Denon AVR-X3300W Service Manual

HDMI
REF No. Part No. Part Name Remarks Q'ty New Ver
U1065 943239101860S IC,LINEAR-REGULATOR TPS563200 SOT6 STEP DOWN VOL REG J126563200010S 1
U1066 943239101860S IC,LINEAR-REGULATOR TPS563200 SOT6 STEP DOWN VOL REG J126563200010S 1
U1067 943239101860S IC,LINEAR-REGULATOR TPS563200 SOT6 STEP DOWN VOL REG J126563200010S 1
U1068 943239101860S IC,LINEAR-REGULATOR TPS563200 SOT6 STEP DOWN VOL REG J126563200010S 1
U1069 943239101860S IC,LINEAR-REGULATOR TPS563200 SOT6 STEP DOWN VOL REG J126563200010S 1
U1070 963231102360S IC,LINEAR-REGULATOR TPS562200 SOT6 STEP DOWN VOL REG J126562200010S 1
U1071 963231102360S IC,LINEAR-REGULATOR TPS562200 SOT6 STEP DOWN VOL REG J126562200010S 1
U1072 963231102360S IC,LINEAR-REGULATOR TPS562200 SOT6 STEP DOWN VOL REG J126562200010S 1
U1073 963245100680S IC,ANALOG CS49844A AUDIO DSP J080498440010S 1
U2207 963239002150S IC,LOGIC SN74LVC244APWR TSSOP 20P/OCTAL BUFFER/DRIVER J040742440230S 1
RESISTOR GROUP
R1010 nsp R,CHIP THICK 47K-J,1/16W-1005REEL C20004736M101S 1
R1011 nsp R,CHIP THICK 47K-J,1/16W-1005REEL C20004736M101S 1
R1013 nsp R,CHIP THICK 1K-J,1/16W-1005REEL C20001026M101S 1
R1014 nsp R,CHIP THICK 10K-J,1/16W-1005REEL C20001036M111S 1
R1015 nsp R,CHIP THICK 47K-J,1/16W-1005REEL C20004736M101S 1
R1016 nsp R,CHIP THICK 47K-J,1/16W-1005REEL C20004736M101S 1
R1017 nsp R,CHIP THICK 0-J,1/16W-1005REEL C20000006M101S 1
R1018 nsp R,CHIP THICK 47K-J,1/16W-1005REEL C20004736M101S 1
R1019 nsp R,CHIP THICK 0-J,1/16W-1005REEL C20000006M101S 1
R1021 nsp R,CHIP THICK 0-J,1/16W-1005REEL C20000006M101S 1
R1038 nsp R,CHIP THICK 1K-J,1/16W-1005REEL C20001026M101S 1
R1039 nsp R,CHIP THICK 10K-J,1/16W-1005REEL C20001036M111S 1
R1040 nsp R,CHIP THICK 47K-J,1/16W-1005REEL C20004736M101S 1
R1041 nsp R,CHIP THICK 47K-J,1/16W-1005REEL C20004736M101S 1
R1042 nsp R,CHIP THICK 0-J,1/16W-1005REEL C20000006M101S 1
R1043 nsp R,CHIP THICK 47K-J,1/16W-1005REEL C20004736M101S 1
R1044 nsp R,CHIP THICK 0-J,1/16W-1005REEL C20000006M101S 1
R1045 nsp R,CHIP THICK 0-J,1/16W-1005REEL C20000006M101S 1
R1050 nsp R,CHIP THICK 1K-J,1/16W-1005REEL C20001026M101S 1
R1051 nsp R,CHIP THICK 1K-J,1/16W-1005REEL C20001026M101S 1
R1052 nsp R,CHIP THICK 1.8K-J,1/16W-1005REEL C20001826M101S 1
R1053 nsp R,CHIP THICK 0-J,1/16W-1005REEL C20000006M101S 1
R1054 nsp R,CHIP THICK 10K-F,1/16W-1608REEL C20001034M160S 1
R1055 nsp R,CHIP THICK 1.8K-J,1/16W-1005REEL C20001826M101S 1
R1056 nsp R,CHIP THICK 1K-F,1/16W-1608REEL C20001024M160S 1
R1057 nsp R,CHIP THICK 1.8K-J,1/16W-1005REEL C20001826M101S 1
R1058 nsp R,CHIP THICK 1.8K-J,1/16W-1005REEL C20001826M101S 1
R1059 nsp R,CHIP THICK 1K-F,1/16W-1608REEL C20001024M160S 1
