Denon AVR-X4700H User Manual

o
Pre-out
When “Assign Mode” is set to “11.1ch”, selects the PRE OUT
connector the external power amplifier used in MAIN ZONE.
The PRE OUT connectors that can be selected differ depending on the
combination of “Floor” and “Height” - “Layout” settings configured in
the menu.
This can be set when “5ch & SB” is set for “Floor” in the menu and four
or more Height and Dolby speakers in total are used.
HEIGHT 2z
(Default):
The Height2 left and right pre-amplifier
outputs are connected to an external
amplifier.
Front:
The Front left and right pre-amplifier
outputs are connected to an external
amplifier.
z
The name of the speaker is displayed that is set for the HEIGHT 2 speaker
terminals by the “Height” - “Layout” setting in the menu.
o
View Terminal Config.
This shows how to connect the speaker terminals and PRE OUT
connectors for your “Amp Assign” setting on the menu screen.
Contents Connections Playback Settings Tips Appendix
237
Front panel Display Rear panel Remote Index

Denon AVR-X4700H Specifications

General

Channels	9.2
HDMI Outputs	3
Dolby Atmos	Yes
DTS:X	Yes
IMAX Enhanced	Yes
4K/120Hz Pass-through	Yes
8K/60Hz Pass-through	Yes
Wi-Fi	Yes
Bluetooth	Yes
HEOS Multi-room	Yes
Voice Control	Amazon Alexa, Google Assistant, Apple Siri
Speaker Impedance	4-16 ohms
HDR Support	HDR10, HDR10+, Dolby Vision, HLG
eARC Support	Yes
Auro-3D	Yes
Audyssey MultEQ XT32	Yes
AirPlay 2	Yes
Phono Input	Yes
Input Sensitivity/Impedance	200mV/47k ohms
Analog Audio Inputs	6
Ethernet	Yes
Supported Audio Formats	MP3, WMA, AAC, FLAC, ALAC, WAV, DSD
Power Output	125W per channel (8 ohms, 20Hz-20kHz, THD: 0.05%, 2ch driven)
HDMI Inputs	8
Dimensions	17.1 x 15.3 x 6.6 inches
Zone Output	Zone 2, Zone 3
Frequency Response	10Hz-100kHz (+1, -3 dB, Direct Mode)
Total Harmonic Distortion	0.05% (20Hz-20kHz, 8 ohms)
Signal-to-Noise Ratio	102dB
Video Inputs/Outputs	Component (2 in / 1 out)
Digital Audio Inputs	Optical (2), Coaxial (2)
USB Port	1 (Front)
Supported Video Formats	4K, 8K
