Denon AVR-X3300W Service Manual

HDMI
REF No. Part No. Part Name Remarks Q'ty New Ver
R2092 nsp R,CHIP THICK 24-J,1/16W-1608REEL C20002406M160S 1
R2093 nsp R,CHIP THICK 51-J,1/16W-1608REEL C20005106M160S 1
R2094 nsp R,CHIP THICK 51-J,1/16W-1608REEL C20005106M160S 1
R2095 nsp R,CHIP THICK 51-J,1/16W-1608REEL C20005106M160S 1
R2096 nsp R,CHIP THICK 51-J,1/16W-1608REEL C20005106M160S 1
R2097 nsp R,CHIP THICK 2.2K-J,1/16W-1005REEL C20002226M101S 1
R2098 nsp R,CHIP THICK 100-J,1/16W-1005REEL C20001016M101S 1
R2099 nsp R,CHIP THICK 100-J,1/16W-1005REEL C20001016M101S 1
R2100 nsp R,CHIP THICK 100-J,1/16W-1005REEL C20001016M101S 1
R2101 nsp R,CHIP THICK 3.3K-J,1/16W-1005REEL C20003326M101S 1
R2102 nsp R,CHIP THICK 3.3K-J,1/16W-1005REEL C20003326M101S 1
R2103 nsp R,CHIP THICK 3.3K-J,1/16W-1005REEL C20003326M101S 1
R2104 nsp R,CHIP THICK 4.7K-J,1/16W-1005REEL C20004726M101S 1
R2105 nsp R,CHIP THICK 3.3K-J,1/16W-1005REEL C20003326M101S 1
R2108 nsp R,CHIP THICK 3.3K-J,1/16W-1005REEL C20003326M101S 1
R2110 nsp R,CHIP THICK 470-J,1/16W-1005REEL C20004716M101S 1
R2111 nsp R,CHIP THICK 3.3K-J,1/16W-1005REEL C20003326M101S 1
R2112 nsp R,CHIP THICK 3.3K-J,1/16W-1005REEL C20003326M101S 1
R2113 nsp R,CHIP THICK 3.3K-J,1/16W-1005REEL C20003326M101S 1
R2114 nsp R,CHIP THICK 3.3K-J,1/16W-1005REEL C20003326M101S 1
R2115 nsp R,CHIP THICK 100K-J,1/16W-1005REEL C20001046M101S 1
R2116 nsp R,CHIP THICK 10K-J,1/16W-1005REEL C20001036M111S 1
R2117 nsp R,CHIP THICK 0-J,1/16W-1608REEL C20000006M160S 1
R2118 nsp R,CHIP THICK 10K-J,1/16W-1005REEL C20001036M111S 1
R2120 nsp R,CHIP THICK 470-D,1/16W-1608REEL C20004711M160S 1
R2121 nsp R,CHIP THICK 10K-J,1/16W-1005REEL C20001036M111S 1
R2123 nsp R,CHIP THICK 10K-J,1/16W-1005REEL C20001036M111S 1
R2126 nsp R,CHIP THICK 10K-J,1/16W-1005REEL C20001036M111S 1
R2127 nsp R,CHIP THICK 10K-J,1/16W-1005REEL C20001036M111S 1
R2128 nsp R,CHIP THICK 10K-J,1/16W-1005REEL C20001036M111S 1
R2130 nsp R,CHIP THICK 470-J,1/16W-1005REEL C20004716M101S 1
R2132 nsp R,NETWORK A-TYPE 4.7K-J 1/16W SMD(1005)*4 WA04X C180472042100S 1
R2134 nsp R,CHIP THICK 100K-J,1/16W-1005REEL C20001046M101S 1
R2135 nsp R,NETWORK A-TYPE 4.7K-J 1/16W SMD(1005)*4 WA04X C180472042100S 1
R2139 nsp R,NETWORK A-TYPE 4.7K-J 1/16W SMD(1005)*4 WA04X C180472042100S 1
R2142 nsp R,NETWORK A-TYPE 10-J 1/16W SMD(1005)*4 WA04X C180100042100S 1
R2143 nsp R,CHIP THICK 2.2K-J,1/16W-1005REEL C20002226M101S 1
R2144 nsp R,CHIP THICK 2.2K-J,1/16W-1005REEL C20002226M101S 1
R2146 nsp R,CHIP THICK 4.7K-J,1/16W-1005REEL C20004726M101S 1
R2147 nsp R,CHIP THICK 10-J,1/16W-1005REEL C20001006M101S 1
R2151 nsp R,NETWORK A-TYPE 4.7K-J 1/16W SMD(1005)*4 WA04X C180472042100S 1
R2156 nsp R,NETWORK A-TYPE 4.7K-J 1/16W SMD(1005)*4 WA04X C180472042100S 1
R2159 nsp R,CHIP THICK 1K-J,1/16W-1005REEL C20001026M101S 1
R2163 nsp R,CHIP THICK 4.7K-J,1/16W-1005REEL C20004726M101S 1
