Denon AVR-X4700H User Manual

.
Stereo
SSS
Dolby Digital
Dolby Digital
SSS
Dolby Digital + Dolby Surround z8 SSS
Dolby Digital + Neural:X z8 SSS
Dolby Digital Plus
Dolby Digital Plus
SSS
Dolby Digital Plus + Dolby Surround z8z9 SSS
Dolby Digital Plus + Neural:X z8 SSS
Dolby Atmos z8z10 SSS
Dolby TrueHD
Dolby TrueHD
SSS
Dolby TrueHD + Dolby Surround z8z9 SSS
Dolby TrueHD + Neural:X z8 SSS
Dolby Atmos z8z10 SSS
Dolby Atmos Dolby Atmos
SSS
Multi-channel z7
GAME button
MUSIC button
MOVIE button
Sound modeInput signal
z7
The sound mode that can be selected differs depending on the audio format of the input signal and the number of channels.
z8
This cannot be selected when headphones are used.
z9
This can be selected when the input signal does not contain Dolby Atmos.
z10
This can be selected when the input signal contains Dolby Atmos.
Contents Connections Playback Settings Tips Appendix
151
Front panel Display Rear panel Remote Index

Denon AVR-X4700H Specifications

General

Channels	9.2
HDMI Outputs	3
Dolby Atmos	Yes
DTS:X	Yes
IMAX Enhanced	Yes
4K/120Hz Pass-through	Yes
8K/60Hz Pass-through	Yes
Wi-Fi	Yes
Bluetooth	Yes
HEOS Multi-room	Yes
Voice Control	Amazon Alexa, Google Assistant, Apple Siri
Speaker Impedance	4-16 ohms
HDR Support	HDR10, HDR10+, Dolby Vision, HLG
eARC Support	Yes
Auro-3D	Yes
Audyssey MultEQ XT32	Yes
AirPlay 2	Yes
Phono Input	Yes
Input Sensitivity/Impedance	200mV/47k ohms
Analog Audio Inputs	6
Ethernet	Yes
Supported Audio Formats	MP3, WMA, AAC, FLAC, ALAC, WAV, DSD
Power Output	125W per channel (8 ohms, 20Hz-20kHz, THD: 0.05%, 2ch driven)
HDMI Inputs	8
Dimensions	17.1 x 15.3 x 6.6 inches
Zone Output	Zone 2, Zone 3
Frequency Response	10Hz-100kHz (+1, -3 dB, Direct Mode)
Total Harmonic Distortion	0.05% (20Hz-20kHz, 8 ohms)
Signal-to-Noise Ratio	102dB
Video Inputs/Outputs	Component (2 in / 1 out)
Digital Audio Inputs	Optical (2), Coaxial (2)
USB Port	1 (Front)
Supported Video Formats	4K, 8K
