HDMI

REF No. Part No. Part Name Remarks Q'ty New Ver

C2285 nsp C,CERAMIC CHIP HIK X7R)0.01UF-K/25V-1005REEL D011103174101S 1

C2286 nsp C,CERAMIC CHIP HIK X7R)0.01UF-K/25V-1005REEL D011103174101S 1

C2287 nsp C,CERAMIC CHIP HIK X7R)0.01UF-K/25V-1005REEL D011103174101S 1

C2288 nsp C,CERAMIC CHIP HIK X7R)0.01UF-K/25V-1005REEL D011103174101S 1

C2289 nsp C,CERAMIC CHIP HIK X7R)0.01UF-K/25V-1005REEL D011103174101S 1

C2290 nsp C,CERAMIC CHIP HIK X7R)0.01UF-K/25V-1005REEL D011103174101S 1

C2291 nsp C,CERAMIC CHIP HIK X7R)4.7UF-K/6.3V-1608REEL D011475571160S 1

C2292 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL D011104177101S 1

C2293 nsp C,CERAMIC CHIP HIK X7R)0.01UF-K/25V-1005REEL D011103174101S 1

C2294 nsp C,CERAMIC CHIP HIK X7R)4.7UF-K/6.3V-1608REEL D011475571160S 1

C2295 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL D011104177101S 1

C2296 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL D011104177101S 1

C2297 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL D011104177101S 1

C2298 nsp C,CERAMIC CHIP HIK X7R)0.01UF-K/25V-1005REEL D011103174101S 1

C2299 nsp C,CERAMIC CHIP HIK X7R)0.01UF-K/25V-1005REEL D011103174101S 1

C2300 nsp C,CERAMIC CHIP HIK X7R)4.7UF-K/6.3V-1608REEL D011475571160S 1

C2301 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL D011104177101S 1

C2302 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL D011104177101S 1

C2303 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL D011104177101S 1

C2304 nsp C,CERAMIC CHIP HIK X7R)0.01UF-K/25V-1005REEL D011103174101S 1

C2305 nsp C,CERAMIC CHIP HIK X7R)4.7UF-K/6.3V-1608REEL D011475571160S 1

C2306 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL D011104177101S 1

C2307 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL D011104177101S 1

C2308 nsp C,CERAMIC CHIP HIK X7R)0.01UF-K/25V-1005REEL D011103174101S 1

C2309 nsp C,CERAMIC CHIP HIK X7R)4.7UF-K/6.3V-1608REEL D011475571160S 1

C2310 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL D011104177101S 1

C2311 nsp C,CERAMIC CHIP HIK X7R)4.7UF-K/6.3V-1608REEL D011475571160S 1

C2312 nsp C,CERAMIC CHIP HIK X7R)4.7UF-K/6.3V-1608REEL D011475571160S 1

C2313 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL D011104177101S 1

C2314 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL D011104177101S 1

C2315 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL D011104177101S 1

C2316 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL D011104177101S 1

C2317 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL D011104177101S 1

C2320 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/25V-1608REEL D011104774161S 1