R2164 nsp R,NETWORK A-TYPE 4.7K-J 1/16W SMD(1005)*4 WA04X C180472042100S 1
R2171 nsp R,CHIP THICK 10K-J,1/16W-1005REEL C20001036M111S 1
R2181 nsp R,NETWORK A-TYPE 10K-J*4 1/16W SMD(1005) WA04 C180103042100S 1
R2182 nsp R,NETWORK A-TYPE 33-J 1/16W SMD(1005)*4 WA04X C180330042100S 1
R2183 nsp R,NETWORK A-TYPE 33-J 1/16W SMD(1005)*4 WA04X C180330042100S 1
R2184 nsp R,NETWORK A-TYPE 47-J 1/16W SMD(1005)*4 WA04X C180470042100S 1
R2185 nsp R,NETWORK A-TYPE 33-J 1/16W SMD(1005)*4 WA04X C180330042100S 1
R2186 nsp R,NETWORK A-TYPE 47-J 1/16W SMD(1005)*4 WA04X C180470042100S 1
R2187 nsp R,NETWORK A-TYPE 33-J 1/16W SMD(1005)*4 WA04X C180330042100S 1
R2188 nsp R,NETWORK A-TYPE 33-J 1/16W SMD(1005)*4 WA04X C180330042100S 1
R2189 nsp R,NETWORK A-TYPE 10-J 1/16W SMD(1005)*4 WA04X C180100042100S 1
R2190 nsp R,NETWORK A-TYPE 10-J 1/16W SMD(1005)*4 WA04X C180100042100S 1
R2191 nsp R,NETWORK A-TYPE 10-J 1/16W SMD(1005)*4 WA04X C180100042100S 1
R2192 nsp R,NETWORK A-TYPE 10-J 1/16W SMD(1005)*4 WA04X C180100042100S 1
R2193 nsp R,NETWORK A-TYPE 47-J 1/16W SMD(1005)*4 WA04X C180470042100S 1
R2194 nsp R,NETWORK A-TYPE 47-J 1/16W SMD(1005)*4 WA04X C180470042100S 1
R2195 nsp R,NETWORK A-TYPE 100-J*4 1/16W SMD(1005) WA04 C180101040500S 1
R2196 nsp R,NETWORK A-TYPE 100-J*4 1/16W SMD(1005) WA04 C180101040500S 1
R2197 nsp R,NETWORK A-TYPE 100-J*4 1/16W SMD(1005) WA04 C180101040500S 1
R2198 nsp R,NETWORK A-TYPE 100-J*4 1/16W SMD(1005) WA04 C180101040500S 1
R2199 nsp R,NETWORK A-TYPE 100-J*4 1/16W SMD(1005) WA04 C180101040500S 1
R2200 nsp R,NETWORK A-TYPE 100-J*4 1/16W SMD(1005) WA04 C180101040500S 1
R2201 nsp R,NETWORK A-TYPE 33-J 1/16W SMD(1005)*4 WA04X C180330042100S 1
R2202 nsp R,NETWORK A-TYPE 47-J 1/16W SMD(1005)*4 WA04X C180470042100S 1
R2203 nsp R,NETWORK A-TYPE 47-J 1/16W SMD(1005)*4 WA04X C180470042100S 1
R2204 nsp R,NETWORK A-TYPE 47-J 1/16W SMD(1005)*4 WA04X C180470042100S 1
R2205 nsp R,NETWORK A-TYPE 47-J 1/16W SMD(1005)*4 WA04X C180470042100S 1
R2206 nsp R,NETWORK A-TYPE 47-J 1/16W SMD(1005)*4 WA04X C180470042100S 1
R2207 nsp R,NETWORK A-TYPE 47-J 1/16W SMD(1005)*4 WA04X C180470042100S 1
R2208 nsp R,NETWORK A-TYPE 10-J 1/16W SMD(1005)*4 WA04X C180100042100S 1
R2209 nsp R,NETWORK A-TYPE 10-J 1/16W SMD(1005)*4 WA04X C180100042100S 1
R2210 nsp R,NETWORK A-TYPE 10-J 1/16W SMD(1005)*4 WA04X C180100042100S 1
R2211 nsp R,NETWORK A-TYPE 10-J 1/16W SMD(1005)*4 WA04X C180100042100S 1
R2212 nsp R,NETWORK A-TYPE 10-J 1/16W SMD(1005)*4 WA04X C180100042100S 1
R2213 nsp R,NETWORK A-TYPE 10-J 1/16W SMD(1005)*4 WA04X C180100042100S 1
R2214 nsp R,NETWORK A-TYPE 10-J 1/16W SMD(1005)*4 WA04X C180100042100S 1
R2215 nsp R,NETWORK A-TYPE 10-J 1/16W SMD(1005)*4 WA04X C180100042100S 1
R2216 nsp R,NETWORK A-TYPE 10-J 1/16W SMD(1005)*4 WA04X C180100042100S 1
R2217 nsp R,NETWORK A-TYPE 10-J 1/16W SMD(1005)*4 WA04X C180100042100S 1
R2218 nsp R,NETWORK A-TYPE 22-J*4 1/16W SMD(1005) WA04 C180220042100S 1
