Denon AVR-X4700H User Manual

Playback in ZONE2/ZONE3
.
SOUND MODE
SOUND MODE
AVR CONTROL
AVR CONTROL
QUICK SELECT
QUICK SELECT
TUNE
TUNE
TUNE
TUNE
PURE
PURE
MOVIE
MOVIE
GAME
GAME
MUSIC
MUSIC
OPTION
OPTION
INFO
INFO
BACK
BACK
SETUP
SETUP
CH/
PAG E
PAGE
MENU
MENU
Z2
Z 3
Z 3
1
1 2 3 4
2 3
4 5 6
7 8 9
ENTER
ENTER0
+10
+10
GHI
GHI
JKL
JKL
MNO
MNO
PQRS
PQRS
TUV
TUV
ABC
ABC
. /
. /
DEF
DEF
SLE
EP
EP
WXYZ
WXYZ
MAIN
MAIN
DE
V.
V. TV AVR
DEVICE
DEVICE T V
MENU
MENU
ECO
ECO
ENTER
ENTER
POWER
POWER
GAME
GAME
CB
CBL/
SAT
Blu-ray
Blu-ray
D
VD
VD
AUX
AUX
8K
8K
INTERNET
R
ADIO
ADIO
PHONO
PHONO
MED
IA
IA
PLAY
ER
ER
CD
CD
Bluetooth
Bluetooth
TUNER
TUNER
TV
AUDIO
AUDIO
INP
INPUT
VOLUME
VOLUME
MUTE
MUTE
USB
USB
VOLUME
df
POWER
X
Z2
Z3
MUTE
:
Input source
select buttons
1
Press Z2 or Z3 to switch the zone mode.
Z2 or Z3 button lights.
2
Press POWER X to turn on the ZONE2 or ZONE3 power.
The j indicator on the display lights.
0
Power in ZONE2 or ZONE3 can be turned on or off by pressing
ZONE2 ON/OFF or ZONE3 ON/OFF on the main unit.
3
Press the input source select button to select the input
source to be played.
The audio signal of the selected source is output to ZONE2 or
ZONE3.
0
To perform an operation with the main unit, press ZONE2
SOURCE or ZONE3 SOURCE. Each time you press ZONE2
SOURCE or ZONE3 SOURCE, the input source changes.
0
Setting the input source of ZONE2 as the “Source” allows you to play the same
content in MAIN ZONE and in ZONE2, regardless of the type of input signal.
0
Set the input source of ZONE2 as the “Source” by pressing the ZONE2
SOURCE button on the main unit.
0
If the MAIN ZONE input source is changed while ZONE2 is selected as the
“Source”, then ZONE2’s input source will be changed to mirror the MAIN
ZONE’s input source.
0
As well as ZONE2, you can play the same content of MAIN ZONE when the input
source of ZONE3 is set as “Source”.
Contents Connections Playback Settings Tips Appendix
175
Front panel Display Rear panel Remote Index

Denon AVR-X4700H Specifications

General

Channels	9.2
HDMI Outputs	3
Dolby Atmos	Yes
DTS:X	Yes
IMAX Enhanced	Yes
4K/120Hz Pass-through	Yes
8K/60Hz Pass-through	Yes
Wi-Fi	Yes
Bluetooth	Yes
HEOS Multi-room	Yes
Voice Control	Amazon Alexa, Google Assistant, Apple Siri
Speaker Impedance	4-16 ohms
HDR Support	HDR10, HDR10+, Dolby Vision, HLG
eARC Support	Yes
Auro-3D	Yes
Audyssey MultEQ XT32	Yes
AirPlay 2	Yes
Phono Input	Yes
Input Sensitivity/Impedance	200mV/47k ohms
Analog Audio Inputs	6
Ethernet	Yes
Supported Audio Formats	MP3, WMA, AAC, FLAC, ALAC, WAV, DSD
Power Output	125W per channel (8 ohms, 20Hz-20kHz, THD: 0.05%, 2ch driven)
HDMI Inputs	8
Dimensions	17.1 x 15.3 x 6.6 inches
Zone Output	Zone 2, Zone 3
Frequency Response	10Hz-100kHz (+1, -3 dB, Direct Mode)
Total Harmonic Distortion	0.05% (20Hz-20kHz, 8 ohms)
Signal-to-Noise Ratio	102dB
Video Inputs/Outputs	Component (2 in / 1 out)
Digital Audio Inputs	Optical (2), Coaxial (2)
USB Port	1 (Front)
Supported Video Formats	4K, 8K
