAMIC CHIP HIK X7R)1000PF-K/50V-1608REE
L
D011102777160
S
1
C1395
ns
p
C,CERAMIC CHIP HIK X7R)1000PF-K/50V-1608REE
L
D011102777160
S
1
C1396
ns
p
C,CERAMIC CHIP HIK X5R)10UF-K/16V-2012REEL GRM21BR61C106KE15
L
D011106573200
S
1
C4200
ns
p
C,ELECT GE 85C 10UF-M/50V,5*11-5RE.SMS SY D040100087070
S
1
C4201
ns
p
C,ELECT GE 85C 10UF-M/50V,5*11-5RE.SMS SY D040100087070
S
1
C4202
ns
p
C,ELECT GE 85C 10UF-M/50V,5*11-5RE.SMS SY D040100087070
S
1
C4203
ns
p
C,ELECT GE 85C 10UF-M/50V,5*11-5RE.SMS SY D040100087070
S
1
C4204
ns
p
C,ELECT GE 85C 10UF-M/50V,5*11-5RE.SMS SY D040100087070
S
1
C4205
ns
p
C,ELECT GE 85C 10UF-M/50V,5*11-5RE.SMS SY D040100087070
S
1
C4206
ns
p
C,ELECT GE 85C 10UF-M/50V,5*11-5RE.SMS SY D040100087070
S
1
C4208
ns
p
C,CERAMIC CHIP T.C COG330PF-J/50V-1608REEL D010331167160
S
1
C4210
ns
p
C,CERAMIC CHIP T.C CH)1500PF-J/50V-1608REEL GRM1882C1H152JA01
D
D010152167165
S
1
C4211
00D2544583971
C,ELECT GE 85C 47UF-M/50V,8*11.5-5RE ROB-50V470MG3#9-T
2
D040470087140
S
1
C4212
963133502020
S
C,ELECT GE 85C 470UF-M/16V,8*11.5 KR3-016V471MF115-T/A5.0S KOSHIN D040471083550
S
1
C4213
ns
p
C,CERAMIC CHIP T.C COG330PF-J/50V-1608REEL D010331167160
S
1
C4214
963133502020
S
C,ELECT GE 85C 470UF-M/16V,8*11.5 KR3-016V471MF115-T/A5.0S KOSHIN D040471083550
S
1
C4215
ns
p
C,CERAMIC CHIP T.C CH)1500PF-J/50V-1608REEL GRM1882C1H152JA01
D
D010152167165
S
1
C4216
ns
p
C,CERAMIC CHIP T.C CH)330PF-J/50V-1608REEL GRM1882C1H331JA01
D
D010331167165
S
1
C4217
ns
p
C,CERAMIC CHIP T.C CH)330PF-J/50V-1608REEL GRM1882C1H331JA01
D
D010331167165
S
1
C4218
ns
p
C,ELECT GE 85C 100UF-M/16V,5*11-5RE,SHL S
Y
D040101083090
S
1
C4219
ns
p
C,ELECT GE 85C 47UF-M/50V,6.3*11 KR3-050V470ME110-T/A5.0S KOSHIN D040470087550
S
1
C4220
ns
p
C,CERAMIC CHIP T.C CH)1500PF-J/50V-1608REEL GRM1882C1H152JA01
D
D010152167165
S
1
C4221
ns
p
C,CERAMIC CHIP T.C CH)330PF-J/50V-1608REEL GRM1882C1H331JA01
D
D010331167165
S
1
C4222
ns
p
C,ELECT GE 85C 100UF-M/16V,5*11-5RE,SHL S
Y
D040101083090
S
1
C4223
ns
p
C,ELECT GE 85C 47UF-M/50V,6.3*11 KR3-050V470ME110-T/A5.0S KOSHIN D040470087550
S
1
C4224
ns
p
C,ELECT GE 85C 22UF-M/50V,5*11-5RE.SMS SY D040220087060
S
1
C4225
ns
p
C,ELECT GE 85C 22UF-M/50V,5*11-5RE.SMS SY D040220087060
S
1
C4226
ns
p
C,CERAMIC CHIP T.C COG330PF-J/50V-1608REEL D010331167160
S
1
C4228
ns
p
C,CERAMIC CHIP T.C CH)1500PF-J/50V-1608REEL GRM1882C1H152JA01
D
D010152167165
S
1
C4229
00D2544583971
C,ELECT GE 85C 47UF-M/50V,8*11.5-5RE ROB-50V470MG3#9-T
2
D040470087140
S
1
C4230
ns
p
C,CERAMIC CHIP T.C X7R)0.01UF-K/50V-1608REE
L
D010103777160
S
1
C4232
ns
p
C,CERAMIC CHIP T.C CH)330PF-J/50V-1608REEL GRM1882C1H331JA01
