Denon AVR-X4700H - Example Connection When Using One Set of Dolby Atmos Enabled Speakers

o
Example connection when using one set of Dolby Atmos Enabled speakers
.
C
SBL
SBR
SW
SL SR
FL
FR
FDL FDR
0
Set “Height” - “Dolby Sp” to “2ch” in the menu when connecting in this
configuration. (v p. 233)
.
FR FL C SR SL
SW
SBR SBL
FDR FDL
HEIGHT 1
z
z
The surround Dolby or back Dolby speakers can be connected instead of the
front Dolby speakers. In this case, set the Dolby Atmos Enabled speakers to be
connected under “Height” - “Layout” in the menu. (v p. 234)