R2219 nsp R,NETWORK A-TYPE 22-J*4 1/16W SMD(1005) WA04 C180220042100S 1
R2220 nsp R,NETWORK A-TYPE 22-J*4 1/16W SMD(1005) WA04 C180220042100S 1
R2221 nsp R,NETWORK A-TYPE 22-J*4 1/16W SMD(1005) WA04 C180220042100S 1
R2222 nsp R,NETWORK A-TYPE 22-J*4 1/16W SMD(1005) WA04 C180220042100S 1
R2223 nsp R,NETWORK A-TYPE 22-J*4 1/16W SMD(1005) WA04 C180220042100S 1
R2224 nsp R,NETWORK A-TYPE 22-J*4 1/16W SMD(1005) WA04 C180220042100S 1
R2225 nsp R,NETWORK A-TYPE 1.8K-J*4 1/16W SMD(1005) WA04 C180182040500S 1 *
CAPACIITORS GROUP
C1008 nsp C,CERAMIC CHIP HIK X7R)4.7UF-K/6.3V-1608REEL D011475571160S 1
C1009 nsp C,CERAMIC CHIP HIK X7R)4.7UF-K/6.3V-1608REEL D011475571160S 1
C1010 nsp C,CERAMIC CHIP HIK X7R)4.7UF-K/6.3V-1608REEL D011475571160S 1
C1015 nsp C,CERAMIC CHIP HIK X7R)4.7UF-K/6.3V-1608REEL D011475571160S 1
C1030 nsp C,CERAMIC CHIP HIK X7R)4.7UF-K/6.3V-1608REEL D011475571160S 1
C1031 nsp C,CERAMIC CHIP HIK X7R)4.7UF-K/6.3V-1608REEL D011475571160S 1
C1032 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL D011104177101S 1
C1034 nsp C,CERAMIC CHIP HIK X7R)4.7UF-K/6.3V-1608REEL D011475571160S 1
C1035 nsp C,CERAMIC CHIP HIK X7R)4.7UF-K/6.3V-1608REEL D011475571160S 1
C1042 nsp C,CERAMIC CHIP HIK X7R)4.7UF-K/6.3V-1608REEL D011475571160S 1
C1043 nsp C,CERAMIC CHIP HIK X7R)4.7UF-K/6.3V-1608REEL D011475571160S 1
C1056 nsp C,CERAMIC CHIP HIK X7R)4.7UF-K/6.3V-1608REEL D011475571160S 1
C1057 nsp C,CERAMIC CHIP HIK X7R)4.7UF-K/6.3V-1608REEL D011475571160S 1
C1067 nsp C,CERAMIC CHIP HIK X7R)4.7UF-K/6.3V-1608REEL D011475571160S 1
C1068 nsp C,CERAMIC CHIP HIK X7R)4.7UF-K/6.3V-1608REEL D011475571160S 1
C1070 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL D011104177101S 1
C1073 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL D011104177101S 1
C1074 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL D011104177101S 1
C1075 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL D011104177101S 1
C1076 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL D011104177101S 1
C1077 nsp C,CERAMIC CHIP T.C COG)10PF-J/50V-1608REEL D010100167161S 1
27

Denon AVR-X3300W Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Pre-out channels	7.2
Pre-out connectivity	Yes
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.05 %
Power output per channel (1KHz@6 Ohm)	180 W
Power output per channel (20-20KHz@8 Ohm)	105 W
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W
Product color	Black
Audio decoders	DTS-HD, DTS-HD Master Audio, Dolby TrueHD
Multi-Zone quantity	2
Apple docking compatibility	-
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
HDMI in	8
Audio (L/R) in	5
Remote control in	1
Composite video in	3
Composite video out	0
Connectivity technology	Wired
Speakers connectivity type	Clamp terminals
Audio formats supported	AAC, AIFF, ALAC, DSD, FLAC, MP3, WAV, WMA

Weight and Dimensions

Depth	389 mm
Width	434 mm
Height	167 mm
Weight	10800 g