R1060 nsp R,CHIP THICK 47-J,1/16W-1005REEL C20004706M101S 1
R1061 nsp R,CHIP THICK 47-J,1/16W-1005REEL C20004706M101S 1
R1062 nsp R,CHIP THICK 47-J,1/16W-1005REEL C20004706M101S 1
R1063 nsp R,CHIP THICK 1M-J,1/16W-1005REEL C20001056M101S 1
R1065 nsp R,CHIP THICK 10K-J,1/16W-1005REEL C20001036M111S 1
R1068 nsp R,CHIP THICK 10K-J,1/16W-1005REEL C20001036M111S 1
R1069 nsp R,CHIP THICK 1K-J,1/16W-1005REEL C20001026M101S 1
R1070 nsp R,CHIP THICK 10K-J,1/16W-1005REEL C20001036M111S 1
R1071 nsp R,CHIP THICK 47K-J,1/16W-1005REEL C20004736M101S 1
R1072 nsp R,CHIP THICK 47K-J,1/16W-1005REEL C20004736M101S 1
R1073 nsp R,CHIP THICK 10K-J,1/16W-1005REEL C20001036M111S 1
R1075 nsp R,CHIP THICK 0-J,1/16W-1005REEL C20000006M101S 1
R1076 nsp R,CHIP THICK 47K-J,1/16W-1005REEL C20004736M101S 1
R1077 nsp R,CHIP THICK 10K-F,1/16W-1608REEL C20001034M160S 1
R1078 nsp R,CHIP THICK 1K-F,1/16W-1608REEL C20001024M160S 1
R1079 nsp R,CHIP THICK 10K-F,1/16W-1608REEL C20001034M160S 1
R1080 nsp R,CHIP THICK 1K-J,1/16W-1005REEL C20001026M101S 1
R1081 nsp R,CHIP THICK 0-J,1/16W-1005REEL C20000006M101S 1
R1082 nsp R,CHIP THICK 0-J,1/16W-1005REEL C20000006M101S 1
R1083 nsp R,CHIP THICK 1K-J,1/16W-1005REEL C20001026M101S 1
R1084 nsp R,CHIP THICK 6.2K-D,1/16W-1608REEL C20006221M161S 1
R1085 nsp R,CHIP THICK 3.6K-F,1/16W-1608REEL C20003624M161S 1
R1086 nsp R,CHIP THICK 47K-J,1/16W-1005REEL C20004736M101S 1
R1087 nsp R,CHIP THICK 3.6K-F,1/16W-1608REEL C20003624M161S 1
R1088 nsp R,CHIP THICK 3.6K-F,1/16W-1608REEL C20003624M161S 1
R1089 nsp R,CHIP THICK 10K-J,1/16W-1005REEL C20001036M111S 1
R1090 nsp R,CHIP THICK 27K-F,1/16W-1608REEL C20002734M160S 1
R1091 nsp R,CHIP THICK 10K-F,1/16W-1608REEL C20001034M160S 1
R1092 nsp R,CHIP THICK 47K-J,1/16W-1005REEL C20004736M101S 1
R1093 nsp R,CHIP THICK 10K-J,1/16W-1005REEL C20001036M111S 1
R1094 nsp R,CHIP THICK 1K-J,1/16W-1005REEL C20001026M101S 1
R1096 nsp R,CHIP THICK 2.2K-J,1/16W-1005REEL C20002226M101S 1
R1097 nsp R,CHIP THICK 0-J,1/16W-1005REEL C20000006M101S 1
R1098 nsp R,CHIP THICK 1K-J,1/16W-1005REEL C20001026M101S 1
R1099 nsp R,CHIP THICK 8.2K-J,1/16W-1005REEL C20008226M101S 1
R1100 nsp R,CHIP THICK 10K-F,1/16W-1608REEL C20001034M160S 1
R1101 nsp R,CHIP THICK 1K-J,1/16W-1005REEL C20001026M101S 1
R1102 nsp R,CHIP THICK 10K-J,1/16W-1005REEL C20001036M111S 1
R1103 nsp R,CHIP THICK 47K-J,1/16W-1005REEL C20004736M101S 1
R1104 nsp R,CHIP THICK 47K-J,1/16W-1005REEL C20004736M101S 1
R1105 nsp R,CHIP THICK 0-J,1/16W-1005REEL C20000006M101S 1
R1106 nsp R,CHIP THICK 47K-J,1/16W-1005REEL C20004736M101S 1
R1107 nsp R,CHIP THICK 0-J,1/16W-1005REEL C20000006M101S 1
R1108 nsp R,CHIP THICK 0-J,1/16W-1005REEL C20000006M101S 1