D
D010331167165
S
1
C4234
ns
p
C,CERAMIC CHIP T.C COG330PF-J/50V-1608REEL D010331167160
S
1
C4236
ns
p
C,ELECT GE 85C 10UF-M/50V,5*11-5RE.SMS SY D040100087070
S
1
C4237
ns
p
C,ELECT GE 85C 1UF-M/50V,5*11-5RE.SMS SY (Pb Free) D040010087150
S
1
C4238
ns
p
C,ELECT GE 85C 22UF-M/50V,5*11-5RE.SMS SY D040220087060
S
1
C4239
ns
p
C,ELECT GE 85C 22UF-M/50V,5*11-5RE.SMS SY D040220087060
S
1
C4240
ns
p
C,ELECT GE 85C 10UF-M/50V,5*11-5RE.SMS SY D040100087070
S
1
C4241
ns
p
C,ELECT GE 85C 1UF-M/50V,5*11-5RE.SMS SY (Pb Free) D040010087150
S
1
C4242
ns
p
C,CERAMIC CHIP T.C CH)1500PF-J/50V-1608REEL GRM1882C1H152JA01
D
D010152167165
S
1
C4243
ns
p
C,ELECT GE 85C 47UF-M/50V,6.3*11 KR3-050V470ME110-T/A5.0S KOSHIN D040470087550
S
1
C4244
00D2544583971
C,ELECT GE 85C 47UF-M/50V,8*11.5-5RE ROB-50V470MG3#9-T
2
D040470087140
S
1
C4245
ns
p
C,ELECT GE 85C 47UF-M/50V,6.3*11 KR3-050V470ME110-T/A5.0S KOSHIN D040470087550
S
1
C4246
ns
p
C,ELECT GE 85C 47UF-M/50V,6.3*11 KR3-050V470ME110-T/A5.0S KOSHIN D040470087550
S
1
C4247
ns
p
C,CERAMIC CHIP T.C CH)330PF-J/50V-1608REEL GRM1882C1H331JA01
D
D010331167165
S
1
C4248
ns
p
C,ELECT GE 85C 22UF-M/50V,5*11-5RE.SMS SY D040220087060
S
1
C4249
ns
p
C,ELECT GE 85C 22UF-M/50V,5*11-5RE.SMS SY D040220087060
S
1
C4250
ns
p
C,CERAMIC CHIP T.C CH)330PF-J/50V-1608REEL GRM1882C1H331JA01
D
D010331167165
S
1
C4251
ns
p
C,ELECT GE 85C 47UF-M/25V,5*11 KR3-025V470MC110-T/A5.0S KOSHIN D040470084550
S
1
C4252
ns
p
C,ELECT GE 85C 47UF-M/25V,5*11 KR3-025V470MC110-T/A5.0S KOSHIN D040470084550
S
1
C4253
ns
p
C,CERAMIC CHIP T.C COG330PF-J/50V-1608REEL D010331167160
S
1
C4255
ns
p
C,CERAMIC CHIP T.C X7R)0.01UF-K/50V-1608REE
L
D010103777160
S
1
C4256
ns
p
C,CERAMIC CHIP T.C COG330PF-J/50V-1608REEL D010331167160
S
1
C4258
ns
p
C,ELECT GE 85C 22UF-M/50V,5*11-5RE.SMS SY D040220087060
S
1
C4259
ns
p
C,ELECT GE 85C 22UF-M/50V,5*11-5RE.SMS SY D040220087060
S
1
C4261
ns
p
C,CERAMIC CHIP T.C CH)1500PF-J/50V-1608REEL GRM1882C1H152JA01
D
D010152167165
S
1
C4262
ns
p
C,ELECT GE 85C 47UF-M/25V,5*11 KR3-025V470MC110-T/A5.0S KOSHIN D040470084550
S
1
C4263
ns
p
C,ELECT GE 85C 47UF-M/50V,6.3*11 KR3-050V470ME110-T/A5.0S KOSHIN D040470087550
S
1
C4265
ns
p
C,CERAMIC CHIP T.C CH)330PF-J/50V-1608REEL GRM1882C1H331JA01
D
D010331167165
S
1
C4266
ns
p
C,ELECT GE 85C 10UF-M/50V,5*11-5RE.SMS SY D040100087070
S
1
C4267
ns
p
C,ELECT GE 85C 10UF-M/50V,5*11-5RE.SMS SY D040100087070
S
1
C4268
ns
p
C,CERAMIC CHIP T.C CH)330PF-J/50V-1608REEL GRM1882C1H331JA01
D
D010331167165
S
1
C4269
ns
p
C,ELECT GE 85C 0.1UF-M/50V,5*11-5RE.SMS SY (Pb Free) D040R10087080
S
1
C4270
ns
p