C2322 nsp C,CERAMIC CHIP T.C COG18PF-J/50V-1608REEL D010180167160S 1

C2323 nsp C,CERAMIC CHIP T.C COG15PF-J/50V-1608REEL D010150167160S 1

C2324 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL D011104177101S 1

C2325 nsp C,CERAMIC CHIP HIK X7R)1UF-K/10V-1608REEL D011105772161S 1

C2326 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL D011104177101S 1

C2327 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL D011104177101S 1

C2328 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL D011104177101S 1

C2329 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL D011104177101S 1

C2330 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL D011104177101S 1

C2331 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL D011104177101S 1

C2332 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL D011104177101S 1

C2333 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL D011104177101S 1

C2334 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL D011104177101S 1

C2335 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL D011104177101S 1

C2336 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL D011104177101S 1

C2337 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL D011104177101S 1

C2338 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL D011104177101S 1

C2339 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL D011104177101S 1

C2340 nsp C,CERAMIC CHIP HIK X7R)1000PF-K/50V-1005REEL D011102177101S 1

C2341 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL D011104177101S 1

C2342 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL D011104177101S 1

C2343 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL D011104177101S 1

C2344 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL D011104177101S 1

C2345 nsp C,CERAMIC CHIP HIK X7R)1000PF-K/50V-1005REEL D011102177101S 1

C2346 nsp C,CERAMIC CHIP HIK X7R)1000PF-K/50V-1005REEL D011102177101S 1

C2347 nsp C,CERAMIC CHIP HIK X7R)1000PF-K/50V-1005REEL D011102177101S 1

C2348 nsp C,CERAMIC CHIP HIK X7R)1000PF-K/50V-1005REEL D011102177101S 1

C2349 nsp C,CERAMIC CHIP HIK X7R)1000PF-K/50V-1005REEL D011102177101S 1

C2350 nsp C,CERAMIC CHIP HIK X7R)1000PF-K/50V-1005REEL D011102177101S 1

C2351 nsp C,CERAMIC CHIP HIK X7R)1000PF-K/50V-1005REEL D011102177101S 1

C2352 nsp C,CERAMIC CHIP HIK X7R)1000PF-K/50V-1005REEL D011102177101S 1

C2353 nsp C,CERAMIC CHIP HIK X7R)1000PF-K/50V-1005REEL D011102177101S 1

C2354 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL D011104177101S 1

C2356 nsp C,ELECT CHIP(GE) 10UF-MVG/16V,3.3*3.7*5.2 REEL (Z8154) SY D050100083470S 1

C2357 nsp C,CERAMIC CHIP HIK X7R)0.22UF-K/16V-1005REEL D011224773101S 1 *

C2358 nsp C,CERAMIC CHIP HIK X5R)2.2UF-M/6.3V-1005REEL GRM155R60J225ME15D D011225581100S 1

C2359 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL D011104177101S 1

C2360 nsp C,CERAMIC CHIP HIK X7R)0.22UF-K/16V-1005REEL D011224773101S 1 *

C2361 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL D011104177101S 1

C2362 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL D011104177101S 1

C2363 nsp C,CERAMIC CHIP HIK X5R)2.2UF-M/6.3V-1005REEL GRM155R60J225ME15D D011225581100S 1

C2364 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL D011104177101S 1

C2365 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL D011104177101S 1

C2366 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL D011104177101S 1

C2367 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL D011104177101S 1

C2368 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL D011104177101S 1

C2369 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL D011104177101S 1

C2370 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL D011104177101S 1

C2371 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL D011104177101S 1

C2372 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL D011104177101S 1

C2373 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL D011104177101S 1

C2374 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL D011104177101S 1

C2375 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL D011104177101S 1

C2376 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL D011104177101S 1

C2377 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL D011104177101S 1

C2378 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL D011104177101S 1

C2379 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL D011104177101S 1

OTHER PARTS GROUP

BKT1000 nsp BRACKET AVRX2100WBKE3(DENON) SPTE t0.5 A4/SCREW L6.65 4010216286000S 1

CLP1001 nsp CLAMP HMX9800(ON)(HAITAI) (W=2.6,L=50)/WIRE(SOLDER) 4330000120000S 1

K1002 00D9630217905 TER,RCA 2PIN RCA-206A-02 NI SHIELD(ORANGE,ORANGE) G601206A0200YS 1

L1000 nsp COIL,BEAD CB05YTYH221-2012REEL D340201292210S 1

L1001 963115100670S COIL,BEAD FBMJ3216HL160NT 16ohm SMD3216 D340321661600S 1

L1002 nsp COIL,BEAD CB05YTYH221-2012REEL D340201292210S 1

L1003 nsp COIL,BEAD CB05YTYH221-2012REEL D340201292210S 1

L1004 nsp COIL,BEAD CB05YTYH221-2012REEL D340201292210S 1

L1005 nsp COIL,BEAD CB05YTYH221-2012REEL D340201292210S 1

L1006 963115100670S COIL,BEAD FBMJ3216HL160NT 16ohm SMD3216 D340321661600S 1

L1007 nsp COIL,BEAD CB05YTYH221-2012REEL D340201292210S 1

L1008 963115100670S COIL,BEAD FBMJ3216HL160NT 16ohm SMD3216 D340321661600S 1

L1009 nsp COIL,BEAD CB05YTYH221-2012REEL D340201292210S 1

L1010 nsp COIL,BEAD CB05YTYH221-2012REEL D340201292210S 1

L1011 nsp COIL,BEAD CB05YTYH221-2012REEL D340201292210S 1

L1012 nsp COIL,BEAD CB05YTYH221-2012REEL D340201292210S 1

L1013 963115100670S COIL,BEAD FBMJ3216HL160NT 16ohm SMD3216 D340321661600S 1

L1014 nsp COIL,CHIP DLW21SN181SQ2L COMMON MODE CHOKE COILS SMD2012 D311201211810S 1

L1015 nsp R,CHIP THICK 0-J,1/10W-2012REEL C200000060201S 1

L1016 nsp COIL,BEAD CB05YTYH221-2012REEL D340201292210S 1

L1017 nsp COIL,CHIP DLW21SN900HQ2L COMMON MODE CHOKE COILS SMD2012 D311201219000S 1

Receiver type	Surround
Frequency range	10 - 100000 Hz
Pre-out channels	7.2
Pre-out connectivity	Yes
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.05 %
Power output per channel (1KHz@6 Ohm)	180 W
Power output per channel (20-20KHz@8 Ohm)	105 W
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W
Product color	Black
Audio decoders	DTS-HD, DTS-HD Master Audio, Dolby TrueHD
Multi-Zone quantity	2
Apple docking compatibility	-
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
HDMI in	8
Audio (L/R) in	5
Remote control in	1
Composite video in	3
Composite video out	0
Connectivity technology	Wired
Speakers connectivity type	Clamp terminals
Audio formats supported	AAC, AIFF, ALAC, DSD, FLAC, MP3, WAV, WMA

Depth	389 mm
Width	434 mm
Height	167 mm
Weight	10800 g