R1109 nsp R,CHIP THICK 6.2K-D,1/16W-1608REEL C20006221M161S 1
R1110 nsp R,CHIP THICK 27K-F,1/16W-1608REEL C20002734M160S 1
R1111 nsp R,CHIP THICK 1K-J,1/16W-1005REEL C20001026M101S 1
R1112 nsp R,CHIP THICK 10K-F,1/16W-1608REEL C20001034M160S 1
R1113 nsp R,CHIP THICK 1K-F,1/16W-1608REEL C20001024M160S 1
R1114 nsp R,CHIP THICK 2.2K-F,1/16W-1608REEL C20002224M160S 1
R1115 nsp R,CHIP THICK 1K-J,1/16W-1005REEL C20001026M101S 1
R1116 nsp R,CHIP THICK 10K-F,1/16W-1608REEL C20001034M160S 1
R1117 nsp R,CHIP THICK 10K-D,1/16W-1608REEL C20001031M161S 1
R1118 nsp R,CHIP THICK 3.9K-F,1/16W-1608REEL C20003924M161S 1
R1119 nsp R,CHIP THICK 10K-F,1/16W-1608REEL C20001034M160S 1
R1120 nsp R,CHIP THICK 5.6K-D,1/16W-1608REEL C20005621M161S 1
R1121 nsp R,CHIP THICK 1K-J,1/16W-1005REEL C20001026M101S 1
R1122 nsp R,CHIP THICK 10K-J,1/16W-1005REEL C20001036M111S 1
R1123 nsp R,CHIP THICK 47K-J,1/16W-1005REEL C20004736M101S 1
R1124 nsp R,CHIP THICK 47K-J,1/16W-1005REEL C20004736M101S 1
R1125 nsp R,CHIP THICK 0-J,1/16W-1005REEL C20000006M101S 1
R1126 nsp R,CHIP THICK 47K-J,1/16W-1005REEL C20004736M101S 1
R1127 nsp R,CHIP THICK 0-J,1/16W-1005REEL C20000006M101S 1
R1128 nsp R,CHIP THICK 1K-J,1/16W-1005REEL C20001026M101S 1
R1129 nsp R,CHIP THICK 0-J,1/16W-1005REEL C20000006M101S 1
R1130 nsp R,CHIP THICK 10K-D,1/16W-1608REEL C20001031M161S 1
R1131 nsp R,CHIP THICK 2.7K-D,1/16W-1608REEL C20002721M161S 1
R1132 nsp R,CHIP THICK 11K-D,1/10W-1608REEL C200011310161S 1
R1133 nsp R,CHIP THICK 1K-J,1/16W-1005REEL C20001026M101S 1
R1134 nsp R,CHIP THICK 10K-D,1/16W-1608REEL C20001031M161S 1
R1135 nsp R,CHIP THICK 18K-D,1/16W-1608REEL C20001831M161S 1
R1136 nsp R,CHIP THICK 2.4K-F,1/16W-1608REEL C20002424M160S 1
R1137 nsp R,CHIP THICK 820-D,1/16W-1608REEL C20008211M160S 1
R1138 nsp R,CHIP THICK 47K-J,1/16W-1005REEL C20004736M101S 1
21

Denon AVR-X3300W Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Pre-out channels	7.2
Pre-out connectivity	Yes
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.05 %
Power output per channel (1KHz@6 Ohm)	180 W
Power output per channel (20-20KHz@8 Ohm)	105 W
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W
Product color	Black
Audio decoders	DTS-HD, DTS-HD Master Audio, Dolby TrueHD
Multi-Zone quantity	2
Apple docking compatibility	-
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
HDMI in	8
Audio (L/R) in	5
Remote control in	1
Composite video in	3
Composite video out	0
Connectivity technology	Wired
Speakers connectivity type	Clamp terminals
Audio formats supported	AAC, AIFF, ALAC, DSD, FLAC, MP3, WAV, WMA

Weight and Dimensions

Depth	389 mm
Width	434 mm
Height	167 mm
Weight	10800 g
