Page #267 background imageLoading...
Page #267 background image
Trigger Out 1 / Trigger Out 2
Select the conditions for activating trigger out.
For details about how to connect the TRIGGER OUT jacks, see
“TRIGGER OUT jacks” (v p. 88).
n
When setting for zone (MAIN ZONE / ZONE2 /
ZONE3)
Trigger out is activated through linkage to the power of the zone set to
“On”.
n
When setting for input source
Activate trigger out when the input source set to “On” is selected.
n
When setting for HDMI monitor
Activate trigger out when the HDMI monitor set to “On” is selected.
On:
Activate trigger on this mode.
– – –: Do not activate trigger on this mode.
Front Display
Makes settings related to the display on this unit.
o
Dimmer
Adjust the display brightness of this unit.
Bright
(Default):
Normal display brightness.
Dim: Reduced display brightness.
Dark: Very low display brightness.
Off: Turns the display off.
0
You can also adjust the display by pressing DIMMER on the main unit.
Contents Connections Playback Settings Tips Appendix
267
Front panel Display Rear panel Remote Index

Table of Contents

Other manuals for Denon AVR-X4700H

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Denon AVR-X4700H and is the answer not in the manual?

Denon AVR-X4700H Specifications

General IconGeneral
Channels9.2
HDMI Outputs3
Dolby AtmosYes
DTS:XYes
IMAX EnhancedYes
4K/120Hz Pass-throughYes
8K/60Hz Pass-throughYes
Wi-FiYes
BluetoothYes
HEOS Multi-roomYes
Voice ControlAmazon Alexa, Google Assistant, Apple Siri
Speaker Impedance4-16 ohms
HDR SupportHDR10, HDR10+, Dolby Vision, HLG
eARC SupportYes
Auro-3DYes
Audyssey MultEQ XT32Yes
AirPlay 2Yes
Phono InputYes
Input Sensitivity/Impedance200mV/47k ohms
Analog Audio Inputs6
EthernetYes
Supported Audio FormatsMP3, WMA, AAC, FLAC, ALAC, WAV, DSD
Power Output125W per channel (8 ohms, 20Hz-20kHz, THD: 0.05%, 2ch driven)
HDMI Inputs8
Dimensions17.1 x 15.3 x 6.6 inches
Zone OutputZone 2, Zone 3
Frequency Response10Hz-100kHz (+1, -3 dB, Direct Mode)
Total Harmonic Distortion0.05% (20Hz-20kHz, 8 ohms)
Signal-to-Noise Ratio102dB
Video Inputs/OutputsComponent (2 in / 1 out)
Digital Audio InputsOptical (2), Coaxial (2)
USB Port1 (Front)
Supported Video Formats4K, 8K