C,ELECT GE 85C 22UF-M/50V,5*11-5RE.SMS SY D040220087060
S
1
C4271
ns
p
C,ELECT GE 85C 22UF-M/50V,5*11-5RE.SMS SY D040220087060
S
1
C4272
ns
p
C,ELECT GE 85C 10UF-M/50V,5*11-5RE.SMS SY D040100087070
S
1
C4273
ns
p
C,ELECT GE 85C 10UF-M/50V,5*11-5RE.SMS SY D040100087070
S
1
C4274
ns
p
C,CERAMIC CHIP T.C CH)330PF-J/50V-1608REEL GRM1882C1H331JA01
D
D010331167165
S
1
C4275
ns
p
C,CERAMIC CHIP T.C COG330PF-J/50V-1608REEL D010331167160
S
1
C4276
ns
p
C,ELECT GE 85C 0.1UF-M/50V,5*11-5RE.SMS SY (Pb Free) D040R10087080
S
1
C4277
ns
p
C,ELECT GE 85C 10UF-M/50V,5*11-5RE.SMS SY D040100087070
S
1
C4278
ns
p
C,ELECT GE 85C 10UF-M/50V,5*11-5RE.SMS SY D040100087070
S
1
C4279
00D963022390
2
C,CERAMIC CHIP T.C COG39PF-J/50V-1608REEL D010390167160
S
1
C4280
ns
p
C,CERAMIC CHIP T.C CH)1500PF-J/50V-1608REEL GRM1882C1H152JA01
D
D010152167165
S
1
C4281
ns
p
C,CERAMIC CHIP T.C X7R)0.01UF-K/50V-1608REE
L
D010103777160
S
1
C4282
ns
p
C,ELECT GE 85C 47UF-M/25V,5*11 KR3-025V470MC110-T/A5.0S KOSHIN D040470084550
S
1
C4283
ns
p
C,ELECT GE 85C 10UF-M/50V,5*11-5RE.SMS SY D040100087070
S
1
C4284
ns
p
C,ELECT GE 85C 0.1UF-M/50V,5*11-5RE.SMS SY (Pb Free) D040R10087080
S
1
C4285
ns
p
C,ELECT GE 85C 22UF-M/50V,5*11-5RE.SMS SY D040220087060
S
1
C4286
ns
p
C,ELECT GE 85C 22UF-M/50V,5*11-5RE.SMS SY D040220087060
S
1
C4287
ns
p
C,CERAMIC CHIP T.C CH)330PF-J/50V-1608REEL GRM1882C1H331JA01
D
D010331167165
S
1
C4288
ns
p
C,CERAMIC CHIP T.C COG330PF-J/50V-1608REEL D010331167160
S
1
C4289
ns
p
C,ELECT GE 85C 0.1UF-M/50V,5*11-5RE.SMS SY (Pb Free) D040R10087080
S
1
C4290
ns
p
C,CERAMIC CHIP T.C X7R)0.01UF-K/50V-1608REE
L
D010103777160
S
1
C4291
00D963022390
2
C,CERAMIC CHIP T.C COG39PF-J/50V-1608REEL D010390167160
S
1
C4292
ns
p
C,CERAMIC CHIP T.C CH)1500PF-J/50V-1608REEL GRM1882C1H152JA01
D
D010152167165
S
1
10

Denon AVR-X3300W Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Pre-out channels	7.2
Pre-out connectivity	Yes
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.05 %
Power output per channel (1KHz@6 Ohm)	180 W
Power output per channel (20-20KHz@8 Ohm)	105 W
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W
Product color	Black
Audio decoders	DTS-HD, DTS-HD Master Audio, Dolby TrueHD
Multi-Zone quantity	2
Apple docking compatibility	-
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
HDMI in	8
Audio (L/R) in	5
Remote control in	1
Composite video in	3
Composite video out	0
Connectivity technology	Wired
Speakers connectivity type	Clamp terminals
Audio formats supported	AAC, AIFF, ALAC, DSD, FLAC, MP3, WAV, WMA

Weight and Dimensions

Depth	389 mm
Width	434 mm
Height	167 mm
Weight	10800 g
